EMP-Centauri MS17/17+6ECP-4 Instruction Manual page 2

Specification
Current drawn
Dimensions (w,d,h)
Temperature Range
Notes: * average value
3) Product Takeover
Make sure that the product is not damaged. In the case of damage please contact your dealer.
4) Product Storing and Installation
We recommend the device to be installed and serviced by the qualified technician.
The product must not be stored and installed:
• in the place with excessive humidity
• in the place with dropping or splashing water,
•
in the place with excessive dust pollution, mechanical vibrations or impacts
• in the place out of temperature limits specified in the section 2) Technical Specifications
• close to heat sources (radiators or air ventilators, direct sunshine etc.)
• in the reach of children
Use the apparatus only in moderate climates (not in tropical climate).
Fix the product firmly on a wall or another hard and inflammable surface with screws and dowels. The
product shall be in no case held only by the connected cables.
Further instructions:
•
ensure the free space at least 10 cm around the product for the sufficient air circulation
• do not cover the product (with curtains etc.)
• do not place any containers with liquids (vases, glasses etc.) or naked flame sources (lighted
candle etc.) on the product or near the product
5) Product Connection
Connect the product in accordance with this manual and valid regulation in you country. Use high quality
75 Ω coaxial cable designed for satellite reception. The coaxial cables shall not be broken, the minimum
bending radius should be 5 cm. Mount the F connectors (screw, crimp or compress type) on the ends of
coaxial cables. Connect the F connectors into the F sockets of product and fasten them with an appropriate
force.
• Connect input F sockets marked "A" – "D", "TERR" with outputs of preceding device in the
cascade (LNB/antenna, amplifier, cascadable multiswitch)
• Connect output F sockets marked "A" – "D", "TERR" with inputs of following device in the cascade
(cascadable multiswitch, amplifier) or with 75 Ohm terminators (DC-blocked)
• Connect output F sockets marked "1", "2", "3"... with wall sockets or receivers or terminate them
with 75 ohm terminators*
• Connect connector marked with protective earth symbol with protective bonding conductor
• Connect DC2.1 socket marked "DC 12V" with power supply
* Termination is not required if terrestrial reception is not used.
MS17/17+ MS17/17+
6ECP-4 10ECP-4
100 mA (per user output)
18.6 x 14.6 x 5.1 cm
−25 – +60 °C
** according to EN 50083-3/35dB IMA3 (SAT), EN 50083-3/60dB IMA3 (TERR)
MS17/17+ MS17/17+
16ECP-12 20ECP-12
18.6 x 24.5 x 5.1 cm
2 of 4
MS17/17+ MS17/17+
26ECP-17 30ECP-17
18.6 x 33.2 x 5.1 cm
