Installing InView Marquee 2706-P4xC2-SC Message Displays
NOTE
Sign installation must be performed by qualified personnel. Ceiling mounting brackets and fasteners
are provided with the display. These brackets allow the customer to hang the sign with the
appropriate braided wire or chain or rope, etc. Hardware to fasten the display to the wall or ceiling is
not provided as the appropriate fasteners must be used for brick, stone, or wood etc.
NOTE
The maximum weight of the displays is 5.17 kg (11.40 lbs) for the 2706-P42C2-SC, and 9.66 kg
(21.30 lbs) for the 2706-P44C2-SC. This is the weight of the displays only, without the attached
2706-PENETM2C2-SC Comms Module. The module, with its attached bracket adds 1.32 kg (2.6
lbs) to the weight of the display.
WARNING
•
A indicates bracket(s).
•
B indicates bracket screws.
PN: 1778600501
Keep a minimum 2.54 cm (1.0 in) clearance on all sides of the sign
for adequate ventilation.
Mounting Displays on a Ceiling
If you use the equipment in a manner not specified by Spectrum
Controls, Inc., this may impair the protection provided by the
equipment.
The factory-applied finish must not be altered or changed.
Mount the sign so that it is easy to disconnect power when
servicing.
Always disconnect the communications cable(s) before
disconnecting power.
Modifying the sign housing voids the warranty.
HAZARD of injury to personnel or damage to equipment.
Be sure to place the ceiling brackets so the ceiling bracket flanges face
appropriately as shown below.
Failure to place the ceiling brackets correctly will result in the sign
failing to stay in place when hung from its chains.
