Hardware to attach the sign to the ceiling varies based on the type of material (concrete, brick,
wood) and is not included.
Installers must use the following guidelines:
•
The hardware for attaching to the mounting surface must be rated for the mounting
surface.
•
Hardware for attaching to the mounting surface, including hanging chains, must be
capable of supporting the weight of the sign.
•
The display cannot be installed directly to drywall, plasterboard, or any other fragile
supports.
•
The ceiling, or the ceiling-mounted support system must be capable of supporting at least
four times the weight of the sign.
1. Attach the ceiling mounting brackets (A) to the sign using the 4 6-32×3/8-inch Phillips screws
(B) as shown. Tighten to 1.3 N-m (10 in-lbs).
NOTE
Spectrum Controls, Inc. Publication 0100290-01A
Installing InView Marquee 2706-P4xC2-SC Message Displays
Use chains capable of supporting 4 times the total weight of the
signs.
