Wiring the 2706-P42C2-SC and 2706-P44C2-SC Displays

WARNING
Hazardous voltage.
Contact with high voltage may cause death or serious injury.
Always disconnect power to the InView display prior to servicing.
Maintain separation of circuits. Route the incoming power directly to the
power connections terminal block.
Do not run the power wiring over the logic board.
WARNING
Tension dangereuse.
Toucher un câble a haute tension peut provoquer la mort ou des
blessures graves.
Sortir la prise d'alimentation de l'afficheur avant de le réparer.
Maintenir la séparation des câbles.
Brancher le câble d'alimentation directement au bornier d'alimentation
électrique.
Ne pas faire cheminer le câble d'alimentation le long de la carte
NOTE
Wiring method must be in accordance with:
•
In the United States, the National Electrical Code, NFPA 70, and the National Fire
Alarm and signaling Code, NFPA 72.
•
In Canada, CSA C22.1, Canadian Electrical Code, Part I, Safety Standard for
Electrical Installations, Section 32.
NOTE
Spectrum Controls, Inc. Publication 0100290-01A
Installing InView Marquee 2706-P4xC2-SC Message Displays
Wiring instructions apply to both displays unless indicated.
Wiring Power to the Display
Use appropriate conduit fittings and connections to route wires for
power and communication into the power access compartment.
Ensure a provided ferrite is properly installed on the cables as
shown in the supplied photos.
PN: 1778600501
