Clearances; Flue/Chimney Location - Main Eco Compact System 15 Installation And Service Manual

Fig.16 Flue outlets
Tab.18 Terminal position with minimum distance
Key Description
Directly below an opening, air brick open­
A
(1)
ing window etc.
B Above an opening, air brick, opening win­
(1)
dow etc.
Horizontally to an opening, air brick,
C
(1)
opening window etc.
The fitting of a "Trace Heating" Element is NOT a substitute for correct
installation of the condensate drain. ALL requirements in this section must
still be adhered to.
5.3.5
A flat vertical area is required for the installation of the boiler and it should
be capable of bearing the weight of the boiler when full of water.
These dimensions include the necessary clearances around the boiler for
case removal, spanner access and air movement. Additional clearances
may be required for the passage of pipes around local obstructions such
as joists running parallel to the front face of the boiler.
In the diagram these are MINIMUM recommended dimensions. Greater
clearance will aid installation and maintenance.
5.3.6
The following guidelines indicate the general requirements for siting
balanced flue terminals. For GB recommendations are given in BS 5440
Pt 1. For IE recommendations are given in the current edition of I.S. 813
Domestic Gas Installations.
J,K
T
N
R
M
I
I
F
L
1
1

Clearances

Flue/chimney location

Important
Due to the nature of the boiler a plume of water vapour will be
discharged from the flue. This should be taken into account when
siting the flue terminal.
U
D A
E
C
I
S
B
F
A
A
G
H
H
I
Flue positions marked
mm Key Description
300 J From a surface or boundary line facing
a terminal
300 K From a terminal facing a terminal
(Horizontal flue)
From a terminal facing a terminal (Ver­
tical flue)
300 L From an opening in carport (e.g. door,
window) into the dwelling
I
J,K
require a flue terminal guard.
5 Before installation
PN-0000456
mm
600
1200
600
1200
