- Page 1 System HE User’s Guide and Range Important Warranty Information Please keep these instructions in a safe place. If you move house, please hand them over to the next occupier. © Baxi Heating UK Ltd 2007...
-
Page 2: Table Of Contents
Contents Section Page Natural Gas Quick Reference Guide Main System 18 HE G.C.N 41 467 01 Troubleshooting Main System 24 HE G.C.N 41 467 02 Main System 28 HE Fault Indication G.C.N 41 467 03 Repressurising System Clearances Care of the Boiler... -
Page 3: Quick Reference Guide
1.0 Quick Reference Guide 30° 40° 50° 60° 70° 80° Reset ON/OFF/Reset Indicator Central Heating System Pressure Gauge Selector Switch Neons Temperature Control Reset Reset Reset OFF Position Central Heating & Hot Water Reset The boiler will not operate. Both Heating & Hot Water will operate. Hold for approx 5 seconds and release. -
Page 4: Troubleshooting
Boiler not working 2.0 Troubleshooting START Make sure the gas supply is Is the ( ) light on and the Is the ON/OFF/Reset turned ON and check if other ) on ? Select Switch in the gas appliances are operating ) position and (e.g. - Page 5 2.0 Troubleshooting Is the Timer ON and calling for Is the Room Thermostat (if heat ? fitted) set high enough ? Typical examples of external timer CH ON CH OFF Turn Room Thermostat to maximum setting (typical example shown). Ensure timer is set for Central Heating ON (see any instructions supplied with timer).
-
Page 6: Fault Indication
1 minute in every 24 hours to prevent sticking. Reset Safety Thermostat 1. Your Main System HE is fitted with an additional safety devices, which shut down the boiler in the event of the Fig. 2 system, boiler or flue overheating. The safety thermostat neon ( ) will light in this instance (Fig. -
Page 7: Repressurising System
4.0 Repressurising System Central Heating System Pressure 1. The normal operating water pressure is between 1 and 2.5 bar (Fig. 4). If the pressure exceeds 3 bar the safety pressure valve will operate and a fault is indicated (Fig. 6). Contact your installer. Fig. -
Page 8: Clearances
5.0 Clearances 20mm/5mm Min For your Safety see *NOTE: 5mm Min 450mm 1. This appliance must have been installed in accordance with the manufacturer’s instructions and the regulations in force. 200mm Min 2. Any modification that may interfere with the normal operation of the appliance without express written permission from the manufacturer or his agent could invalidate the appliance warranty. -
Page 9: Care Of The Boiler
6.0 Care of the Boiler Cleaning the Outer case The painted panels should be wiped with a damp cloth and then dried completely. DO NOT USE ABRASIVE CLEANING AGENTS. Protection & Precaution 1. The boiler incorporates an integral frost protection feature that will operate when the selector switch is in the ( position. -
Page 10: Legislation
7.0 Legislation Installation, Commissioning, Service & Repair 1. This appliance must be install in accordance with the manufacturer’s instructions and the regulations in force. Read the instructions fully before installing or using the appliance. 2. In GB, this must be carried out by a competent person as stated in the Gas Safety (Installation &... -
Page 11: Emergency
8.0 Emergency Warning ! If you smell gas Turn off the gas supply at the meter and call your gas supplier immediately. It is possible to isolate the boiler at the isolating valve (Fig. 9). In GB, Transco operate a 24 hour emergency service and the telephone number will be listed in your telephone directory. -
Page 12: Warranty & Service
Please complete the boxes below 9.0 Warranty & Service Serial Number Standard Warranty Term & Conditions 12 Months Free Warranty - register today To receive your 12 months free warranty please complete the form supplied with the boiler or simply call heateam, the service of Baxi Heating UK Ltd on 08706 000 653.
