ELIDENS
Gas fired condensing boiler
DTG130 - 45/65/90/115 Eco.NOx Plus
Technical instructions
300014279-03

Advertisement

Table of Contents
loading

Related Manuals for DeDietrich DTG130-45

Summary of Contents for DeDietrich DTG130-45

  • Page 1 ELIDENS Gas fired condensing boiler DTG130 - 45/65/90/115 Eco.NOx Plus Technical instructions 300014279-03...

  • Page 2: Declaration Of Conformity

    Declaration of conformity The appliance complies with the standard model described in declaration of compliance . It is manufactured and distributed pursuant to the requirements of european directives. The original declaration of conformity is available from the manufacturer. DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...

  • Page 3: Table Of Contents

    Contents Safety instructions ...............5 General safety instructions .
  • Page 4 Programming boiler control ................41 Domestic hot water preparation .

  • Page 5: Safety Instructions

    1. Safety instructions 1 Safety instructions Danger Any operation on the installation must be This appliance can be used by children aged performed by a qualified technician respecting from 8 years and above and persons with professional regulations and in accordance with reduced physical, sensory or mental capabilities this document.

  • Page 6: Recommendations

    1. Safety instructions 1.2 Recommendations For a proper operating of the boiler, follow Work on electrical equipment must be carried out carefully the instructions. by a qualified professional in compliance with the prevailing regulations. Any intervention on the appliance and heating equipment must be carried out by a qualified Check that the appliance is properly set for the engineer.

  • Page 7: About This Manual

    1. Safety instructions 2 About this manual 2.1 Symbols used in the manual Caution danger Reference Risk of injury and damage to equipment. Attention must be Refer to another manual or other pages in this instruction paid to the warnings on safety of persons and equipment. manual.
  • Page 8 1. Safety instructions DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...

  • Page 9: Description

    (underfloor domestic hot water (when DHW tank is connected). heating, gentle heat radiators, etc.). 3.2 Composition of the range Boiler DTG130-45 / DTG130-65 / DTG130-90 / DTG130-115 No. CE CE-0063BS3826 * - C Type...

  • Page 10: Main Parts

    3. Description 3.3 Main parts • DTG130-45 / DTG130-65 Fan air inlet Return sensor Heating body Venturi premix Combined venturi and gas valve unit Control panel Burner Output sensor 10 Ignition electrode + Ionization electrode 11 Flame inspection window 12 Inspection hatch DTG130 - 45/65/90/115 Eco.NOx Plus...
  • Page 11 3. Description • DTG130-90 / DTG130-115 Fan air inlet Return sensor Heating body Venturi premix Combined venturi and gas valve unit Control panel Burner Output sensor 10 Ignition electrode + Ionization electrode 11 Flame inspection window 12 Inspection hatch 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...

  • Page 12: Technical Specifications

    3. Description 3.4 Technical specifications 3.4.1 Boiler - For operation on Natural Gas or Propane (See "Switching from - Single-unit heat exchanger in aluminium/silicium alloy. Natural Gas to Propane"). - Cylindrical premix burner covered in metal fibres. - The boiler is preset in the factory to operate on natural gas G20, - Centrifugal fan with combustive air intake silencer for a low noise Wobbe index IWS = 15.0 kWh/m , 20 mbar.

  • Page 13: Technical Data

    3. Description 3.5 Technical data DTG 45 DTG... 130... DTG 45 DTG 65 DTG 90 DTG 115 Italy CE identification no **** CE-0063BS3826 Boiler specifications Power input (Hi) - minimum/maximum G20 8.2 - 41.2 8.2 - 34.0 12.2 - 62.0 14.6 - 86.0 19.6 - 110.2 Power input (Hs) - minimum/maximum G20...

  • Page 14: Main Dimensions

    3. Description 3.6 Main dimensions 3.6.1 Boiler self-standing • DTG130 - 45 / 65 / 90 / 115 Eco.NOx Plus DTG130- 45 / 65 / 90 / 115 Heating flow Flow to the exchanger on the independent DHW tank (plugged as standard) (Option) - Package HE25 or Package EA124 Heating return Condensates discharge...
  • Page 15 DTG130 Eco.NOxPlus + Tank BC or BP (150,200,300 l) - Boiler/tank connection kit (Package EA116) Connection options (Not represented): - DTG130-45/65/90/115 Eco.NOxPlus + Tank BSC or BSP (150,200,300 l) - Boiler/tank connection kit (Package EA121). DTG130-45 / 65 / 90 / 115...

