NEXSYS Series Compact PDU User Manual
TIP
NOTE
5. Install the power cord retainer (E) by pressing inward on its sides and hooking the ends
through the input post holes on the back of the unit as shown.
6. Use the power cord (F) to connect your Compact PDU from the AC input into an outlet on an
appropriately rated receptacle.
Use a rubber mallet to gently tap your PDU into the mounting clip, if
necessary.
Use a flat head screwdriver and wedge the tip between the side of
the mounting clip and against your PDU to carefully pry it free as
shown.
18
©2023 |
Legrand AV,
Mounting Your Compact PDU on Rackrail Brackets or 10"
Inc. All rights reserved.
Lever Lock Plates
