No.
a
b
c
d
e
f
g
h
Steps:
(1)
Put tripod in the target position, center and level it roughly.
(2)
Place and lock the tribrach in the tripod.
(3)
Insert the batteries into the receiver.
If work as a cellular base station, the SIM card need to be inserted before the batteries.
(4)
Screw the receiver onto the tribrach.
(5)
Center and level the receiver more precisely.
If work as a UHF base station, the UHF whip antenna need to be connected to the receiver.
(6)
Connect the receiver to external battery by using external power cable if necessary.
(7)
Connect the receiver to external storage disk by using USB cable if necessary.
(8)
Turn on the receiver by pressing the power button for 3 s.
(9)
Measure the antenna height by using H.I. tape and auxiliary H.I. tool.
(10)
Switch on the data controller and connect it to the receiver.
(11)
Use software to configure the receiver as cellular base or UHF base mode.

4.2.2 External UHF

For good performance, the following base station setup guidelines are recommended:
CHCNAV iBase GNSS USER GUIDE
Name
UHF whip antenna
iBase GNSS receiver
Extension pole (30 cm)
Tribrach adaptor
Tribrach w/ Opti
Aluminum tripod
Nino SIM card (12 mm x 9 mm)
Lithium battery
