Installing The Child Seat In The Box - Cube TRIKE HYBRID Operator's Manual

39 TRIKE HYBRID
4.
Close the soft top ⮫
soft top" on page 37 .
7.9.4 Installing the child seat in the
box
WARNING
Risk of injury if the child seat is not
correctly installed.
If the child seat is not correctly installed in the box or
properly locked, children can be injured during trans‐
port.
■
Only use the child seat when it is properly installed
and correctly locked.
■
Do not use the child seat if it does not lock cor‐
rectly. In this case, contact your specialist bicycle
dealer.
NOTICE
The child seat has recessed grips on
the front and back.
1.
Pull the latches on the side rails forward to open
the latches.
Fig. 31: Bolt on rail pulled forward, lock opened
2.
Insert the child seat at first in to the back of the
box
Chapter 7.9.2 "Closing the The hooks on the two rails must engage with the
corresponding eyelets in the box.
Fig. 32: Eyelets for child seat in box
3.
Press down the front part of the child seat with
a little pressure so that it audibly engages 2x on
both sides.
2x Click
Fig. 33: Press child seat into locking position
NOTICE
The child seat has two locking stages
at the front. The first engagement
only indicates the first, lighter locking
stage. The child seat is not fully
locked in the box until it has engaged
2x on both sides at the front.
2x Click
