CIRCLE FITNESS B-7 SERIES Engineer's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Document NO.
B-7A-EM-English
Engineer Manual-Trouble Shooting
PAGE
Page 1 of 14
VERSION
A
ENGINEER MANUAL FOR
AFTER SALE SERVICE
PRODUCT：UPRIGHT BIKE
MODEL： B-7 SERIES A TYPE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-7 SERIES and is the answer not in the manual?

Questions and answers

Related Manuals for CIRCLE FITNESS B-7 SERIES

Summary of Contents for CIRCLE FITNESS B-7 SERIES

  • Page 1 Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 1 of 14 VERSION ENGINEER MANUAL FOR AFTER SALE SERVICE PRODUCT：UPRIGHT BIKE MODEL： B-7 SERIES A TYPE...

  • Page 2: Table Of Contents

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 2 of 14 VERSION INFORMATION GUIDE： 1. Problem Check Steps And Solutions 1.1 No Resistance ----- Page 3~5 1.2 No Any Display On Console(No Power) ----- Page 6~8 1.3 Can Not Keep Display While Stop Paddling ----- Page 9 1.4 Too Heavy Or Light Resistance ----- Page 9 1.5 Abnormal Display On Console...

  • Page 3: No Resistance

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 3 of 14 VERSION 1. Problem Check Steps And Solutions 1.1. 【No Resistance】 ：Press START and adjust the LEVEL by press UP or DOWN key, but no any change on the resistance. ※...
  • Page 4 Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 4 of 14 VERSION Step illustrate Auxiliary Photo To open the housing a side. Take off the screws. Take off the screws. Take off the housing. Fix back the crank.
  • Page 5 Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 5 of 14 VERSION Step illustrate Auxiliary Photo Start to paddling and press START to begin. Check the pilot lamp LED3 where on the resistance control board. Is it light up? It shall be light up or flash depend on paddling speed and level in the normal condition.

  • Page 6: No Any Display On Console(No Power)

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 6 of 14 VERSION 1.2. 【No Any Display On Console(No Power)】 ：No any display on console when paddling. ※ If this is a all new product that just finished assemble, there are more possibly in assemble problems, maybe connect wire not well or wire damaged while assemble.

  • Page 7: No Resistance

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 7 of 14 VERSION Step illustrate Auxiliary Photo Start to paddling. To measure the power supply component where on the console PCB by multi-meter. It shall have about 12Vdc input and 5Vdc output in the normal condition.
  • Page 8 Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 8 of 14 VERSION Step illustrate Auxiliary Photo If LED1 did not light up when paddling, to measure the terminal JK1 where on the control board when paddling. It shall have AC voltage and the value high or low depend on paddling speed, paddling faster the voltage will be higher.

  • Page 9: Can Not Keep Display While Stop Paddling

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 9 of 14 VERSION 1.3. 【Can Not Keep Display While Stop Paddling】 ： Steps illustrate： Step illustrate Auxiliary Photo To open the housing a side. According to 1.1.【No Resistance】step 3 Replace the battery. Refer to：...

  • Page 10: No Any Display On Console(No Power)

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 10 of 14 VERSION 1.5. 【Abnormal Display On Console】 ： Steps illustrate： Step illustrate Auxiliary Photo Start to paddling and press START to begin. If all functions are fine but display, please replace the console PCB. 1.6.

  • Page 11: Resistance Control Board

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 11 of 14 VERSION 2. Information For Components 2.1. Resistance Control Board 2.1.1.Appearance and connector description： Console wire Generator power source input External power Battery Coil power output 2.1.2.Description of pilot lamps on Control Board： LED1: Main power pilot lamp, lights up when paddling.

  • Page 12: Console Wire

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 12 of 14 VERSION 2.2. Console Wire：Check all connect certainty and outward completely. Step illustrate Auxiliary Photo Take off the console and pull out the console wire connector plug. Take off the screws. Dis-connect the console wire.

  • Page 13: Battery

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 13 of 14 VERSION 2.3. Battery： Step illustrate Auxiliary Photo To measure the battery, it shall be have 12~13Vdc。 2.4. Membrane Key：PINs definition Display Down( ) START Enter UP( )

  • Page 14: Engineering Mode One： Factory Settings

    Document NO. B-7A-EM-English Engineer Manual-Trouble Shooting PAGE Page 14 of 14 VERSION 3. Engineering Mode 3.1. Engineering Mode ONE： Factory Settings 3.1.1.Console no power condition, press START and UP simultaneously and start to paddling, To leave you hand from keys till dot-matrix window show WELCOME. 3.1.2.LED will do the scan mode after dot-matrix window show WELCOME, then dot-matrix will show『BM010 FACTORY SETTINGS PRESS ENTER』.
