Rear view showing VESA mounting holes.
1.3 INSTALLATION
SMC highly recommend that the SMC-1310 Data Display is attached to a wall or suitable surface
using a VESA compatible mounting.
The VESA spacing is 100 x 100 mm
The Panel PC should not be mounted outside.
1.3.1 INSTALLATION LOCATION RECOMMENDATION S
Install the SMC-1310 Data Display in an area with free air flow. The SMC-1310 is a fanless device and
the air need to be able to circulate through the ventilation holes in the case.
Avoid positioning the display sensor in direct sunlight. Where possible the display should be mounted
away from heat sources.
6
SMC-1310 User Guide revision 1.1
SMC Ship Motion Control
www.shipmotion.eu