  • Page 16: Boiler Installed

    - 60 cm in front of the boiler, - 40 cm above the boiler, • DTG-45 / DTG130-65 / DTG130-90 / DTG130-115 Eco.NOxPlus A. DTG130-45 / DTG130-65 = 1100 DTG130-90 / DTG130-115 = 1322 DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...

  • Page 17: Hydraulic Specifications

    - loss of load in the boiler. ALPHA 2 L 25-60 electronic heating pump (Class A pump): - Optional for DTG130-45 (Package HC142). Manometric height (mWG) Flow rate (m...
  • Page 18 3. Description Circulator UPML XX-95 130 AUTO (Class A pump): - Optional for . (Package SA13). [kPa] Q [m³/h] Q [l/s] C005031-A Constant pressure Proportional pressure Operating pressure Manometric height in metres of water column Flow rate The user interface allows to select between 6 control curves in 2 control modes: - 3 proportional pressure curves (PP), - 3 constant pressure/power curves (CP).
  • Page 19 3. Description Loss of load DTG130-45 A. Manometric height in mWG B. Water flow rate (m3/h) C. Loss of load Loss of load DTG130-65 Loss of load DTG130-90 Loss of load DTG130-115 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...

  • Page 20: Control Panel

    4. Control panel 4 Control panel 4.1 Electromechanical components The panel must always be supplied with 230V voltage: Main ON/OFF switch - to ensure the anti-grip of the heating pump. Pressure gauge Use the mode: * Depending on the model of the appliance, the pressure gauge is - summer to shut down the heating, manual (dial display) or automatic (pictogram display) - antifreeze to shut down the boiler if you are to be absent.

  • Page 21: Keys Accessible When The Flap Is Closed

    4. Control panel 4.3 Keys accessible when the flap is closed Operating mode selection keys Setting the temperatures AUTO Heating according to the time programme Comfort temperature Forced Comfort mode: - until midnight if flashes Reduced temperature - all the time if is steady Forced Low mode: Domestic hot water temperature...

  • Page 22: Operating Mode

    4. Control panel 4.5 Operating mode Select the operating modes using the AUTO - • = Reduced mode keys. Heating operates according to the reduced temperature, • AUTO key = Automatic mode independently of the time programmes. Heating and domestic hot water production operate according to the time •...

  • Page 23: Summer Mode

    4. Control panel Anti-freeze Temporary activation (Number of days) Permanent activation First brief touch: Key Long touch, 5 seconds: Key For all circuits: With DIEMATIC Set the number of days' absence (current day = 1) using The arrow above the key is steady. keys (up to 99 days).

  • Page 24: Heating And Domestic Hot Water Temperature Setting

    5. Heating and domestic hot water temperature setting 5 Heating and domestic hot water temperature setting Comfort temperature Reduced temperature Domestic hot water temperature 5.1 Heating temperature setting The comfort and reduced temperatures are set separately for each circuit: Temperature Adjustment range Factory setting - Select the comfort temperature or the reduced temperature for the...

  • Page 25: Selecting A Programme

    6. Selecting a programme 6 Selecting a programme 6.1 Selecting a programme • The DIEMATIC 3 control unit includes 4 heating • Allocation of a programme to a circuit: programmes: - Select the circuit using key A.B.C. - 1 fixed programme P1, activated in the factory. - Select the programme using the PROG key.

  • Page 26: Installation

    7. Installation 7 Installation 7.1 Statutory terms and conditions of installation and maintenance Germany The installation and maintenance of the appliance must be carried out by a qualified professional in compliance with the statutory texts In addition to the instructions on construction and combustion of the codes of conduct in force, particularly: equipment, also abide by the following standards, rules and directives when installing and commissiong gas condensing boilers:...

  • Page 27: Important Comments On The Treatment Of The Heating Circuit

    75°C. Otherwise, the minimum required flow is: - 160 l/h for DTG130-45, - 240 l/h for DTG130-65, - 300 l/h for DTG130-90, - 350 l/h for DTG130-115.
  • Page 28 7. Installation Location DTG130 - 45/65/90/115 Eco.NOx Plus boilers must be installed in a frost-free room. In order to avoid damage to the boiler, it is necessary to prevent the contamination of combustion air by chlorine and/or fluoride compounds, which are particularly corrosive.

