Getting Started with iBase
battery fluid.

2.4 Inserting Battery and SIM Card

(1) Inserting battery:
(a) Push down the spring-loaded button on the battery cover to open the cover.
(b) Put the battery into the iBase slot, lock the battery as the picture shows like below.
Lock the battery
Push back
Battery cover
(c) Close the battery cover to prevent water immersion.
(d) To remove the battery, unlock the battery from the slot first.
(2) Inserting SIM card:
(a) Push down the spring-loaded button on the battery cover to open the cover.
(b) Insert the SIM card with the contacts facing downward, as indicated by the SIM card icon
on the battery slot.
