Wall-mounted outlet:
To avoid adverse effects
At walls in buildings with staggered
heights.
On a wall - general. (*)
At <1 m from the roof overhang.
Beneath balconies, walkways etc.
Beneath balconies, walkways
etc. where the outlet extends to
the front.
To the garden or on the terrace.
With respect to a facing wall.
Enquire at your local gas company for the regulations relating to outlets
positioned opposite each other and outlet(s) in facade(s) that form an angle.
(*) These minimum distances do not apply if there is an obstruction
between the outlet and A, B and C that protrudes at least 0.5 m from
the wall and has a length exceeding the distance.
(**) This distance is not required if the outlet is situated at least 1 m
higher than the intended area of the outside space.
If the outlet has a clearance of less than 0.5 m from the hard surface of a public area at
a height of less than 2 m, it must be fi tted with an effective protector. The mesh size of
the guard must not affect the correct operation of the appliance.
12
Distance: outlet - A, B or C
Not permitted if A, B, or C are located
above the outlet.
Above the outlet:
Below the outlet:
Left and right of the outlet:
>2 m
>2 m from the underside of the
protruding balcony or walkway.
>2 m
>2 m to the outside space. (**)
>2 m (if the distance from the facing
wall is less, the criteria detailed for
"On a wall - general" apply).
English
>2 m
>0.75 m
>0.75 m
