HAMMER
DRILL
1200W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor:
1200W
Input:
230-240V ~ 50Hz
1
Chuck Size:
13mm (
/
") Keyed
2
No Load Speed:
0-1,000 / 0-3,000/min
Impact Rate:
0-16,000/0-48,000bpm
Drilling Capacities:
Timber 40mm
Steel 13mm
Masonry 16mm
ozito.com.au
WHAT'S IN THE BOX
Hammer Drill
Side Handle
Depth Rod
Chuck Key
HDR-5000
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito HDR-5000
Summary of Contents for Ozito HDR-5000
- Page 1 INSTRUCTION MANUAL Side Handle SPECIFICATIONS Motor: 1200W Input: 230-240V ~ 50Hz Chuck Size: 13mm ( ”) Keyed Depth Rod No Load Speed: 0-1,000 / 0-3,000/min Impact Rate: 0-16,000/0-48,000bpm Drilling Capacities: Timber 40mm Steel 13mm Masonry 16mm ozito.com.au Chuck Key HDR-5000...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION 1. SIDE HANDLE & DEPTH ROD HAMMER DRILL 1 Depth Rod 6 Speed Selection Dial CAUTION: Ensure the tool is disconnected from the power supply before performing any of the following operations. 2 Chuck 7 Variable Speed Switch 3 Side Handle 8 Forward/Reverse Lever...
- Page 3 OPERATION 2. CHUCK 3. ON/OFF SWITCH Keyed Chuck WARNING! To reduce the risk of electric shock, the use of a residual current device (rated 30mA or less) is recommended. 1. Open the chuck jaws Variable Speed Switch slightly larger than the bit you wish to insert.
- Page 4 4. To set hammer mode, slide the selector to the hammer icon. For drilling mode, slide to drill bit icon. drill Note: Do not force the drill or apply side pressure to elongate the hole. Let the drill do the work. hammer HDR-5000...
-
Page 5: Carbon Brushes
Always replace both carbon brushes at the same time. New Zealand 0508 069 486 Note: Ozito Industries will not be responsible for any damage or injuries E-mail: enquires@ozito.com.au caused by the repair of the drill by an unauthorised person or by mishandling of the drill. - Page 6 Tool: 2 Speed 1200W Hammer Drill Model No. HDR-5000 Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No.
- Page 7 Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. extension lead for signs of damage, w ear and ageing. Replace the extension lead if damaged or defective.
- Page 8 • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0414...