  • Page 29: Connecting The Furnace

    8. Connecting the furnace 8 Connecting the furnace These actions must be carried out by a qualified To prevent damage caused by overpressure on the gas regulator, the technician. gas supply valve must be closed before carrying out the pressure test on the gas supply pipe.

  • Page 30: Flue Gas System Connections

    8. Connecting the furnace 8.4 Flue gas system connections - The horizontal sections on the flue gas side will be constructed with a gradient to the boiler of 3 %. The cross-section of the aeration Remove the anti-dust plug. vent in the premises for B type connections (i.e.
  • Page 31 8. Connecting the furnace 8.4.1 Classification 3 3 3 Belgium: Boilers can only be installed with flue gas connection pipes Homologation C Air/flue gas connection by means of concentric provided by the constructor. For the list of parts, refer to the current price list.

  • Page 32: Connection Options

    Lmax is measured by adding the lengths of the air/flue gas pipes and the equivalent lengths of the other elements. Maximum length of the connection pipes (Metre) Type of air/flue gas connection Diameter DTG130-45 DTG130-65 DTG130-90 DTG130-115 Concentric pipes connected to a horizontal...

  • Page 33: Electrical Connection

    8. Connecting the furnace 8.5 Electrical connection The appliance must be powered by a circuit containing an omnipolar switch with an opening distance 3 mm. 12 Flow sensor (circuit B) 3-way valve (circuit C) 13 Input 0-10 V Pump (circuit C) 14 Room sensor (circuit B) Safety thermostat (circuit C) 15 Room sensor (circuit A)

  • Page 34: Commissioning

    9. Commissioning 9 Commissioning Initial commissioning must be done by a qualified Operation while the condensation water siphon is empty may professional. damage the boiler. Before start-up, the heating installation must be completely emptied and rinsed. 9.1 Filling the system Fill the installation with water.

  • Page 35: Putting The Appliance Into Operation

    9. Commissioning 9.3 Putting the appliance into operation 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...
  • Page 36 9. Commissioning 9.3.1 DTG130-45 / DTG130-65 / DTG130-90 For Belgium: Any work on the gas block must be carried Open the panel flap. out by a factory technician (For example: SERV’élite). Press key simultaneously for 2 seconds. The boiler is preset in the factory to operate on natural gas Set the burner output using the + and - keys.
  • Page 37 9. Commissioning For the United Kingdom: content (%) (Maximum heat input) content (%) (Maximum heat input) Boilers DTG130-45 DTG130-65 DTG130-90 DTG130-45 DTG130-65 DTG130-90 Natural gas H (G20) - 9.3 - 9.3 - 9.8 4.3 - 4.8 4.3 - 4.8 3.4 - 3.9 Propane (G31) 10.7...
  • Page 38 9. Commissioning 9.3.2 DTG130-115 For Belgium: Any work on the gas block must be carried out by a factory technician (For example: SERV’élite). The boiler is preset in the factory to operate on natural gas G20. The conversion from Natural Gas G20 to Natural Gas G25 requires the installation of the conversion kit delivered with the boiler.
  • Page 39 9. Commissioning Fitting the G25 natural gas conversion kit C001282-B Replace the diaphragm diameter 8.6 with the diaphragm diameter content (%) 9.8 in the sachet. Maximum heat input 3.5 - 4.0 Natural gas G25 Natural gas G25 (Netherlands) 3.8 - 4.3 G25.1 3.8 - 4.3 G25.3...
  • Page 40 9. Commissioning If the values exceed the tolerances : - Check the gas input pressure. - Check that the diaphragm fitted is suitable for the gas being used : (G25 = Diameter 9.8, G20 = Diameter 8.6, Propane = Diameter 6.7). Set the burner output to minimum using the - key.

  • Page 41: Adapting The Output

    9. Commissioning 9.4 Adapting the output Setting the burner output Control value Output (kW) (Hi / Hs) DTG130-45 DTG130-65 DTG130-90 DTG130-115 41.2 / 45.7 62.0 / 68.8 86.0 / 95.5 110.2 / 122.4 37.9 / 42.1 57 / 63.3 79.1 / 87.8 102.1 / 113.3...

