Network Attached Storage
TeraStation 6000
User Manual
TS6200DN Series
TS6400DN Series
TS6400RN Series
Please make sure to read this manual before using and follow the procedures. If you have any inquiries about
the product, contact the number on the warranty statement or the packing box. Do not discard the included
documents, the warranty statement, or the packing box.
Americas: www.buffaloamericas.com
Europe: www.buffalo-technology.com
Asia Pacific: www.buffalo-asia.com
TS6200DN0402
TS6400DN0804
TS6400DN3204
TS6400DN1602
TS6400RN1604
TS6400RN0802
TS6200DN0802
TS6400DN1604
TS6400DN0802
TS6400RN3204
TS6400RN1602
35021637-04
March 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS6400DN0802 and is the answer not in the manual?

Questions and answers

Related Manuals for Buffalo TS6400DN0802

Summary of Contents for Buffalo TS6400DN0802

  • Page 1 Please make sure to read this manual before using and follow the procedures. If you have any inquiries about the product, contact the number on the warranty statement or the packing box. Do not discard the included documents, the warranty statement, or the packing box. Americas: www.buffaloamericas.com Europe: www.buffalo-technology.com Asia Pacific: www.buffalo-asia.com 35021637-04 March 2020...

  • Page 2: Notice

    Notice Notice Regulatory Compliance Information For Customers in the United States This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 3: Warning Symbols And Graphical Icons On The Product

    Notice Warning Symbols and Graphical Icons on the Product Warning symbols are used on the product for safety operation and prevention of injury to you and damage to the unit. The following explains the meanings of symbols used on the product. This symbol indicates important warnings or cautions for operation and maintenance.
  • Page 4 Notice Caution: Do not remove the cover. (10) Caution: Slide/rail mounted equipment is not to be used as a shelf or a work space. (11) Caution: Be careful not to injure fingers when handling. Do not remove the cover. (12) Caution: Do not replace the battery.

  • Page 5: Table Of Contents

    Table Of Contents Notice ................1 Regulatory Compliance Information ..........1 Warning Symbols and Graphical Icons on the Product ....2 Safety Precautions ................2 Chapter 1 Getting Started .......... 12 Diagrams ..................12 Turning the TeraStation On and Off..........15 Re-Inserting Drives ............... 17 Creating an Initialization Drive ............
  • Page 6 Configuring Users ................. 27 Adding a User ...................27 Importing User Information ..............29 Adding a Group ................29 Configuring Access Restrictions for Shared Folders ....32 Local Users and Groups ................32 Active Directory ..................33 Configuring Access Restrictions for Subfolders ......36 Enabling Subfolders’...
  • Page 7 Checking Drives ................57 S.M.A.R.T..................58 Displaying S.M.A.R.T. Information ............58 Checking Drive Condition ...............59 Formatting Drives ................. 60 Encrypting Drives ................61 Erasing Data on the TeraStation Completely ......61 Using the TeraStation as an iSCSI Device ........62 Introduction .....................62 Creating an iSCSI Volume ................62 Connecting or Disconnecting Volumes ..........65...
  • Page 8 Preparing a Backup Destination .............95 Configuring a Backup Job ...............97 If Backing Up from rsync-Compatible Devices to the TeraStation ..101 Restoring Backup Data ................101 Backup Logs for If Backup Fails ............105 Replication ................... 108 Preparing a Replication Destination ............109 Configuring a Replication Job ..............110 Synchronizing Between Source and Destination TeraStations Periodically .....................113 Failover ..................
  • Page 9 Configuring a New Job ................146 Changing Job Settings ................153 Corrective Actions for in Case of Error ..........156 WebAccess ................... 157 FTP ....................159 Chapter 7 Advanced Features ........161 Antivirus Software ..............161 Activating Virus Scanning ..............161 Configuring Security Settings ..............162 Licenses ....................164 Connecting Through a Proxy Server ............165 Updating Antivirus Pattern Files ............166...
  • Page 10 SSL Keys ....................184 SNMP .................... 185 Saving and Applying Settings ............ 186 Saving Settings ..................187 Applying Settings ..................188 Transferring Another TeraStation’s Settings ......189 Creating a Config File (.nas_config) ............189 Transferring Settings ................190 Restoring Factory Defaults ............191 Initializing from Settings ..............191 Initializing with the USB Initialization Drive ........191 Resetting the Administrator Password ........
  • Page 11 Mapping IP Address and Hostname .......... 210 Boot Authentication ..............211 Notes Before Use ..................212 Important Notice ...................212 Setting Up the Authentication Server on a Windows PC ....212 Configuring Boot Authentication on the TeraStation ......213 If the TeraStation Cannot Be Accessed ..........214 Chapter 8 Drive Replacement ........
  • Page 12 Cleaning the Dustproof Filter ............ 227 LCD Panel ..................229 Modes .....................229 Errors .......................230 Status ......................231 Default Settings ................233 Specifications ................234...

