Summary of Contents for Hougen HMD2MT Series
- Page 1 HMD2MT SERIES PORTABLE MAGNETIC DRILL Covers Drill Covers Drill Part Numbers: Part Numbers: 0200102 OM2MT0118EF Printed in U.S.A.
- Page 2 HMD2MT MAG BASE DRILL Control Panel Assembly (see page 10)
- Page 3 HMD2MT Breakdowns 07985 Magnet Assembly Item Part # Description Item Part # Description 08700 Motor / Label Assy. 07982 Magnet / Winding Assembly 08723 Slide - Dovetail 04961 Plunger Assembly 08251 Control Panel Assy 10971 SCR SHC 1/4-20 x 1/2 08519 Gib, Brass, Right Hand 10972...
- Page 4 CONTROL PANEL BREAKDOWN & WIRING 08251 Panel Assembly 3 & 4 Item Part # Description 07011 Faceplate 2 & 5 01335 Switch - Motor Off 01334 Switch - Motor On 02409 Seal - Green 01228 Seal - Red 01226 Guard Switch 04614 Magnet Switch 02548...
- Page 5 COOLANT BOTTLE ASSEMBLY Attach Coolant Bottle 05060 Coolant Bottle Assembly Part # Description 05064 Coolant Bottle 05059 Coolant Botttle Bracket 41044 SCR-BHC 10-32 x 3/8 05065 Ball Valve 05067 Brass Barb Fitting (bottom of the bottle) 40304 Vinyl Tube 24124 Cap - Coolant Bottle Coolant Flow On / Off...
- Page 6 MOTOR PARTS DIAGRAM 08700 Motor Assembly Item Part # Description Item Part # Description 08234 SCR-SHC #10-32 x 1-5/8 08070 Washer - Spring Wave 50038 Washer - Lock Helical #10 08696 Armature Assembly 08721 Retaining Ring 08025 SCR-SHC #10-32 x 3-1/4 08719 Bearing 25 x 42 x 9 07958...
- Page 7 flammable liquids, gases or dust. Power tools Tool Use and Care create sparks which may ignite the dust or fumes. HOUGEN ACCESSORIES Use clamps or other practical way to secure and support Keep bystanders, children, and visitors away while operating a the work piece to a stable platform.
