Operating Instructions
HT11K Hand Tool MCON050, 0.13 – 0.35 mm²
Customer Manual No.:
Customer Manual PN:
Language:
411-18539-1 Rev.B
6-744015-4
EN (translation of the German original version)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT11K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TE Connectivity HT11K

Summary of Contents for TE Connectivity HT11K

  • Page 1 Operating Instructions HT11K Hand Tool MCON050, 0.13 – 0.35 mm² Customer Manual No.: 411-18539-1 Rev.B Customer Manual PN: 6-744015-4 Language: EN (translation of the German original version)
  • Page 2 HT11K Hand Tool MCON050, 0.13 – 0.35 mm² Contents Revision history....................... 3 Introduction ......................3 About these operating instructions ......................3 Intended use ............................3 Description ....................... 4 Operation ......................... 4 Crimping terminals ..........................4 Customer Service, EMEA Service Hotline ............. 7 Maintenance and servicing ..................
  • Page 3 Introduction About these operating instructions These operating instructions describe the use and operation of the HT11K hand tool and the necessary maintenance measures. All persons using the hand tool must therefore be familiar with these operating instructions and follow them. It should be stressed that the operating in- structions for the HT11K hand tool are essential.
  • Page 4 HT11K Hand Tool MCON050, 0.13 – 0.35 mm² Description The hand tool essentially consists of a crimping head, two moveable handles, a ratchet mecha- nism, a sliding crimping die, a die latch, a hinged terminal holder and a hinged wire stop. The sliding crimping die contains six marked crimping nests.
  • Page 5 HT11K Hand Tool MCON050, 0.13 – 0.35 mm² NOTE The locking mechanism of the hand tool has a ratchet that makes audible clicks when you close the handles. When you hear the last click, the locking mechanism releases and the hand tool can be opened again. For an emergency release, the lever of the un- locking mechanism must be operated.
  • Page 6 HT11K Hand Tool MCON050, 0.13 – 0.35 mm² Carefully close the hinged terminal holder. Feed the wire, insulated according to the processing specification, into the terminal until it reaches the wire stop. Hold the wire against the wire stop and press the handles together until the locking mecha- nism opens again.
  • Page 7 HT11K Hand Tool MCON050, 0.13 – 0.35 mm² Customer Service, EMEA Service Hotline Please contact us for service enquiries or technical support: Monday - Thursday 8am - 4pm Friday 8am - 2pm Tel. +49 (0) 6151 607 -1518 TEFE1@TE.COM (EMEA Customer Support) TEFE2@TE.COM...