  • Page 13: Chapter 1 Getting Started

    Chapter 1 Getting Started Chapter 1 Getting Started Diagrams Depending on the number or type of drives in the unit, the model name will be different. Check the sticker on the packing box for your unit’s model name. TS6200DN 2 3 4 5 6 7 15 16 17 18 19 TS6400DN 2 3 4 5 6 7...
  • Page 14 Chapter 1 Getting Started TS6400RN 3 4 5 6 7 13 15 23 16 17 18 19 Power Button To power on, connect the power cable and wait for 10 seconds, then press the power button. To power off, press and hold down the power button for three seconds. If the TeraStation beeps, pressing this button for a short period will stop the beeping.
  • Page 15 Spins to prevent overheating inside. Do not block the fan. Not in use. USB Port Compatible Buffalo USB drives, USB memory devices, and USB UPS connections can be connected. USB hubs are not compatible. LAN Port 1 (1GbE) Connect an Ethernet cable to use this port for your network. It is available for communicating at max. 1000 Mbps.

  • Page 16: Turning The Terastation On And Off

    Chapter 1 Getting Started Link/Act LED Glows green when the TeraStation is connected to a network at 1000 Mbps, 2.5 Gbps, or 5 Gbps. It blinks when the connection is active. Link/Act LED Glows blue when the TeraStation is connected to a network at 10 Gbps. It blinks when the connection is active. Turning the TeraStation On and Off Note: Do not disconnect or reconnect the internal drives while turning on or off the TeraStation.
  • Page 17 Chapter 1 Getting Started Enter the username and password, then click OK. Note: The default username and password are “admin” and “password”. Settings will open.

  • Page 18: Re-Inserting Drives

    Chapter 1 Getting Started Click at the top-right of Settings and choose Shut Down. Click Yes. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. When the power LED turns off, the shutdown process is completed. Re-Inserting Drives If the E14 or E16 error appears on the LCD panel after initial bootup, follow the procedure below to re-insert the internal drives.

  • Page 19: Creating An Initialization Drive

    Chapter 1 Getting Started Insert the drive back into the same slot with the lock mechanism remaining open. Push here to insert. Swing the lock back down until it clicks into place. Repeat steps 3–6 for all other installed drives. Once every drive has been re-inserted, close the front cover.

  • Page 20: Chapter 2 Configuration

    Chapter 2 Configuration Chapter 2 Configuration Configure and manage your TeraStation using the Settings interface, accessible from a browser window. Open the interface using the procedure below or type the TeraStation’s IP address into the URL field of your browser. Note: Microsoft Edge, Firefox, Google Chrome, Internet Explorer 9 or later, and Safari 9 or later are supported.

  • Page 21: Opening Settings

    Chapter 2 Configuration From Settings, click Management. Click the settings icon (   ) to the right of “Restore/Erase”. Click Execute Wizard. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Follow the procedure on the screen and finish the setup wizard. Opening Settings Double-click the NAS Navigator2 icon ( ...
  • Page 22 Chapter 2 Configuration Enter the username and password, then click OK. Notes: • If the time-out period is set to “10 minutes”, you will be logged out of Settings after 10 minutes of inactivity. • Click Secure Connection to log in using an encrypted connection. Settings will open.

