Main Eco Compact System 15 Installation And Service Manual page 37

Fig.31 Flue dimension Y
2
Y
1
Fig.32 Attaching the flue
4
A
1
B
2
5. To dimension " X" add 40mm. This dimension to be known as "Y" .
1
4
6. Adjust the two telescopic sections to dimension "Y" and seal the joint
3
7. Using the clearance holes in the connection assembly secure it to the
PN-0000464
8. Remove the flue elbow and insert the flue through the hole in the wall.
C
4
3
5
9. Draw the flue back through the wall and engage it in the elbow. It may
10. Ensure that the terminal is positioned with the slots to the bottom.
PN-0000465
11. Make good between the wall and air duct outside the building,
12. If necessary fit a terminal guard.
1 TOP label
2 Sealing tape
3 Securing screw
4 Peak to be uppermost
with the tape provided. Ensure that the labels marked "TOP" on the
terminal and connection assemblies are uppermost.
terminal assembly using the screws supplied with the telescopic flue.
Fit the flue trims if required, and refit the elbow to the boiler adaptor,
ensuring that it is pushed fully in. Secure the elbow with the screws
supplied in the boiler fitting kit.
1 Flue elbow
2 Boiler adaptor
3 Telescopic flue
4 Flue trim
5 Securing screw
A Apply the lubricant supplied for ease of assembly (do not use
any other type). Ensure flue is fully engaged into elbow.
B Apply the lubricant supplied for ease of assembly (do not use
any other type). Ensure elbow is fully engaged into boiler
adaptor.
C Peak to be uppermost
be necessary to lubricate to ease assembly of the elbow and flue.
Secure to the elbow with the screws supplied with the telescopic flue.
Important
It is essential that the flue terminal is fitted as shown to ensure
correct boiler operation and prevent water entering the flue.
appropriate to the wall construction and fire rating.
Important
There must be no part of the air duct (white tube) visible outside
the property.
6 Installation
