Page 1: User Guide
SOLNEO Gas fired condensing boiler SGC 24 SOL User Guide 300017555-001-C... -
Page 2: Table Of Contents
Contents Introduction ................3 Symbols and abbreviations . -
Page 3: Introduction
In so doing, Risk of injury and damage to equipment. De Dietrich Thermique S.A.S. wishes to safeguard the user's safety, Attention must be paid to the warnings on safety of obviate hazards and guarantee correct operation of the boiler. -
Page 4: Certifications
1. Introduction 1.3 Certifications CE identification no CE-0085BQ0052 Type of connection Chimney: B Forced flue: C 13(x) 33(x) 43(x) 63(x) * 83(x) 93(x) Ignition Automatic * Except Belgium and France (x) For Germany only SGC 24 SOL 15/10/2009 - 300017555-001-C... -
Page 5: Safety Instructions And Recommendations
2. Safety instructions and recommendations 2 Safety instructions and recommendations 2.1 Safety instructions 2.1.1 Fire hazard DANGER DANGER If you smell flue gases: If you smell gas: 1. Switch the appliance off 1. Do not use a bare flame, do not smoke, do not actuate electrical contacts or switches ( doorbell, light, motor, lift, etc..). -
Page 6: Description
3. Description 3 Description 3.1 General description The SGC 24 SOL solar column is a multi-energy unit which includes The boiler is preset in the factory to operate on natural gases H and a gas-fired condensing boiler and a 200-litre solar domestic hot water E (Operating pressure: 20 mbar). -
Page 7: Parameter Display - Diemasol A Solar Regulator
3. Description Position Key Description 6-position switch : Shutdown/antifreeze/vent. : Domestic hot water (Summer). : Heating and domestic hot water (Winter). : Measurement mode (Key to access the parameters reserved for the installer). : Fitter mode (Key to access the parameters reserved for the installer). : Sweeping mode (Key to access the parameters reserved for the installer). -
Page 8: Operating Instructions
4. Operating instructions 4 Operating instructions 4.1 Start the boiler Check the water pressure in the installation several times a year. If necessary, top up the boiler with water. The water pressure in the installation must be between 1.5 and 2 bar. -
Page 9: Changing The Settings
4. Operating instructions 4.3 Changing the settings 4.3.1 Selecting the operating mode Set the 6-position switch T to the desired operating mode. : Shutdown/antifreeze/vent. : Domestic hot water (Summer). : Heating and domestic hot water (Winter). 4.3.2 Changing the heating temperature Set the temperature of the heating water using button V. -
Page 10: Prolonged Absence
4. Operating instructions 4.5 Prolonged absence 4.5.1 Switching off the appliance If the central heating system is not used for a long period, we 2. Cut the power supply to the boiler. recommend switching the boiler off. 3. Close the gas valve. 1. -
Page 11: Checking And Maintenance
5. Checking and maintenance 5 Checking and maintenance 5.1 General instructions An annual inspection is compulsory. Maintenance operations must be done by a qualified professional. We recommend that you take out a maintenance contract. Only original spare parts must be used. 5.2 Periodic checks Regularly check the water pressure in the installation (minimum pressure 0.8 bar, recommended pressure between 1.5 and 2... -
Page 12: Bleeding The Heating System
5. Checking and maintenance 5.4 Bleeding the heating system It is essential that you vent any air in the appliance, the ducts or the 6. Bleed the radiators. valves to prevent the noise annoyance likely to be produced during Start with the lower floors. heating or water draw-off. -
Page 13: Draining The Installation
5. Checking and maintenance 5.5 Draining the installation It may become necessary to empty the water from the heating system when the radiators have to be replaced, should there be a major water leak or a risk of frost. To do this, proceed as follows 1. -
Page 14: Troubleshooting
6. Troubleshooting 6 Troubleshooting 6.1 Breakdown codes In the event of a fault, the display indicates an alarm message by alternately showing AL and a code from which the type of fault can be determined. 6.1.1 Safety alarms Alarm code Meaning Igniter fault Ionization error... -
Page 15: Incidents And Solutions
6. Troubleshooting 6.3 Incidents and solutions Checks to make before calling your fitter 6.3.1 The burner is not working It is cold. Check the boiler thermostat settings. If using a room temperature thermostat or a remote control (Easymatic or Easyradio), check that it is set according to the instructions. -
Page 16: The Burner Is Operating But The Radiators Are Cold
6. Troubleshooting 6.3.2 The burner is operating but the radiators are cold Air and water noise in the radiators Bleed the radiators. Top up the heating circuit with water. If it is often necessary to top up the installation with water, contact your fitter. -
Page 17: Technical Characteristics
7. Technical characteristics 7 Technical characteristics Boiler SGC 24 SOL General Useful output 50 / 30 °C Nominal output 23.7 Minimum output (heating and DHW modes) Useful output 80 / 60 °C Nominal output 22.0 Minimum output (heating and DHW modes) Power input Nominal output 22.8... -
Page 18: Energy Savings
7. Technical characteristics Boiler SGC 24 SOL Dimensions Height 1710 Width Depth Shipping weight (1) Heat exchanger inlet temperature: 80 °C (3) Cold water temperature: 10 °C Domestic hot water temperature: 45 °C (2) DHW setting: 60 °C Average domestic hot water temperature: 40 °C Boiler setting: 80 °C 8 Energy savings 8.1 Energy-saving advice... -
Page 19: Warranty Terms
7. Technical characteristics Warranty Italy You have just purchased one of our appliances and we thank you for the trust you have placed in our products. Please note that your The duration of our warranty is shown on the certificate delivered appliance will provide good service for a longer period of time if it is with the appliance. - Page 20 All technical and technological information contained in these technical instructions, as well as any drawings and technical descriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations. 15/10/2009 DE DIETRICH THERMIQUE 57, rue de la Gare F- 67580 MERTZWILLER - BP 30...