  • Page 23: Checking The Device Information From Dashboard

    Chapter 2 Configuration • Click at the top-right of Settings and choose I'm here to have the TeraStation beep so it can be located easily. Checking the Device Information from Dashboard When opening the Settings interface, the Dashboard page will appear first. Dashboard will show the following device information: •...

  • Page 24: Chapter 3 File Sharing

    Chapter 3 File Sharing Chapter 3 File Sharing You can create users and groups to access the shared folders on the TeraStation and configure access restrictions to limit access to key data. Configuring Shared Folders Adding a Shared Folder From Settings, click File Sharing. Click the settings icon ( ...
  • Page 25 Chapter 3 File Sharing Configure the desired settings, then click OK. Notes: • Names may contain up to 27 alphanumeric characters, hyphens (-), and underscores (_). Multibyte characters are supported. The first character should not be a symbol. • When you click the Option 1 tab, you can enter the folder description. Descriptions may contain up to 75 alphanumeric characters, hyphens (-), underscores (_), and spaces.

  • Page 26: Recycle Bin

    Chapter 3 File Sharing ? ] [ / \ = + > < ; : " , | * • Do not use a name already in use as an iSCSI volume name; do not use any of the following words for the name of a shared folder as these words are reserved for internal use by the TeraStation: authtest, global, homes, info, lost+found, lp, msdfs_root, mt-daapd, printers, ram, spool, usbdisk x (where “x”...

  • Page 27: Hidden Shares

    Chapter 3 File Sharing Read-only shares and HFS Plus-formatted USB drives will have “(Read Only)” added to comments in File Explorer. Notes: • Configure the share attribute only through Settings. Configuring folder attributes through Windows is not supported and may cause unexpected behavior. •...

  • Page 28: Configuring Users

    Chapter 3 File Sharing Enable quotas, choose the alert and the maximum amount of space the user will be allowed to use, and click Configuring Users Adding a User Note: The TeraStation can register a maximum 300 of users, which include the default users “admin” and “guest”. From Settings, click File Sharing.
  • Page 29 Chapter 3 File Sharing Enter the desired settings, then click OK. Notes: • Usernames may contain up to 128 alphanumeric characters, hyphens (-), underscores (_), periods (.), and the symbols ! # & @ $ * ^ %. The first character should not be a symbol. •...

  • Page 30: Importing User Information

    Chapter 3 File Sharing Importing User Information You can import users in File Sharing > Users by clicking Import CSV File. An example format for user data: Username (required), password (required), and user description (optional). Example 1: Importing usernames, passwords, and comments username1,password1,comment1 username2,password2,comment2 username3,password3,comment3...
  • Page 31 Chapter 3 File Sharing Click Add Group.
  • Page 32 Chapter 3 File Sharing Enter the desired settings, then click OK. Notes: • Group names may contain up to 20 alphanumeric characters, hyphens (-), underscores (_), and periods (.). The first character should not be a symbol. • Group descriptions may contain up to 75 alphanumeric characters, hyphens (-), underscores (_), and spaces. Multibyte characters are supported.

  • Page 33: Configuring Access Restrictions For Shared Folders

    Chapter 3 File Sharing Configuring Access Restrictions for Shared Folders You may restrict access to specific shared folders, including external USB drives. Notes: • Shared folders with limited access can still be used as backup destinations. • If you grant both read-only and read and write access to the users or groups, the attributes will become as below: Group with read and Group with read-only Group with no access...

