REVEX
3PH from 120A to 210A
16

Internal Fuse

The thyristor unit have internal fuse extrarapid at low I²t for the thyristor protection of against the short-circuits.
The Fuses must have I²t 20% less than thyristor's I²t. The warranty of thyristor is null if no proper fuses are used.
Type Fuse Code
120 FU2055920.180
150 FU2055920.200
180 FU2055920.250
210 FU2055920.315
1.2
1.0
K
0.8
0.7
0.6
0.4
0.2
200 400
(Line voltage)
Caution: High speed fuses are used only for the thyristor protection and can not be used to
protect the installation.
Caution: The warranty of thyristor is null if no proper fuses are used. See tab.
Warning: When it is supply, the Thyristor unit is subject to dangerous voltage, don't open the
Fuse-holder module and don't touch the electric equipments.
All manuals and user guides at all-guides.com
Current
(A )
RMS
180
200
250
315
500
600 800
Vac
2
Fuse I t value
Vac Suggested A2s
(at 500V)*
660 14280
660 17500
660 30800
660 53900
*
2
I t are multiplied for K value in function of Vac at
500V K is equal to 0,7 (ex:20400 X 0,7 = 14280).
At 660Vsc K is equal to 1.
56
User's manual
2
Fuse I t value
Quantity for
Suggested A2s
each phase
(at 660V)
20400
25000
44000
77000
1
1
1
1
