Front Panel Operation

3 Front Panel Operation
The front panel contains one LCD screen, two indicator LEDs, and two buttons. The operating
controls are all located on the front panel.

3.1 Main Operation Menus

The top-level menu of the front panel includes 6 parts: Status, mode, static and info. Status
shows satellites, receiver solution and the power percentage. Mode is the important part
which illustrate the work mode and users can select the mode according to their needs. Static
is used to set static mode. Info is the basic information of firmware such as SN, PN and etc.
The details of main operation are as follows and they are concluded two tables. The first table
includes 5 parts: Info, SV, Power, Data and Set and the second table displays details of Data.
Top-level Menu Second-level Menu Description
Indicate the total number of satellites
that have been tracked and the number
of satellites tracked of each
36=G07 R03.... constellation, where G represents GPS, R
represents GLONASSS, C represents
BeiDou, S represents SBAS and E
represents Galileo.
Indicates the remaining power of the
Status
Power battery inserted in the left (B) and right
(A) battery compartment.
WIFI ON/OFF Press Enter to turn on or turn off WIFI
Network status displays the if a sim card inserts the RTK
Back Press Enter to back to last page
