Gas-fired boilers
DTG 230 S
User Guide
300011506-02

Advertisement

Table of Contents
loading

Related Manuals for DeDietrich DTG 230 S

Summary of Contents for DeDietrich DTG 230 S

  • Page 1 Gas-fired boilers DTG 230 S User Guide 300011506-02...

  • Page 2: Table Of Contents

    Contents Introduction ................3 Symbols used .

  • Page 3: Introduction

    1. Introduction 1 Introduction 1.1 Symbols used Caution danger Reference Risk of injury and damage to equipment. Attention must be Refer to another manual or other pages in this instruction paid to the warnings on safety of persons and equipment. manual.

  • Page 4: Safety Instructions And Recommendations

    2. Safety instructions and recommendations 2 Safety instructions and recommendations 2.1 Safety instructions Fire hazard Risk of being burnt Do not stock products of an inflammable nature close to Avoid direct contact with the flame viewport. the appliance. Depending on the settings of the appliance: If you smell gas, do not use a naked flame, do not smoke, - The temperature of the flue gas conduits may exceed 60°C do not operate electrical contacts or switches (doorbell,...

  • Page 5: Description

    3. Description 3 Description 3.1 Main parts 7 to 13 sections 14 sections 1. Control panel 2. Factory fitted bridge Connection for gas pressure switch (Option - Package GC191) Natural gas: 12.5 mbar Propane: 20 mbar 3. a: Gas valve - Stage 1 b: Gas valve - Stage 2 4.

  • Page 6: Control Panel

    3. Description 3.2 Control panel 3.2.1 B3 control panel When preparing domestic hot water 1. General ON (1) / OFF (0) switch 2. Burner alarm indicator + Reset button 12. Electronic thermostat (10 to 80 °C) This light comes on when the safety control box is in safety 13.

  • Page 7: Diematic-M3 Control Panel

    3. Description 3.2.2 DIEMATIC-m3 control panel Electromechanical components 1. General ON (1) / OFF (0) switch 6. Pump shutdown switch 2. Burner alarm indicator + Reset button 7. Boiler thermostat (30 to 90 °C) This light comes on when the safety control box is in safety 8.

  • Page 8: K3 Control Panel

    3. Description 3.2.3 K3 control panel 1. General ON (1) / OFF (0) switch 3. Switch AUTO/ /TEST-STB AUTO: This position enables automatic operation of the 2. Burner alarm indicator + Reset button installation in accordance with DIEMATIC-m 3 regulation This light comes on when the safety control box is in safety controls.

  • Page 9: Diematic-M3 Control Panel

    3. Description 4.2.2 DIEMATIC-m3 control panel Keys accessible when the flap is closed Keys accessible when the flap is open Adjustment keys MODE Various operating modes can be selected by successively Adjustment keys pressing key MODE: AUTOMATIQUE Enter (per 1/2 hour) the comfort temperature period or tank load enabled (dark area).

  • Page 10: Switching Off The Boiler

    3. Description 4.3 Switching off the boiler Set the On/Off switch to 0. - to ensure Titan Active System® operation when a titanium anode is protecting the DHW tank. DIEMATIC-m3 control panel Use the mode: The panel must always be supplied with 230V voltage: - summer to shut down the heating.

  • Page 11: Troubleshooting

    6. Troubleshooting 6 Troubleshooting 6.1 Type plate Before informing the fitter of a fault, make a note of the following information: Type of gas used Boiler type XX-XX Manufacturing date Year (01 = 2001, 02 = 2002, ...) Week Serial no. of the appliance This information can be found on the rating plate stuck to the front plate of the boiler.

  • Page 12: Diematic-M3 Control Panel

    6. Troubleshooting 6.2.2 DIEMATIC-m3 control panel Message Probable causes Action The message SHOW REM.CTRL indicates the To cancel the overrides on all remote controls, press the AUTO key for 5 SHOW REM.CTRL presence of an override on a remote control. seconds.

  • Page 13: Incidents And Solutions

    6. Troubleshooting 6.3 Incidents and solutions The burner is not working: - The safety control box is malfunctioning (Fault indicator light illuminated) - Check the boiler thermostat settings. - Shutdown by the safety thermostat due to accidental overheating Press the resetting button of the burner. Call your fitter. The burner is operating but the radiators are cold: Check that the safety thermostat has not triggered.

  • Page 14: Technical Specifications

    7. Technical specifications 7 Technical specifications DTG 230-...S Stage 1 Useful output Stage 2 (1) (2) °C Smoke temperature Minimum output temperature °C Maximum output temperature °C Maximum operating pressure 6 (0,6) 6 (0,6) 6 (0,6) 6 (0,6) 6 (0,6) 6 (0,6) 6 (0,6) 6 (0,6)
  • Page 15 7. Technical specifications Warranty You have just purchased one of our appliances and we thank you Italy for the trust you have placed in our products. Please note that your The duration of our warranty is shown on the certificate delivered appliance will provide good service for a longer period of time if it is with the appliance.
