4
•
Where power and series communications wires must cross, the intersection should be
perpendicular.
•
Shield all serial communication wires. Connect the shield to ground at only one point.
NOTE
Description of the 2706-P42C2-SC and 2706-P44C2-SC Displays
InView 2706-P42C2-SC Display:
InView 2706-P44C2-SC Display:
InView 2706-P42C2-SC and 2706-P44C2-SC displays both provide 1200 NITs brightness level.
Power consumption is also much lower than the previous models of 2706-P4xC InView displays.
The resolution for both displays is 7.6 mm (0.3 in). The displays provide 10, user-selectable colors
for fonts and bitmaps. You may scroll images and characters from right-to-left, or left-to-right,
depending on the language. The displays comply with NEMA 12 housing standards.
Spectrum Controls, Inc. Publication 0100290-01A
Installing InView Marquee 2706-P4xC2-SC Message Displays
You can configure your InView Communications module or
Messaging software without having an InView display connected.
