Friendess FSCUT6000 User Manual page 14

HPL2720E
Module Qty
Power /
Suppl
y
PWM 1
DA 4
Common
20
Outpu
t
24V level, active low (<15.6V); IN1~IN3 can be
Common 27
Input
Working
Environment
Dimension
Weight
FSCUT6000 User Manual
Description
24V DC/5A
24V, ±50kHz 0.3%
0-10V, 12bit, ±20mV
High level 24V output, ≤ 0.7A per channel
The total current output ≤ 2.5A
switched to active high (>5.8V)
Temperature: 0~60℃
Humidity: 10%~90% (no condensation)
195×118×45.2mm
Table 2-4 HPL2720E Hardware Resources
480g
14
Note
Max 50kHz,3%
External relay
recommended
