Installation Instructions
Anti Vandal Pull Trim
Used with 8800 & 8900 Series and
PE8800 & PE8900 Series Exit Devices
For proper trim installation, prepare door with instructions and template(s) supplied with the exit device, and
template A7628 (Included with AVT trim).
824
04 Function with

latch protection

WARNING
This product can expose you to
lead which is known to the state of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to www.
P65warnings.ca.gov.
1-800-727-5477 • www.sargentlock.com
Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written
permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Latch Protection
827
10 Function with
latch protection
Latch Protection
826
04 Function without
latch protection
A5030-3 05/23
821
10 Function without
latch protection
WARNING
Attention Installer: Improper
installation may result in damage
to the product and void the factory
warranty.
