4 TECHNICAL SPECIFICATIONS SMC-1310

System
Communication
External output
Physical
Environmental
Electrical
Warranty & Support
SMC-1310 User Guide revision 1.1
Processor
Operating System
Storage
RAM
Display size
Brightness
Aspect Ratio
Resolution
Viewing angle
Touch Type
Mounting
User configurable serial inputs.
2xRS232 or 2x RS422/RS485
USB A for data export
Ethernet
Serial, Ethernet, SNMP, MODBUS TCP/RTU
Housing Material UV resistant ABS plastic
Dimensions (W x H x D) 260 x 178 x 42mm
Weight 1.2 kg
Terminal and PSU connectors included
Operating Temperature 0° to +50° Celsius
MTBF (computed) 50 000 hours
IP22
Power requirements 12 - 36 VDC
Power consumption 20W
Complies with the IEC 60945
2-year Limited Hardware & Software Warranty
Free Technical & Hardware support
SMC Ship Motion Control
ARM based processor
Linux
8 GB
2 GB
10.1 inch
800 cd/m2
16:10
1280x800
89 degrees
Capacitive
VESA 75x75mm