  • Page 34: Active Directory

    Chapter 3 File Sharing Click the Access Restrictions tab. Enable “Access Restrictions for Shared Folders”. Select the level of access for the user or group. : Read and write : Read-only : No access Click OK. Note: The example above shows access restrictions by users. To restrict access by group, click the Local Groups tab and select group permissions.
  • Page 35 Chapter 3 File Sharing Click Edit. Select “Active Directory”, then click Next. Enter the domain controller information and click Search. The domain controller on the same network will be detected and required settings will be entered into each field automatically. Alternatively, you can also manually enter the settings.
  • Page 36 Chapter 3 File Sharing Click the shared folder that you want to set access restrictions for. Click the Access Restrictions tab. Enable “Access Restrictions for Shared Folders”. Select the level of access for the user or group. : Read and write : Read-only : No access Click OK.

  • Page 37: Configuring Access Restrictions For Subfolders

    Chapter 3 File Sharing In such a case, change the policy settings on the domain controller or let the TeraStation join the Active Directory domain again. Configuring Access Restrictions for Subfolders You may restrict access to subfolders in shared folders by configuring access permissions from your computer using Windows File Explorer.
  • Page 38 Chapter 3 File Sharing Click the shared folder that you want to set access restrictions for. Clear all checkboxes for “LAN Protocol Support” other than “SMB (Windows/Mac)”, “Backup”, and “NFS”. Click the Option 2 tab. Enable “Access Restrictions for Subfolders”. Note: If “Hide Non-Access Permitted Files and Folders”...

  • Page 39: Restoring Owner And Permission Settings

    Chapter 3 File Sharing You may also configure access permissions for domain users and groups. You should have the TeraStation join your Active Directory domain before configuring access permissions from File Explorer. Notes: • If enabling subfolders’ access restrictions for a USB drive, the drive should be formatted using Btrfs, XFS, or ext3. •...
  • Page 40 Chapter 3 File Sharing Click the settings icon (   ) to the right of “Folder Setup”. Click Advanced Settings for Subfolders.
  • Page 41 Chapter 3 File Sharing Select a folder to restore permissions from the tree. Note: If you select a root shared folder from the tree, the action will not be run to the recycle bin. To run the action, select the recycle bin instead. Select the actions and action range to run, then click OK.

  • Page 42: Chapter 4 Storage Management

    Chapter 4 Storage Management Chapter 4 Storage Management RAID Modes TeraStations support many types of RAID. The type of RAID arrays available for use depends on how many drives are installed in your TeraStation. Notes: • If you change the RAID mode, all data on the array is deleted. This is true for every procedure in this chapter. Always back up any important data before performing actions that affect your RAID array.

  • Page 43: Working With Raid Arrays

    Chapter 4 Storage Management RAID 1 Combines two or more drives into a mirrored array. The usable space is equal to the capacity of a single drive. Identical data is written to each drive. If a drive becomes damaged, data can be recovered by replacing the damaged drive.

  • Page 44: Changing Raid Mode

    Chapter 4 Storage Management Click the array to delete. Click Delete RAID Array. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Click OK when completed. Next, create a shared folder by referring to the “Adding a Shared Folder” section in chapter 3.

  • Page 45: Shutting Down The Terastation Automatically If An Error Occurs

    Chapter 4 Storage Management Choose a RAID array. Select a RAID mode and the drives to be used, then click Create RAID Array. Click OK. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Click OK when completed. Next, create a shared folder by referring to the “Adding a Shared Folder”...
  • Page 46 Chapter 4 Storage Management From Settings, click Storage. Click the settings icon (   ) to the right of “RAID”. Click Options. Click Edit.

  • Page 47: Configuring Actions For If A Drive Used For The Raid Array Has Not Been Detected

    Chapter 4 Storage Management Change the “Error Behavior” option to “Shut down” and click OK. Configuring Actions for If a Drive Used for the RAID Array Has Not Been Detected The TeraStation can configure actions for if a drive used for the RAID array cannot be mounted when booting. Displaying or Hiding the Confirmation Screen Configure to display or hide the confirmation screen for selecting actions for if a drive used for the RAID array cannot be mounted when booting.
  • Page 48 Chapter 4 Storage Management Click Options. Click Edit. Change the “Drive Detection Action Settings” option to “Don't prompt when a drive could not be detected” and click OK.
  • Page 49 Chapter 4 Storage Management When the confirmation screen is hidden, an undetected drive will automatically be dismounted from the TeraStation and the TeraStation will be in degraded mode if a redundant RAID mode is configured. If RAID 0 is configured, the RAID array will be corrupted so that data will be lost.

