1 INTRODUCTION
The SMC-1310 Panel Display is a reliable and cost effective way to process, log and display data from
Motion Reference Units and/or Weather sensors.
The SMC-1310 can receive data on multiple serial RS232, RS422, RS485 ports and over ethernet. The
panel display accepts data in NMEA formats and many proprietary formats.
Data can be transmitted from the display to another receiving device, via serial or ethernet using the
external output.
The data received can be displayed in one of the SMCs Monitoring System applications for graphical
presentation and data logging.
The SMC-1310 is intended to be used in indoor applications.
1.1 RECEIVING THE DISPLAY
Unpack the equipment and remove all the packaging materials and shipping carton.
The SMC-1310 Display is delivered in a cardboard box designed to protect it from damage during
transit.
When the Panel Display has been received, it must be inspected for damage during shipment. If
damage has occurred during transit, all the shipping cartons and packaging materials should be
stored for further investigation. If damage is visible, a claim for shipping damage must be filed
immediately.
Standard Delivered Items
•
Display Panel
•
USB memory
•
Cable Connectors
Optional Items
•
VESA mount
•
Power adapter