  • Page 42: Messages - Alarms

    10. Messages - Alarms 10 Messages - Alarms 10.1 Faults In the event of a fault, the display may show the following messages. Contact your fitter. Message Probable causes Action The message SHOW REM.CTRL To cancel the overrides on all remote controls, press the AUTO key for 5 seconds. SHOW REM.CTRL indicates the presence of an override on a remote control...
  • Page 43 10. Messages - Alarms Faults Probable causes Action FAN OFF FAIL The fan is not working Fan defective Check the fan wiring (corrosion of the connection) Safety control box defective FAN ON FAIL The fan is working constantly Electrical connections broken Fan control is defective (replace the fan) BOILER S.FAIL.

  • Page 44: Blockage (Temporary)

    10. Messages - Alarms 10.2 Blockage (temporary) Code no. Description Checks BL.AIR The setting of the parameters is incorrect Check the boiler type Briefly cut the electrical power supply to the boiler using the On/Off switch Check the wiring BL.RET.HIG.BOI Return temperature >...

  • Page 45: User Settings

    11. User settings 11 User settings Key for access to setting and measurements Page scrolling Line scrolling Back to the title or the previous line Programming keys Enter (per 1/2 hour) the comfort temperature period or tank load enabled (dark area) Enter (per 1/2 hour) the reduced temperature period or tank load disabled (light area) Return key 11.1 Measurements...

  • Page 46: Programming

    11. User settings 11.2 Programming Factory programmes All customised programmes are replaced with their factory setting. See chapter Selecting a programme Programme P1 is assigned to all heating circuits. Resetting the programmes Press the STANDARD key for 5 seconds. Customised programming #PROG.CIRC.A Comfort periods Monday...
  • Page 47 11. User settings #PROG.DHW: Domestic hot water #PROG.AUXIL: Programming the auxiliary outlet Filling enabled Authorised operation Monday Monday Tuesday Tuesday Wednesday Wednesday Thursday Thursday Friday Friday Saturday Saturday Sunday Sunday Press Display Parameter set Factory setting #PROG.CIRC.A * Heating programme for circuit A if used PROG EVERY DAY P2 PROG MONDAY P2 PROG TUESDAY P2...
  • Page 48 11. User settings Press Display Parameter set Factory setting #PROG.DHW * 5:00 - 22:00 PROG EVERY DAY PROG MONDAY PROG TUESDAY then PROG WEDNESDAY PROG THURSDAY PROG FRIDAY PROG SATURDAY PROG SUNDAY #PROG.AUXIL * 6:00 - 22:00 PROG EVERY DAY PROG MONDAY PROG TUESDAY then...

  • Page 49: Adjustment

    11. User settings 11.3 Adjustment Adjustment Press Display Parameter set Factory setting Customer setting range #SETTING The parameters are set using keys CONTRAST DISP. Allows the display contrast to be set using keys BACK LIGHT ON Lighting is permanent if the circuit is on comfort period If the circuit displayed is in a reduced period, the light shows ECO...
  • Page 50 11. User settings SUM/WIN Used to set the outside temperature above which heating will be shut down. - The heating pumps are shut down, - The burner will only start for domestic hot water needs, - The symbol E appears. If this parameter is set to NO, heating will never be shut down automatically.

  • Page 51: Clock Settings

    11. User settings 11.4 Clock settings Adjustment Press Display Parameter set Factory setting Customer setting range #TIME . DAY The parameters are set using keys HOURS MINUTE MONTH then DATE YEAR SUM.TIME AUTO: automatic switch to summer time on the last Sunday in March and back to winter time on the last AUTO Sunday in October.

  • Page 52: Installer Settings

    12. Installer settings 12 Installer settings These actions must be carried out by a qualified The various settings and programmes are saved even when the technician. power supply is cut off. Open the flap surrounding the display. Press on the installer key for 5 seconds using a screwdriver or a To return to the factory settings of parameters (user and fitter point of a pencil.

