- Page 1 SMC-1310 PANEL DISPLAY USER GUIDE SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu...
- Page 2 SMC Ship Motion Control is not responsible for any errors in this manual or their consequences. All rights reserved. SMC Ship Motion Control Ltd Email: info@shipmotion.eu Web: www.shipmotion.eu Tel: +46 8 644 5010 SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu...
-
Page 3: Table Of Contents
MAINTENANCE ........................11 SERVICE AND WARRANTY ..................... 11 3.1.1 Liability .......................... 11 3.1.2 Restriction of warranty ....................12 ........................13 ECHNICAL SUPPORT TECHNICAL SPECIFICATIONS SMC-1310 ................. 14 FAQ AND SUPPORT ....................... 15 SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu... -
Page 4: Introduction
1 INTRODUCTION The SMC-1310 Panel Display is a reliable and cost effective way to process, log and display data from Motion Reference Units and/or Weather sensors. The SMC-1310 can receive data on multiple serial RS232, RS422, RS485 ports and over ethernet. The panel display accepts data in NMEA formats and many proprietary formats. -
Page 5: Smc-1310 Dimensions
1.2 SMC-1310 DIMENSIONS All dimensions are in mm SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu... -
Page 6: Installation
The Panel PC should not be mounted outside. 1.3.1 INSTALLATION LOCATION RECOMMENDATION S Install the SMC-1310 Data Display in an area with free air flow. The SMC-1310 is a fanless device and the air need to be able to circulate through the ventilation holes in the case. -
Page 7: Electrical & Data Connection
Refer to the tables in the Connecting a device section below for the position of the power and data wire connections for each communication protocol operating mode, RS232, RS422 and RS485. SMC-1310 User Guide revision 1.1 SMC Ship Motion Control... -
Page 8: Operating Modes
1.5 OPERATING MODES The SMC-1310 has several serial operating modes. To access the menu, click on the SMC logo > System > UART > Quad UART RS-232/RS-485 Controller. Click on Edit to select the mode from the drop down menu shown below. -
Page 9: Serial Port Terminals
Signal GND VDC- VDC+ RS232 TxD RS232 RxD RS232 TxD RS232 RxD Position 9 … 16 COM3 COM3 COM4 Signal GND Signal GND VDC- VDC+ 485 Data+ 485 Data- RS232 Rx SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu... -
Page 10: Data Output Formats
12VDC. 1.6.1 DATA OUTPUT FORMATS The SMC-1310 supports data output over serial and ethernet TCP or UDP, Modbus, SNMP and TCP. The Serial and Ethernet string output can be formatted using predefined NMEA style data sentences as below examples. -
Page 11: Maintenance
In case of failure in the product the SMC-1310 User Guide revision 1.1 SMC Ship Motion Control... -
Page 12: Restriction Of Warranty
The sensor should not be opened as this could affect the warranty on the unit. All operations inside the sensor must be carried out by SMC personnel. SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu... -
Page 13: Technical Support
If the Sensor is under warranty, repairs are free. Pack the sensor in its original packaging, or suitable heavy packaging. Mark the RMA# on the outside of the package Return the Sensor, prepaid carrier to SMC SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu... -
Page 14: Technical Specifications Smc-1310
IP22 Electrical Power requirements 12 - 36 VDC Power consumption 20W Complies with the IEC 60945 Warranty & Support 2-year Limited Hardware & Software Warranty Free Technical & Hardware support SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu... -
Page 15: Faq And Support
Verify that there is a signal ground connected for RS232, if not the data would not be readable. Are the cables connected correctly, Note: RS422 uses a cross over Tx+ to Rx+, Tx- to Rx- etc. Check the wiring continuity through to the sensor. SMC-1310 User Guide revision 1.1 SMC Ship Motion Control www.shipmotion.eu...
