Degelman PRO-TILL 33/40 Quick Start Manual

QUICK-START GUIDE
PRO-TILL 33/40
for
* Refer to operators manual for complete safety and operation info.
A
Connect Hydraulics
2
1
Maintenance
(Check Machine Daily)
Grease Points
• Front Frame / Rockshaft Pins
• Wing Frame Pins
• Cylinder Pins
• Wing Transport Roller Pins
• Hubs & Spindles
• Working points & pins
* Refer to operators manual for complete safety and operation info.
*
1
2
3
4
5
IMPORTANT: Models with Wing Pressure Kit
The Wing Cylinder Circuit includes a
Down Pressure Valve. Operator must
engage wing circuit hydraulics
constantly in the extended direction
to ensure constant down pressure.
-OR-
4
2
1
3
GPS Reference
(Set overlap to 6" per side)
(with 20" discs) 2" Depth
Pro-Till 33 390" (9.9m)
Pro-Till 40 470" (11.9m)
Pro-Till 40 CT 491" (12.4m)
(with 20" discs) MAX Depth
Pro-Till 33 393" (10m)
Pro-Till 40 473" (12m)
Pro-Till 40 CT 493" (12.5m)
(Consider setting the GPS to include
a 6" implement offset to the right)
WARRANTY
REMEMBER! You must complete Product
Registration to be eligible for Warranty.
WHEELS
ROLLERS
TRANSPORT
WINGS
JACK
4
-OR-
2
1
3
5
Standard Models with
Configuration Wing
Models Pressure Kit
FLOAT FLOAT CONSTANT
PRESSURE
-OR-
4
3
2
1
2
4
1
143349 v1.4
5
(if available)
