01154020
01154120
01154030
01154130
01154040
01154140
Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo mn Italy. tel +39 0376 771 777 ‐ fax +39 0376 772 140 ‐ email info@ldr.it
Arpa 8/22 150 W LED, 3200K
Arpa 8/22 150 C LED, 5600K
Arpa 18/36 W LED, 3200K
Arpa 18/36 C LED, 5600K
Arpa 30/55 W LED, 3200K
Arpa 30/55 C LED, 5600K
istruzioni per l'uso
operating instructions
Bedienungsanleitung
instrucciones de manejo
mode d'emploi
gebruiksaanwijzing
DMX512 +RDM
Advertisement
Table of Contents
Related Manuals for LDR Arpa 8/22 150 W LED, 3200K
Summary of Contents for LDR Arpa 8/22 150 W LED, 3200K
- Page 1 Bedienungsanleitung instrucciones de manejo mode d'emploi gebruiksaanwijzing Arpa 8/22 150 W LED, 3200K 01154020 Arpa 8/22 150 C LED, 5600K 01154120 01154030 Arpa 18/36 W LED, 3200K Arpa 18/36 C LED, 5600K 01154130 Arpa 30/55 W LED, 3200K 01154040 Arpa 30/55 C LED, 5600K 01154140 DMX512 +RDM Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo mn Italy. tel +39 0376 771 777 ‐ fax +39 0376 772 140 ‐ email info@ldr.it...
-
Page 2: Table Of Contents
13.16 ID for REMOTO ................ 10 13.17 Calibration .................. 11 13.18 Exit hidden menu ................ 11 14. Cleaning and maintenance .............. .11 15. Spare parts .................. .11 16. Warranty .................... ..11 SUMMARY OF CONTROLS AND OPERATION 17. Summary of the ALBA functions ............ 12 18. DMX Charts .................. 13 18.1 DMX Chart 1 .................. 13 18.2 DMX Chart 2 .................. 13 18.3 DMX Chart 3 .................. 14 18.4 DMX Chart 4 .................. 15 LDR Conformity Certificate – Certificato di Conformità – Konformitätserklärung page 16 Complaint form – Modulo di reclamo – Reklamationsformular …………………………. page 17 WEEE Directive – Direttiva RAEE – WEEE Richtlinie …………………………………………… page 18 1 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 3: Important Safety Norms
The limitation extends to damages for personal injury, property damage, loss of operations, loss of profits, loss of product or loss of time, whether incurred in by the customer, the customer’s employees or a third party. Apart from the instructions given on this manual, all relevant safety and health standards of the appropriate EU Directives or the local safety must be complied with. 1. IMPORTANT SAFETY NORMS This product is a professional lighting fixture, namely a profile spot, fitted with a LED light source, which can only be operated by professional staff This product must be fitted with a secondary fixing system such as a safety chain or bond. Should this not be supplied as a standard accessory, please make sure you buy it separately and install it before using the product Warning, high voltage ignition. Disconnect the unit from power before servicing Continuous mains power is required for this spotlight as an internal dimmer controls the intensity via DMX or local rotary knob. Use of a phase control dimmed mains supply may damage the internal electronics This product features fan‐assisted ventilation. Make sure you do not cover the fans or obstruct the air flow at any time Make sure all fans are working correctly at any one time. Should you detect even the slightest malfunction, switch the luminaire off and carry out the necessary servicing. Replace the fans if necessary. This product is rated IP 20 and is therefore designed for interior use only. For details on maximum ambient temperature and tilt angle please refer to what indicated on the product label or screen‐ printing on the side of the lens‐tube or the rear of the LED‐house Repairing and replacement of any component of this product must be carried out exclusively by professional personnel in conformity with the relevant safety and health standards and only with original Luci della Ribalta srl components. 2 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 4: Box Contents