  • Page 53: Professional Settings

    12. Installer settings 12.1 Professional settings Adjustment Press Display Parameter set Factory setting range #LANGUAGE Language selection using keys seconds then FRANCAIS FRANCAIS then #LIMITED TEMP. Setting the temperature limits using keys BOILER MAX Maximum boiler temperature and boiler setting if 80 °C 30 to 90 °C producing domestic hot water...
  • Page 54 12. Installer settings BCT (Bottom of Curve temperature) Used to impose a minimum temperature on the boiler circuit. To direct/control the boiler at a constant temperature by HCZP, set circuit gradient A/B to 0. This setting is required to control an aerothermal or pool type circuit.

  • Page 55: Settings Relating To A Heating Circuit

    12. Installer settings 12.2 Settings relating to a heating circuit Factory Adjustment Customer Press Display Parameter set setting range setting #FITTER PARAM. Setting parameters specific to the installation using keys then BUILD.INERTIA Characterisation of building's inertia 3 (22 hours) 0 (10 hours) to 10 (50 hours) CIRC.CURVE A * Gradient in circuit A...
  • Page 56 12. Installer settings BUILD.INERTIA CIRC.CURVE .. Modification of the factory setting is only useful in exceptional Independent setting for each circuit. cases. - Heating curve circuit A 0 for a building with low thermal inertia. 3 for a building with normal thermal inertia. 10 for a building with high thermal inertia.
  • Page 57 12. Installer settings 12.2 Settings relating to a heating circuit (continued) Adjustment Customer Press Display Parameter set Factory setting range setting #FITTER PARAM. Setting parameters specific to the installation using keys then CT.TEL: Open Telephone input activates if the contact is open Open CLOSE CLOSE...
  • Page 58 12. Installer settings KT.TEL: setting Open CLOSE Open CLOSE I.TEL: status OPEN CLOSE CLOSE OPEN I.TEL ANTIFR Boiler Antifreeze Antifreeze mode Boiler operating mode operating mode selected mode selected DHW+HEAT Hot water storage Burner, heating load pump Boiler operating mode selected. tank affected to (auxiliary pump) and DHW load heating and...
  • Page 59 12. Installer settings CT.TEL: 0-10 V function Defines the nature of the contact (open or closed) which This function controls the boiler using an external system that activates the function associated with the telephone input. includes a 0-10 V output connected to the 0-10 V input. This control imposes an instruction set temperature on the boiler.

  • Page 60: Miscellaneous

    12. Installer settings 12.3 Miscellaneous Adjustment Customer Press Display Parameter set Factory setting range setting #MISCELLANEOUS The parameters are set using keys then DSP: ALTERNATED Alternate display of the two preceding displays ALTERNATED TIME - DAY Permanent time display ALTERNATED TIME - DAY BOILER.T.

  • Page 61: Parameter And Input/Output Check (Mode Tests)

    12. Installer settings 12.4 Parameter and input/output check (mode tests) Press Display Output or input parameter status #PARAMETERS 10 seconds then PERMUT Cascade permutation status (1 = permutation 1-2, 2 = permutation 2-1) STAGE Current speed (Number of boilers requesting heating) NB.CASC.
  • Page 62 12. Installer settings Press Display Output or input parameter status #TEST INPUTS then PHONE REM. Bridge on telephone input (1 = presence, 2 = absence) FLAME Flame (1 = presence, 2 = absence) FAILURE Fault display: yes (1) or no (0) SEQ.

  • Page 63: Adapting To Another Gas Type

    D 51.003, NBN D 30.003, NBN B 61.001, NBN B 61.002 and NBN D 51.006 standards. 13.1 Switching from Natural Gas to Propane DTG130-45 and DTG130-65 DTG130-90 Changing from Natural Gas to Propane requires: Changing from Natural Gas to Propane requires: - the setting of the burner, - the setting of the maximum fan speed.
  • Page 64 Replace the plastic plug onto the measuring tube. Preset the burner by turning the "max output" setting screw - by 3 turns to the right: DTG130-45. - by 4 turns to the right: DTG130-65. Install the conversion kit on DTG130-90.
  • Page 65 13. Adapting to another gas type DTG130-115 Changing from Natural Gas to Propane requires: - Installing the conversion kit. Place the stop/start switch on On. Set the maximum fan speed to a value of: - 6700 rpm: DTG130-115. See chapter Parameter and input/output check (mode tests) "Table: MAX.VENT."...

  • Page 66: Gas Type

    13. Adapting to another gas type Modify the "min output" setting with the setting screw Check the output delivered again. See Table page 40. Adjust if necessary. For Switzerland: The maximum limit values authorised by the OPAIR federal order on air protection regarding CO and NOx must be checked using measurements made in the place of installation.

