Installing InView Marquee 2706-P4xC2-SC Message Displays
NOTE
NOTE
Terminal connection points for communication types are listed below.
PN: 1778600501
Only connect one type of communication type to the display at a
time.
1.
Connect the incoming communication wire(s) to the appropriate
terminals or connection point within the Rear Access Panel
Communications terminal compartment. Terminal connection points are
shown below:
Pin
1
2
3
4
6
7
8
9
10
Only connect one type of communication type to the display at a time.
Spectrum Controls, Inc. Publication 0100267-01B
Description
EGROUND
SHIELD
RS485-(A)
RS485-(B)
5VDC
GROUND
RS232TXD
RS232RXD
GROUND