  • Page 50: Configuring A Hot Spare

    Chapter 4 Storage Management Conditions Corrective Actions RAID 10 has been configured. Refer to the “Selecting the Action on the Confirmation Screen” section above on how to access the confirmation screen. Select “Shut down the TeraStation and reconnect the drives” and click Execute.

  • Page 51: Expanding Raid Capacity Without Deleting Data

    Chapter 4 Storage Management Click Set as a hot spare. Click Yes. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Click OK when completed. Note: To turn the hot spare back to a normal drive, choose Set as a normal drive. Expanding RAID Capacity Without Deleting Data You can create or expand a RAID array without erasing data on the drive by using RMM (RAID Mode Manager).
  • Page 52 Chapter 4 Storage Management From Settings, click Storage. Click the settings icon (   ) to the right of “Drives”. Select the inserted new drive and click Format Drive. Select a format type and click Format. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Click OK when completed.
  • Page 53 Chapter 4 Storage Management From Settings, click Storage. Click the settings icon (   ) to the right of “RAID”. Choose a RAID array. Set the RAID mode to “RAID 1”. Select the “Add a drive to a RAID array with RMM. Your data will be preserved. ” checkbox.
  • Page 54 Chapter 4 Storage Management Select the drive whose data will be saved from the drop-down list. Select the drive to add to the RAID array. Click Create RAID Array. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Click OK when completed.

  • Page 55: Raid Scanning

    Chapter 4 Storage Management Select one drive to add to the RAID array. If changing the RAID mode, choose the desired mode for the array from the drop-down list. If not, keep the current RAID mode as is. Click Change RAID Array. The “Confirm Operation”...

  • Page 56: Adding An External Drive

    Connecting to this TeraStation. Connecting to another Buffalo NAS device. Ext3 Connecting to another Buffalo NAS device that is a TS-X or older model. Connecting to Windows computers. The NTFS-formatted drive can use many NTFS more functions of the operating system than an exFAT drive.

  • Page 57: Dismounting Drives

    Chapter 4 Storage Management Notes: • If your USB 3.0 drive is not reconfigured after rebooting the TeraStation, unplug and reconnect it. • When copying a file that is over 100 MB to a FAT32-formatted USB drive using File Explorer, an error message may appear.

  • Page 58: Checking Drives

    Chapter 4 Storage Management Select the drive to dismount and click Dismount Drive. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. When the dismounting process is completed, it is safe to unplug the drive. Disconnect the drive from the TeraStation.

  • Page 59: Displaying S.m.a.r.t. Information

    Chapter 4 Storage Management Select the drive or array to test, then click Check Drive. Click Check. You have the option of deleting information files from macOS during the check if desired. S.M.A.R.T. S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology) monitors internal drives to detect and report various indicators of reliability, in the hope of anticipating failures.

  • Page 60: Checking Drive Condition

    Chapter 4 Storage Management Select a drive to check and click S.M.A.R.T. The S.M.A.R.T. information for the drive will be displayed. Different information may be displayed depending on the brand of drives in your TeraStation. Critical attributes are displayed in bold. Checking Drive Condition Attributes with the worst value that is equal to or less than the threshold value may be significant.

  • Page 61: Formatting Drives

    Chapter 4 Storage Management Formatting Drives Notes: • Under some circumstances, data deleted when a drive is formatted can be recovered. To ensure that data is “gone forever”, a format might not be sufficient. Refer to the “Erasing Data on the TeraStation Completely” section below.

  • Page 62: Encrypting Drives

    Chapter 4 Storage Management The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Depending on the size and the formatted file system of your drive, the format may take several minutes or several hours to complete. The I20 message for drives or the I28 message for USB drives will appear on the LCD panel until the format is completed.