  • Page 67: Filling In The Commissioning Certificate

    14. Filling in the commissioning certificate 14 Filling in the commissioning certificate Please tick off the work carried out and write down the measurement values Date Company Installation Carry out a gas tightness check Check the fresh air / flue gas pipe Check the tightness of the flue gas pipe Check the neutralisation equipment if used Compare the information on the appliance's rating plate with the type of gas available in situ...

  • Page 68: Maintenance

    5100 5400 6000 6700 1500 1600 2000 1800 (G31) content (%) (Maximum heat input) content (%) (Minimum power) Boilers DTG130-45 DTG130-65 DTG130-90 DTG130-115 DTG130-45 DTG130-65 DTG130-90 DTG130-115 Natural gas H (G20) 4.2 - 4.7 - 6.1 4.3 - 4.8 4.3 - 4.8 3.4 - 3.9...

  • Page 69: Cleaning And Maintenance

    15. Maintenance United Kingdom: content (%) (Maximum heat input) content (%) (Maximum heat input) Boilers DTG130-45 DTG130-65 DTG130-90 DTG130-115 DTG130-45 DTG130-65 DTG130-90 DTG130-115 Natural gas H (G20) - 9.4 4.2 - 4.7 - 9.3 - 9.3 - 9.8 4.3 - 4.8 4.3 - 4.8...
  • Page 70 15. Maintenance - Clean the heat exchanger using the tool provided, - Clean the fan, Operational mode - Clean the siphon, - Close the heating body, When the boiler is fouled, carry out the following maintenance - Measure the combustion. operations: - Open the heating body, - Clean the burner,...
  • Page 71 If the inspection hatch seal remains stuck, it is necessary to replace it. Specific tools: Cleaning knife See chapter Spare parts DTG130-45, DTG130-65: Ref. 83 DTG130-90: Ref. 283 DTG130-115: Ref. 483 Clean inside the exchanger using the specific knife. Remove the inspection hatch, fan, burner and gas block unit.

  • Page 72: Maintenance Of The Air/Flue Gas Drain Connection Flues

    15. Maintenance Cleaning the fan DTG130-45/65: Unscrew the nut on the siphon from underneath the boiler Turn the siphon 90° to the front to dislodge it from the support lug. DTG130-90/115: Unscrew the siphon from the siphon body from underneath the boiler Turn the siphon 90°...

  • Page 73: Temperature Sensor

    15. Maintenance - Check the seal. - Replace the leakproof seals and sections of pipe if these no longer - Check the condensates evacuation device in the boiler and on the offer a perfect guarantee of leak tightness after being dismantled pipe if used.

  • Page 74: Chimney Sweep Instructions

    Press key simultaneously for 2 seconds. EMISSION MES. 88.8uA: Ionization current Use keys + and - to switch from : Maximum boiler output : Minimum output In the display area: DTG130-45 DTG130-65 DTG130-90 DTG130-115 Fan speed (rpm) 1500 1600 1700 1800 Ionization current (µA)

  • Page 75: Schematic Diagrams

    17. Schematic diagrams 17 Schematic diagrams Safety box Operation Display (Not used) Fuse Protection Function protected Ignitor + Ionization probe 230 Volt 2 AF (quick) Safety box Transformer 24 Volt Fuse 4 AT (slow) Safety box 6.3 AT (slow) Power supply 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...
  • Page 76 17. Schematic diagrams Electrical principle diagram See next page. DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...
  • Page 77 17. Schematic diagrams Legend: 0-10 V Input Alim 230 V 50 Power supply230 V - 50 Hz Heating pump circuit A DHW pump Auxiliary pump BPR - BPR I Burner reset button Safety contact EMI-supressor filter PCB connector Live MCBA Safety box Neutral RL PA...

