- Page 1 Owner’s Manual (Premium version) Indoor Cycle...
- Page 3 ATTENTION: S831102-000-00 Sp7(Premium version) 10807 Read instructions carefully, failure to do so may cause permanent damage to your bike. Please verify that all parts associated with this product are in good condition and accounted for. During the assembly process please be sure to follow each step accordingly as it has been...
-
Page 4: Safety Information
SAFETY INFORMATION: 1. Keep children and pets away from this equipment at all times. DO NOT leave them unsupervised in the room where the machine is kept. 2. If you experience dizziness, nausea, chest pains or any other symptom while using this machine STOP the exercise. - Page 5 CAUTION: During assembly it is recommended that all bolts be tightened by hand, upon completing assembly, bolts should then be properly secured using the wrench provided. To avoid injury, check bolts carefully before use. Assembly Step one Attach the rear foot tube (14) first by lifting up the rear of the frame and sliding the rear foot tub under the frame.
- Page 6 Step three Attach the saddle (1) onto seat slider (42), and secure the saddle by tightening the nuts on both sides of the saddle clamp on the underside of the saddle, use wrench. Slide the seat slider (42) into the seat post (43) adjust to desired position and secure with the release lever (6) on the bottom of the seat post (43).
-
Page 7: Right Pedal
Right Pedal Please make sure pedal in your hand is the right pedal before Installation. Please refer to the figure. Align the right pedal with right crank at 90 degree. Gently insert the pedal in the crank arm. Turn the pedals clockwise as tightly as you can with your hand. Use the wrench to ensure it is tightened securely. -
Page 8: Adjusting The Resistance
Adjusting the resistance Adjust the exercise resistance on the spinning bike which using the RED LEVER (51) of the Tension knob (24) to work with Level 1-16 (loosen to tighten). The flywheel should rotate freely without resistance when you loosen the Tension knob fully (Level 1). -
Page 9: Exploded Drawing
Exploded Drawing... -
Page 10: Part List
Part list Name Unit No. Name Unit Alloy bind clamp ( L ) Plastic washer for release lever Spring for release lever Fixed bolt for release lever Alloy bind clamp ( R ) 42,67 Seat slider w/end plug Washer for release lever 43,74 Seat post w/ Rubber sleeve Release lever Washer for release lever... - Page 11 Instruction Handlebar and seat adjustment. It is important that the handlebar and seat are set at the correct height for your body. Ask your instructor for assistance. Adjusting the handlebar height-Undo the release lever that is located where the handlebar post fits into the frame. Slide the handlebar post up or down to the required height and retighten the release lever.
-
Page 12: Maintenance Chart
Maintenance Chart DESCRIPTION Daily Weekly Monthly Quarterly Annually Keep machine clean: Wipe machine down with clean & dry fabric to clear dirt & sweat. Wipe Anti-rusty cream or similar on the seat post set, handlebar set Check security of handle bar post & seat post Check security of saddle Remove handlebar post and clean... -
Page 13: How To Change Battery
How to change battery ﹕ ﹕ 1. Open battery cover and insert 2 AA or 2 UM-3 batteries. 2. Properly put back battery cover. 3. If the LCD shows partial display, please take out batteries, wait for 15 seconds and insert again. 4. -
Page 14: Function And Operation
UP+DOWN： 1. Press UP key and DOWN key at the same time for 3 seconds to delete date. Function and Operation Auto ON/OFF The monitor automatically starts working once the user starts to do the exercise on the machine. It will automatically turn off after the machine is not used for around 2 minutes, and all exercise value will be removed. - Page 16 (Premium version) Indoor Cycle www.circlefitness.com...