Arpa 8/22, 18/36 and 30/55 150W LED User’s Manual – 2.0 Replacement of any part of the wiring system must be carried out exclusively by professional personnel in compliance with the original wiring diagram and with components identical to or compatible with those originally fitted. Installation of this product must be exclusively carried out by professional personnel in compliance with the safety norms in force in the country where the product is used WARNING: DANGER OF ELECTRICAL SHOCK DO NOT OPERATE ON LIVE EQUIPMENT Disconnect power before opening this fixture to access its light source or electronics. The replacement of the LED source or any of its electronic components can be carried out exclusively by professional personnel upon LDR’s written authorization and only with original Luci della Ribalta srl components. Failure to obtain the manufacturer’s authorization to carry out the replacement/repair, will immediately invalidate the product’s warranty WARNING: EYE DAMAGE HAZARD Make sure this fixture is installed so as to avoid prolonged direct staring at its operating light source (LED) from a distance of less than 7m / 23ft. WARNING: FIRE HAZARD Never locate this fixture on any flammable surface. Minimum distance of any part of the body of the luminaire from any flammable surface or object: 0,5m / 20in Minimum distance from lit surface, please refer to product label ... -
Page 5: Weight And Dimensions
MOUNTING / REPLACING THE GOBO‐HOLDER – not supplied Alba profile spots can be fitted with a gobo holder – not supplied in standard delivery but obtainable as a separate accessory, for the projection of: A‐or B‐size metal gobos part # A20100807 A‐size glass gobo part # A20100807/A B‐size glass gobo part # A20100807/B The gobo holder must be inserted in the gate area instead of the iris diaphragm. Usage of both accessories at the same time is not possible. In order to fit or replace a gobo holder, please: Remove the iris diaphragm if fitted (see above) Slide the gobo‐holder in the gate area – bent metal wings must look to the LED‐house Make sure it is correctly positioned and apply pressure to the plastic holder if needed CAUTION: the metal surface of the gobo holder reaches very high temperatures during operation. Make sure the unit is totally cold before attempting to remove it, protect you hands with gloves and avoid skin direct contact with its metal surface IMPORTANT NOTICE BEFORE THE INSTALLATION / INSTALLATION Before installing this fixture check its weight on the product label and the weight of each accessory you are adding and make sure the structure you are installing it to withstands the total weight. 4 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 6: Wiring
When tilting the unit make sure the knob blocking the stirrup is strongly tightened at any time and that the luminaire can hold the desired tilt angle 7. WIRING Before being connected to the mains power, this unit may need to be wired with a suitable plug if not already installed. Make sure the plug you are using is rated for the proper power load and it conforms to the relevant EU/UL electrical standards. Make sure the plug you are fitting withstands the lamp power load. This fixture must be grounded To perform a correct wiring, please note that the cores in this mains lead are colour‐coded as follows: Ground: green+yellow – Neutral: blue ‐ Phase: brown 5 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 7: Voltage
Before operating this unit please refer to the product label mounted at the back of the luminaire to check you are operating with the correct voltage. The Alba profile can be operated between 90V and 260V and the electronic PSU inside the fixture will automatically switch to the available voltage. FREQUENCY Frequency on this product is automatically selected by the electronic PSU (50/60Hz) 10. MECHANICAL OPERATION Installation: this fixture is fitted with a mounting stirrup which is factory‐set for the installation from above (suspended) using a C‐clamp or similar. In case you need to install the fixture on a tripod or support, (see above for reference) Note: the spotlight’s location must provide suitable ventilation for the LED module. For minimum distance from flammable and lit surface please refer to the FIRE HAZARD section in this manual or to the product’s label Focus control: the ARPA range of LED profile spots is available in 3 variable beam angle models, including 8° to 22°, 18° to 36° and 30° to 55°. Two large, easy‐to‐grab control knobs on the right‐hand side of the lens‐tube control the focus. The variable beam is modified by