EMP-Centauri MS17/17+6ECP-4 Instruction Manual page 3

6) Product Settings
The product has no adjustable options.
Each connected satellite receiver must be properly set up to have access to all connected LNBs. Follow
instruction manual for satellite receiver or TV set. The most common styles of setup are shown in the table:
SAT SYSTEM (LNB)
A
B
C
D
7) Safety
Due to security reasons the product and wiring in which the product is connected, must be grounded
properly. Use the terminal identified with the appropriate symbol to ground the product. Make sure the
antennas are properly protected against lightning.
The product should be disconnected from the wiring immediately if it gets into contact with liquids (dropping
water, spilled drinks etc.).
8) Product Maintenance
The maintenance operation is especially cleansing of the product. Use only dry cloth to clean the product
and do not use any liquid agents.
Coaxial cables installed outdoors should be replaced once in a few years. Unscrew all F connectors and
clean connector contacts, resp. shorten the coaxial cable by approx. 2 cm, every 2 years.
9) Symbols Explanation
Certificate of conformity
According to EU directive, electric and electronic devices which are identified by one of the
following symbols must not be disposed of together with municipal waste. When disposing
of the old device, use local waste collection and separation systems.
Setting style 1
DiSEqC 1.0: 1 of 4
DiSEqC 1.0: 2 of 4
DiSEqC 1.0: 3 of 4
DiSEqC 1.0: 4 of 4
Setting style 2
DiSEqC 1.0: A
DiSEqC 1.0: B
DiSEqC 1.0: C
DiSEqC 1.0: D
Protective earth
3 of 4
Setting style 3
committed: AA
committed: AB
committed: BA
committed: BB