  • Page 63: Using The Terastation As An Iscsi Device

    Chapter 4 Storage Management Click the settings icon (   ) to the right of “Restore/Erase”. Click Erase TeraStation. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. All data on the TeraStation will be permanently erased. Using the TeraStation as an iSCSI Device Introduction iSCSI is a protocol for carrying SCSI commands over IP networks.
  • Page 64 Chapter 4 Storage Management Notes: • If the volume settings are changed, all data on the volume will be erased. Before changing any settings, back up any important data. • The TeraStation can have up to 255 volumes, but we recommend creating no more than 32. Exceeding this volume amount may cause irreparable damage to the unit.
  • Page 65 Chapter 4 Storage Management Click Create Volume. Enter a volume name, volume description, drive or array where a volume will be created, and volume size. Click OK when completed. If you enabled LVM for the target drive or array, or selected “File I/O” for the “Backstore” option, the volume size that you specify here can be changed later.

  • Page 66: Connecting Or Disconnecting Volumes

    Chapter 4 Storage Management Notes: • If you click Disable Connection for the selected volume in Storage > iSCSI in Settings, the selected iSCSI volume can no longer be accessed. If you click Enable Connection, the volume will become accessible from the iSCSI initiator software.

  • Page 67: Using With Multiple Computers

    Chapter 4 Storage Management Right-click the drive volume that shows the status “Unallocated” and click New Simple Volume from the displayed menu. Follow the screen to finish formatting. When the formatting process is completed, the drive will be visible as an icon in Computer or This PC and can be used as a normal drive on the computer.
  • Page 68 Chapter 4 Storage Management Click the Security tab. Click Edit under “Access Control (Target Discovery)”. Enable authentication, enter the target CHAP name and secret, and click OK. Note: To enable mutual authentication in addition to target CHAP name and secret authentication, select the “Enable mutual authentication”...
  • Page 69 Chapter 4 Storage Management If mutual authentication is enabled, select the “Perform mutual authentication” checkbox. Click OK, then click OK again. The iSCSI volumes on the TeraStation will be listed under “Discovered targets” on the Targets tab. Select the desired volume to connect and click Connect. Click OK.

  • Page 70: Expanding Volume Sizes

    Chapter 4 Storage Management Note: To enable mutual authentication, select the “Enable” checkbox to the right of “Mutual Authentication” and enter the initiator CHAP secret. Click OK when completed. Connecting to Individual Volumes that Are Access-Restricted Open the Microsoft iSCSI Initiator. Register the initiator CHAP secret to your computer first.

  • Page 71: Deleting Volumes

    Chapter 4 Storage Management Enter the desired volume size to add and click OK. Click OK. Deleting Volumes To delete an existing volume, follow the procedure below. Note: Deleting a volume will erase all data on the volume. Back up the data before deleting the volume. From Settings, click Storage.

  • Page 72: Advanced Settings

    Chapter 4 Storage Management Select the volume to delete and click Delete Volume. Confirm that the volume is correctly selected on the screen and click OK. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. Click OK. Advanced Settings You can configure the following advanced parameters for each iSCSI volume.

  • Page 73: Chapter 5 Backup

    Application for iSCSI Volume Snapshots To create an iSCSI volume snapshot in the environment where the iSCSI volumes on the TeraStation are connected using a virtual machine, we recommend using the Buffalo-offered Windows Server application “Snapshot Agent for TeraStation”, available from the Buffalo website.
  • Page 74 Chapter 5 Backup Click the number under “Snapshot” for the shared folder on the shared folder list. Click Create.
  • Page 75 Chapter 5 Backup Select or clear the “Lock” checkbox to determine whether the created snapshot will be locked or unlocked and enter a short description, then click OK. A locked snapshot cannot be deleted due to auto-archiving. The snapshot will be created in the shared folder. Notes: •...
  • Page 76 Chapter 5 Backup Select the checkbox for the target iSCSI volume and click Show Snapshot List. Click Create.