adjusting the front and rear zoom lenses in relation to each other. The front lens defines the beam spread, the rear lens defines the focus degree of ‘softness’ or ‘hardness’ of the beam edge or shutters. The beam distribution (peak/flat) is fixed. Gently turn the knobs anti‐clockwise until you have reached the desired size/focus of the beam in relation to the distance you are projecting at. Turn the knobs clockwise and tightly close them so that the lenses are held in position at any tilt angle Beam‐shaping: 4 shutter blades are provided with each fixture to shape the beam geometrically Beam‐sizing: an accessory iris diaphragm, part # A20100707 can be purchased separately and used to size the beam of the ARPA Tilt control: The stirrup is factory‐balanced and fitted with a positive friction clamp controlled by a user‐ friendly, effective lever‐knob. Turn the lever anticlockwise to release it, position the profile at the desired tilt angle and turn the lever clockwise to hold the desired position. Press the button at the top of the lever and keep it pressed while turning the lever if you need to change its position. 6 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 8: Connect To The Power Supply
Tap the rotary selector and the LCD screen will display the mode status and the current value: 1 Mode M: DMX TAP THE ROTARY 00 % = LED OFF SELECTOR TO DISPLAY 100 % = LED FULL XX % THE VALUE 1 Mode M: Manual 00 % (000) = LED OFF TAP THE ROTARY 100% (FFF) = LED FULL SELECTOR TO DISPLAY XX % XXX MANUAL THE VALUE 7 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 9: Dmx Address
6 SetStr 6 SetStr THE MENU, AN WITH STROBE ENABLE OPEN ARROW SHOULD OPEN THE LIGHT IS SET TO ON APPEAR 6 SetStr CHOOSE THE STROBE SPEED VALUE FROM SPEED # 1(SLOW) TO 10 (FAST) 6 SetStr WITH STROBE ENABLE THE LIGHT IS SET TO CLOSED OFF 8 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 10: Dimming Curve
PRESS TO ACTIVATE 10 Fan 10 Fan FAN SPEED IS THE MENU, AN REGULATED BY LED AUTO ARROW SHOULD AUTO TEMPERATURE APPEAR 10 Fan SLOW FAN SPEED TO SILENT REDUCE THE NOISE 10 Fan CONSTANT FAN SPEED STEADY 9 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 11: Lcd Screen Illumination
BASIC ProBasic ARROW SHOULD PRESS TO CONFIRM APPEAR 13.15 FACTORY SETTINGS (Reset) The RESET control is a special function which allows to RESET the product to factory settings. Choose Are You MenuType PRESS TO ACTIVATE PRESS TO CONFIRM BASIC Reset SURE? THE MENU THE RESET 13.16 ID for REMOTO (ID Rem): Remoto is a control device which allows to upgrade your ARPA with the latest software version or to load and download stored info. It is available as an optional accessory as follows A20702072 REMOTO control unit To change the initial ID press the rotary switch until an arrow appears, then turn to change to the desired ID number. Press to confirm your selection. It is possible to select an ID number from 0 to 250. If ID number=0 remote control is not active. Factory setting is 000. Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 12: Calibration
14. CLEANING AND MAINTENANCE To ensure maximum performance of the product, a regular maintenance service should be carried out. Please make sure the product is cold and disconnected from power supply when doing this. General maintenance * Clean all reflective parts such as lenses opening the product, if necessary. * Check the lenses and replace any visibly damaged component. * Clean air ducts and fans in order to allow a proper ventilation activity on the product. * Check internal and external wiring and replace any cable which should be damaged by heat or mechanical agents. Cleaning of optical components LEDhouse lenses: Open the lens compartment door by removing the two M4 cross head screws on the top of the LEDhouse tube and slide the top cover free Remove the condensor lenses assembled block by removing the two M5 cross head screws. Clean the lenses with a soft cloth and re‐position Zoom lenses: Slide the front zoom panels positioned at the bottom of the lens tube and clean with a soft cloth. 