EMP-Centauri MS17/17+6ECP-4 Instruction Manual page 4

10) Wiring Examples
4x LNB
(QUATTRO)
TERR ANTENNA
PA12
MS17/17+10ECP-4
17x cable
MS17/17+10ECP-4
17x cable
MS17/17+10ECP-4
17x cable
MS17/10ECP-4
More wiring examples are shown at the manufacturer's website.
11) Contact
Manufacturer: EMP-Centauri s.r.o.
5. kvetna 690
339 01 Klatovy 4
Czech Republic
4x LNB
(QUATTRO)
TERR ANTENNA
MS17/17+6ECP-4
17x cable
MS17/17+6ECP-4
PA12
17x cable
A17/17EUC-4
17x Fm-Fm quick
MS17/17+6ECP-4
17x cable
MS17/17+6ECP-4
17x cable
MS17/17+6ECP-4
17x cable
MS17/17+6ECP-4
17x DC blocked
load 75Ω
tel: (+420) 376 323 813 (sales)
tel: (+420) 376 323 853 (tech. support)
info@emp-centauri.cz
www.emp-centauri.cz
4 of 4
4x LNB
(QUATTRO)
TERR ANTENNA
PA12
MS17/17+16ECP-12
17x cable
MS17/17+16ECP-12
17x cable
MS17/17+16ECP-12
17x DC blocked load 75Ω
