In-bottom/Out-top Cooling Kit for FA09-FA10
Installation Guide
2.
Insert 4 M10 pem self-clinching nuts (not supplied) in the mounting holes.
2x Ø 8 (0.3)
Drive Mounting Holes
844 (33.2)
Illustration 7: FA09 Mounting Plate Template
Danfoss A/S © 2022.03
180 (7.1)
200 (7.9)
2x Ø 8 (0.3)
Drive Mounting Holes
AN371942791357en-000101 / 136R0254 | 9
Installation
