VDBS100 Deep Standard Base
BLR100 Vega Relay Base
VBS100 Detector Sounder Base
B.3 Wireless devices
Model Name
SGW2W Wire to Wireless
Translator
SG100 Wireless Analogue
smoke detector
SG200 Wireless Analogue
Multicriteria detector
SG350 Wireless Analogue
thermal detector
SGMI100 Wireless Input Module
SGMC100 Wireless Output module
SGCP100 Wireless Call Point
SGRS100 Wireless Sounder
a. Configured as "Rate-of-rise detector
ture exceeds the 54°C alarm threshold).
and fixed temperature set at 70°C)
automatically.
B.4 Device Consumption
B.4.1 Detectors
In standby: 90 uA
In alarm: 6 mA
B.4.2 Modules
In standby: 120 uA
In alarm: 6mA
B.5 Notes on Loop wiring
Use suitably sized twisted shielded cable for the loop wiring. Connect the shield to earth using
terminal 3 or 6, connect it to one end of the loop only.
In order to allow the loop to function properly, you must section the device connection cable in such
way that any voltage drop along does not exceed 8 V. The following table shows the minimum
dimensions for the loop wiring with regard the distance between the Loop-O terminals and the most
distant device:
52
Deep Standard Base
Relay Base
Base with Sounder
Description
Wireless Analogue smoke
detector
Wireless Optical/Heat
detector
Wireless Analogue thermal
detector
Wireless Input Module
Wireless Output module
Wireless Call Point
Wireless Sounder
" at default ( alarm is triggered by rapid rise in temperature or when the tempera-
To configure as "High temperature detector" (
use the VPU100 programmer.
up to 500 m
up to 1000 m
up to 1500 m
up to 2000 m
Allows connection to wall-mount cable runs
Relay activated by the detector R output attached
to the base
Activated by the detector R output attached to the
base
Connected to Loop, 32-device interface (Sagittarius
series - SG) wireless to panel
The panel sees the 32 devices as if they were
connected to the Loop (with different addresses)
Used only with SGW2W.
a
( )
The panel will recognize the configuration criteria
2
min. 1 mm
2
min. 1.5 mm
2
min. 2 mm
2
min 2.5 mm
Argus devices supported by the control panel
Installation Manual
Note
Rate-of-rise feature bypassed
