Installing InView Marquee 2706-P4xC2-SC Message Displays
WARNING
WARNING
NOTE
PN: 1778600501
2. Mount the cable grip to the InView display housing, tighten the
locknut finger-tight, and rotate an additional 1/2 turn.
Hazard of damage to electronic equipment.
Failure to ensure that jumper J2 is in the correct position for the
voltage supplied to the InView Comms module can result in
damage to the module circuitry.
Before applying power to the InView Comms Module, check that the
jumper is in the correct position for your application.
Danger de dommage pour l'équipement
S'assurez que le cavalier J2 est dans la position correcte pour la
tension fournie au module de communication InView sinon cela
pourrait entrainer des dommages a l'ensemble des circuits du
module.
InView en tension, vérifiez que le cavalier est dans la position de
voltage adequat pour votre application.
The 2706-PENETM2C2-SC communication modules are provided
with cable PN 6010104-nn, (3 meters long). The cable combines
power and serial communications. Power for the communications
module comes from display terminals #6 and #7. Serial
communications are via RS-232 from the module to the display
using terminals #8 and #9.
3. Tighten the cable grip cap until the cable is securely fastened.
4. Replace the rear panel power cover with the 4 screws and tighten
the screws to 2.7 N-m (24 in-lbs).
5. Connect the power supply to a power source.
6. If you press the reset button in the module, the module restarts,
initializes, and displays the Communications Module's MAC
address, its Ethernet IP address, and its Gateway IP addresses as
part of the associated InView display.
7. Write down the values. Example: 192.168.1.100
8. Connect your PC to the other end of the Ethernet network cable
installed in ETH1 on the Comms module and start an Internet
browser.
9. In the Address field, type in the IP address you obtained from the
display to which the Comms Module is connected.
10. Example entry only. Your value will be different: 192.168.1.100
11. The InView User Interface starts up. If you do not have Adobe
Flash Player installed on your computer, the software provides a
link for you to access, download, and install the Flash Player.
Follow Adobe's instructions to install the Flash Player.
Spectrum Controls, Inc. Publication 0100267-01B
électronique.