15. SPARE PARTS All components are available as spare parts. We strongly recommend you always use original LDR components as spare parts. Please refer to our technical assistance should you need to order and/or replace any part of the unit. 16. WARRANTY Our warranty covers all structural and manufacturing defects for a period of one year from the date of purchase. In case of complaint, we strongly recommend that in the first instance you contact the local dealer who supplied the product to you. In all cases, please refer to the serial number located at the rear of the spotlight. Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... - Page 13 SLOW = ACTIVE NORMAL = 150ms; SLOW = 9 Smooth Dimmer response 300ms FAST = Immediate NORMAL response AUTO = regulated by Tled; 10 Fan Fan setting SILENT = slow speed, low noise; AUTO STEADY = constant speed ON; AutoOFF = LCD light off after 11 BackL LCD screen retro‐illumination AutoOff 1'30" 12 Tled Visualizes the LED temperature Select the LED Temp in °C or F° °C ‐‐‐ 13 SwVer Visualizes the software version ENCODER = Rotary switch; 14 Manu Selects the manual dimmer type ENCODER POTENT = External slider Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
-
Page 14: Dmx Charts
This DMX chart refers to the luminaire set at 16 bits resolution (See chapter 13.3 of this user guide). DMX Type of Percentage Function Effect Decimal Channel Control Master Adjusts luminous output intensity ‐ 255 0% ‐ 100% 1 Proportional 0 Dimmer from 0 to 100% ‐ 255 0% ‐ 100% 2 Dimmer Fine Proportional Fine dimmer control 16 bit 0 Table name: DMX512 Functions Date: Projector: ARPA White Edition: 1 chart 2 (16 bits) 16/05/2018 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... -
Page 15: Dmx Chart 3
221 ‐ 255 87% ‐ 100% Step Closed Table name: DMX512 Functions Date: Projector: ARPA White Edition: 1 chart 3 (Strobe) 16/05/2018 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ... - Page 16 Step Strobe speed 8 181 ‐ 200 72% ‐ 78% Step Strobe speed 9 Strobe speed 10 (maximum 201 ‐ 220 79% ‐ 86% Step frequency) 221 ‐ 255 87% ‐ 100% Step Closed Table name: DMX512 Functions Date: Projector: ARPA White Edition: 1 chart 4 (16 bits + Strobe) 16/05/2018 Luci della Ribalta srl reserves the right to modify the present document without prior notice. Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
- Page 17 P .iva 01815640204 c.iso IT01815640204 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo MN Italy - tel +39 0376 771777 - web www.ldr.it - email info@ldr.it IT/015/MN/11 VAT registration # It01815640204 - REA MN 198438 - Authorized Exporter #...
- Page 18 Reklamationsformular ‐ formulaire de réclamation ‐ hoja de reclamaciones email: info@ldr.it Azienda ed Indirizzo ‐ Company's name and address ‐ Firmenname und Addresse ‐ Nom et adresse ‐ Nombre y direcciòn _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ Nome del rivenditore da cui il prodotto è stato acquistato ‐ Name of the dealer where you have purchased the product ‐ Namen der Firma, die Ihnen das Produkt verkauft hat ‐ Nom de la société qui vous a vendu ce produit ‐ Nombre de la compañia donde han comprado el producto: ____________________________________________________________________________________________________ 01154020 Arpa 8/22 150 W LED, 3200K Prodotto difettoso 01154120 Arpa 8/22 150 C LED, 5600K Faulty product 01154030 Arpa 18/36 W LED, 3200K Defekte s Produkt 01154130 Arpa 18/36 C LED, 5600K Produit défectueux Arpa 30/55 W LED, 3200K Producto defectuoso 01154040 Arpa 30/55 C LED, 5600K 01154140 Descrizione del problema /Problem found/Beschreibung des Defekts/Description du défaut/Descripciòn del problema ________________________________________________________________________________________________________ ________________________________________________________________________________________________________...
- Page 19 local de escoamento de residuos, ou a loja na qual efectuou a compra. Richtlinie 2002/96/EU (Elektro- und Elektronik- Altgeräte - WEEE): Benutzerinformationen. Dieses Produkt entspricht Richtlinie WEEE-symbolet (Waste Electrical 2002/96/EU. Das Symbol des auf dem Gerät Electronic Equipment). dargestellten, durchgestrichenen Korbes gibt an, dass Bruken av WEEE-symbolet indikerer at dette Produkt Ende...
- Page 20 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo mn Italy. tel +39 0376 771 777 ‐ fax +39 0376 772 140 ‐ email info@ldr.it...
