SETUP & OPERATION MANUAL
FEATURES
Industrial rated quality and versatile design
allows for standard crosscuts, as well as bevels,
miters, and head swivels for rip cutting applica-
tions.
Powerful 3 HP 220V single phase (M1) or 4 HP
220V 3-phase (M2) motor.
Cast-iron frame, heavy steel column, and sturdy
easy to assemble all-steel stand for perfect
alignment and stability.
Precision adjustable indexing with positive stops
at 90º, 45º for accurate miter and rip cuts.
Blade guard with anti-kickback attachment and
splitter.
Magnetic switch with overload protection and a
lock-out key to prevent unauthorized use.
Automatic mechanical brake stops the blade in
seconds upon shutdown.
Dual 4" dust ports above the table, and a 2" dust
port on the rear of the blade guard.
Adjustable tension cutterhead / carriage return
spring to smoothly retract the motor and car-
riage back to the start position.
1" arbor included.
SPECIFICATIONS
• Blade diameter
16" (406 mm)
• Arbor diameter
1" (25 mm)
• Maximum depth of cut at 90°
4 7/8" (124 mm)
• Maximum depth of cut at 45°
2 1/2" (65 mm)
• Maximum crosscut capacity (with 16" blade)
24" (609 mm)
• Maximum rip capacity
38" (965 mm)
• Dado capacity
1" (25 mm)
• Table height
32" (813 mm)
• Table size
39 3/4" x 48" (1010 x 1220 mm)
• Overall dimensions (l x w x h)
56 5/8" x 48" x 67 7/16" (1439 x 1220 x 1713 mm)
• Motor M1
3 HP , 220 V, 12.5 A
• Motor M2
4 HP , 220 V, 3 ph, 10.5 A
• Weight (shipping / net)
799 lbs (363 kg) / 572 lbs (260 kg)
Version
2_Revision
1 - February 2016
#
#
© Copyright General International
16" RADIAL ARM SAW
MODEL
50-760 M1
#