  • Page 77: Accessing The Snapshots Via Smb

    Chapter 5 Backup Select or clear the “Lock” checkbox to determine whether the created snapshot will be locked or unlocked and enter a short description, then click OK. A locked snapshot cannot be deleted due to auto-archiving. The snapshot will be created on the iSCSI volume. Notes: •...
  • Page 78 Chapter 5 Backup Click the shared folder to access snapshots from the computer. Click the Option 2 tab. Enable shadow copy and click OK. From the computer, access the TeraStation using File Explorer and right-click the shared folder to view snapshots.

  • Page 79: Restoring Snapshots

    Chapter 5 Backup The entire history of created snapshots will appear. Select the snapshot and the action to be taken for the snapshot. Restoring Snapshots To restore the created snapshots to the shared folder or the iSCSI volume, follow the procedure below. For Shared Folders Note: When restoring snapshots, the file sharing service will restart so shared folders will become inaccessible temporarily.
  • Page 80 Chapter 5 Backup Click the number under “Snapshot” for the shared folder on the shared folder list. Select the checkbox for the target snapshot and then click Restore.
  • Page 81 Chapter 5 Backup A new snapshot will be created before restoring the snapshot. Select or clear the “Lock” checkbox to determine whether the created snapshot will be locked or unlocked and enter a short description, then click OK. A locked snapshot cannot be deleted due to auto-archiving.
  • Page 82 Chapter 5 Backup Select the checkbox for the target iSCSI volume and click Show Snapshot List. Select the checkbox for the target snapshot and then click Restore.

  • Page 83: Configuring Schedule Snapshot

    Chapter 5 Backup A new snapshot will be created before restoring the snapshot. Select or clear the “Lock” checkbox to determine whether the created snapshot will be locked or unlocked and enter a short description, then click OK. A locked snapshot cannot be deleted due to auto-archiving.
  • Page 84 Chapter 5 Backup Click the number under “Snapshot” for the shared folder on the shared folder list. Click Advanced Settings at the lower-left corner of the window.
  • Page 85 Chapter 5 Backup Click the Schedule tab. Enable schedule snapshot. Select the day of the week and time for when to have a snapshot automatically created. Click OK. For iSCSI Volumes From Settings, click Storage. Click the settings icon (   ) to the right of “iSCSI”.
  • Page 86 Chapter 5 Backup Select the checkbox for the target iSCSI volume and click Show Snapshot List. Click Advanced Settings at the lower-left corner of the window.

  • Page 87: Configuring Snapshot Archive Settings

    Chapter 5 Backup Click the Schedule tab. Enable schedule snapshot. Select the day of the week and time when to automatically create a snapshot. Click OK. Configuring Snapshot Archive Settings If you regularly create snapshots, it will use up capacity on the TeraStation. Snapshot archive settings will allow you to save capacity on created snapshots by automatically deleting older snapshots.
  • Page 88 Chapter 5 Backup Click the number under “Snapshot” for the shared folder on the shared folder list. Click Advanced Settings at the lower-left corner of the window.
  • Page 89 Chapter 5 Backup Click the Auto Archive tab. Select the rule to keep the snapshots. For more detailed information on archiving snapshots, refer to the “Archive Rule for Snapshots” section below. Click OK. For iSCSI Volumes From Settings, click Storage.
  • Page 90 Chapter 5 Backup Click the settings icon (   ) to the right of “iSCSI”. Select the checkbox for the target iSCSI volume and click Show Snapshot List. Click Advanced Settings at the lower-left corner of the window.
  • Page 91 Chapter 5 Backup Click the Auto Archive tab. Select the rule to keep the snapshots. For more detailed information on archiving snapshots, refer to the “Archive Rule for Snapshots” section below. Click OK. Archive Rule for Snapshots Version-Based If you enter specific versions, the snapshots created from the latest up to the entered versions will be kept. Snapshots that don’t match the version will not be removed.
  • Page 92 Chapter 5 Backup until a set number of days has passed. If you set this option and the specified days haven’t passed yet, the snapshots will be kept even if they match the target versions to be deleted. Timeline-Based This rule uses a timeline of when the snapshot was created to keep snapshots. Using this rule will keep any snapshots created at closest to 0 minutes on the hour and 12:00 a.m.