  • Page 78: Spare Parts

    18. Spare parts 18 Spare parts To order a spare part, give the reference number shown on the list. Boiler body DTG130 - 45/65 Eco.NOx Plus DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...
  • Page 79 18. Spare parts Casing DTG130 - 45/65 Eco.NOx Plus 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...
  • Page 80 18. Spare parts Boiler body DTG130 - 90 Eco.NOx Plus 229 266 279 250 DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...
  • Page 81 18. Spare parts Casing DTG130 - 90 Eco.NOx Plus 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...
  • Page 82 18. Spare parts Boiler body DTG130 - 115 Eco.NOx Plus 479 450 DTG130 - 45/65/90/115 Eco.NOx Plus 19/01/2017 - 300014279-03...
  • Page 83 18. Spare parts Casing DTG130 - 115 Eco.NOx Plus 19/01/2017 - 300014279-03 DTG130 - 45/65/90/115 Eco.NOx Plus...
  • Page 84 Complete box door 200009281 Control panel guard S44698 Temperature sensor ELMWOOD NTC 57238 Air silencer 300012502 Water flow pipe DTG130-45 S43563 Fuse 2 AF (quick) 230 V MCBA 300013770 Water flow pipe DTG130-65 S14510 Fuse 4 AT (slow) 24 V MCBA 300012503...
  • Page 85 18. Spare parts Mark. Reference Description Mark. Reference Description 300009075 3 pin connector fitted Power supply S44698 Elmwood NTC temperature sensor 300009074 3 pin connector fitted Pump A 300013081 Heating flow pipe 300009077 3 pin connector fitted Auxiliary pump 300012503 Heating return pipe 300009080 4 pin connector fitted PG-TEL...
  • Page 86 18. Spare parts Mark. Reference Description Mark. Reference Description 0294026 Switch hood S100059 23.47X2.62 O-ring 0294038 Burner reset button 57475 Silencer attachment 200009281 Control panel guard 200013781 Holding bracket 57460 Air silencer Casing DTG130-90 Eco.NOxPlus S6778 Fuse 6.3 AT (slow) Power supply 200009374 Complete top panel S14510...
  • Page 87 18. Spare parts Mark. Reference Description Mark. Reference Description S100082 Diaphragm Natural gas H 59908 Front panel S100038 Diaphragm Natural gas L 97864027 Flap S54731 Exchanger inspection hatch insulation 85000023 Automatic air bleed 3/8" S57477 Burner 97939290 Pipe feed diameter 18 mm S55915 Flue gas outlet gasket DN100 200010257...

  • Page 88: Appendix - Information On The Ecodesign And Energy Labelling Directives

    Appendix Information on the ecodesign and energy labelling directives...
  • Page 89 Contents Contents Specific information ................. . 3 Recommendations .
  • Page 90 1 Specific information Specific information Recommendations Note Only qualified persons are authorised to assemble, install and maintain the installation. Ecodesign Directive This product conforms to the requirements of European Directive 2009/125/EC on the ecodesign of energy-related products. Technical data - Boiler space heaters Tab.1 Technical parameters for boiler space heaters DTG 130–45...
  • Page 91 1 Specific information The back cover for contact details. Disposal and Recycling Fig.1 Recycling Warning Removal and disposal of the boiler must be carried out by a quali­ fied installer in accordance with local and national regulations. If you need to remove the boiler, proceed as follows: MW-3000179-03 1.
  • Page 92 1 Specific information Package fiche - Boiler Fig.2 Package fiche for boilers indicating the space heating energy efficiency of the package Seasonal space heating energy effi ciency of boiler ‘I’ Temperature control Class I = 1%, Class II = 2%, Class III = 1.5%, Class IV = 2%, Class V = 3%, Class VI = 4%, from fi...
  • Page 93 1 Specific information The factor for weighting the heat output of preferential and supple­ mentary heaters of a package as set out in the following table. The value of the mathematical expression: 294/(11 · Prated), whereby ‘Prated’ is related to the preferential space heater. The value of the mathematical expression 115/(11 ·...
  • Page 95 300014279 - ErP02 - 24012017...
  • Page 96 DE DIETRICH THERMIQUE S.A.S 129164, +49 (0)25 72 / 9161-0 +49 (0)25 72 / 9161-102 info@remeha.de +7 (495) 221-31-51 info@dedietrich.ru DE DIETRICH THERMIQUE Iberia S.L.U. DE DIETRICH SERVICE www.dedietrich-calefaccion.es www.dedietrich-heiztechnik.com Freecall 0800 / 201608 C/Salvador Espriu, 11 08908 L’HOSPITALET de LLOBREGAT +34 935 475 850 info@dedietrich-calefaccion.es...
