teko Astra-517 ver.P User Manual

«Astra-517 ver. Р»
Optic-Electronic PIR Motion
Detector
(Volumetric Lens)
User Guide
Manufacturer:
ZAO NTC TEKO
420108, Kazan, Russia
Gafuri 71
+7(843) 528-03-69
export@teko.biz
teko.biz
Made in Russia
Rev. 517p-v1_4_instr_en
1 FUNCTION
Detector is intended to detect unauthorized
access into enclosed protected area and to
generate alarm notification
signaling relay contacts.
The detector is resistant to the movement of
pets weighing up to 20 kg.
2 DETECTION ZONE
Side view
2,4m
3m
Top view
5m
5m
3 DELIVERY SET
Delivery set includes: dowel – 2 pcs., screw – 2
pcs., label – 2 pcs., user guide – 1 pcs.
4 SPECIFICATION
Range of detectable
moving speed, m/sec ................. from 0.3 to 3.0
Power supply voltage, V
by opening of
Current consumption, mA, max
Overall dimensions, mm .................70 × 51 × 41
Operation conditions
Temperature range,
Relative air
5 NOTIFICATION
Notification
9m 10m
Boot mode
Normal
Alarm
10m
Failure
Tampering
« » – relay closed,
« » – relay open,
«ТМP
................. from 8 to 15
..................... 15
°С............ from - 30 to + 50
humidity, % ......... up to 98 at + 25 °С
Without moisture condensation
LED Relay (TMP)
Flashes 1 time per
1 second after
turning on the pow- 60 sec
er. Duration 60 sec
Off
Lights up 1 time
for 2.5 sec when
detecting a human
2,5 sec
movement in the
detection zone
On until failure
elimination
ТМР
Off
» –Tamper circuit open
for
for
