JX1 Pinout and Signal Map

Figure 6 shows the JX1 header pinout and
Pin Signal Name
JX1-1 N/C
JX1-2 3V3
JX1-3 RESET
JX1-4 3V3
JX1-5 5V
JX1-6 GND
JX1-7 GND
JX1-8 N/C
Broadcom
®
November 19, 2015 • WICED-UM200-R
Table 2

Figure 6: JX1 Pinout

Table 2: JX1 to Wi-Fi Module Signal Mapping

JX1
Arduino R3 UNO
Name
–
IOREF
RESET
3.3V
5V
GND
GND
VIN
shows the JX1 signal mapping to the Wi-Fi module.
Pin Name
– N/C
16, 26 VDD_3V3_SIP, VBAT_SIP
36 MICRO_RST_N
16, 26 VDD_3V3_SIP, VBAT_SIP
– 5V
1, 15, 17, GND
25, 27, 39,
GND
44, 45
N/C –