  • Page 93: Backing Up Data On The Terastation

    You can back up the TeraStation folders to another shared folder on the same TeraStation, a connected USB drive, or a shared folder on another Buffalo NAS device, either on the same network or on another network. For best results, using a 10GbE port to connect a backup device is recommended.
  • Page 94 Chapter 5 Backup *4 If the “Inherit subfolders' access restrictions” option is selected when creating a backup job, the device should be a Buffalo NAS device whose subfolders’ access restrictions is available. Overwrite (Incremental) The first backup job runs like a full backup. As each subsequent backup job runs, only files that have been changed since the last full backup will be backed up, but any files deleted from the backup source folder will also remain in the backup destination folder.
  • Page 95 *4 If the “Inherit subfolders' access restrictions” option is selected when creating a backup job, the device should be a Buffalo NAS device whose subfolders’ access restrictions is available. Management Backup Each time a backup is executed, management information is stored, and only files that have changed are backed up.

  • Page 96: Preparing A Backup Destination

    Preparing a Backup Destination Configure a shared folder on a Buffalo NAS device or connected USB drive as a backup destination. The following procedure explains using another shared folder on a TeraStation as a backup destination. The procedure may vary...
  • Page 97 Chapter 5 Backup depending on which Buffalo NAS device is selected as a destination. If using a USB drive as a backup destination, make sure its attribute is set to read and write. To change a read-only USB drive’s attribute to read and write, refer to “Read-Only Shares”...

  • Page 98: Configuring A Backup Job

    You can configure backup jobs by using another shared folder on the Buffalo NAS device or a USB drive connected to the TeraStation as a destination. You can also back up to a Buffalo NAS device on another network as long as the two networks are connected by a VPN or the route is configured properly.
  • Page 99 Chapter 5 Backup If you had configured a backup device access key for the backup source folder on another Buffalo NAS device or the backup destination folder, click Set. If you hadn’t, skip to step 5. Enter the backup device access key and click OK.
  • Page 100 Chapter 5 Backup Click Add. Select backup settings such as date and time to run, then select for the “Operation Mode” drop-down list. Refer to the differences between the backup modes in the “Backup Modes” section above.
  • Page 101 Check it before creating a backup job. • To back up data between Buffalo NAS devices on a network using jumbo frames, make sure that both devices are configured to use identical (or similar) MTU sizes. If MTU sizes are significantly different, the backup job may not be properly performed.

  • Page 102: If Backing Up From Rsync-Compatible Devices To The Terastation

    Chapter 5 Backup If Backing Up from rsync-Compatible Devices to the TeraStation If you want to set an rsync-compatible device as the backup source and back up data on the rsync-compatible device to the TeraStation, you will need to enable rsync access on the TeraStation. From Settings, click File Sharing.
  • Page 103 Click the settings icon (   ) to the right of “Backup”. If you had configured a backup device access key for the backup source folder on another Buffalo NAS device or the backup destination folder, click Set. If you hadn’t, skip to step 5.
  • Page 104 Chapter 5 Backup Enter the backup device access key and click OK. Click Add.
  • Page 105 Chapter 5 Backup Select backup settings such as date and time to run, then select “iSCSI backup” for the “Operation Mode” drop- down list. Click Add.

  • Page 106: Backup Logs For If Backup Fails

    Chapter 5 Backup Select the original backup destination as the backup source, then select an iSCSI file I/O volume as the backup destination. Click OK, then click OK again. The backup job will be added to the backup jobs list. The backup data will be restored on the backup destination after the backup job has run.
  • Page 107 Chapter 5 Backup Code Description Corrective Action Log Example The Ethernet cable was disconnected from the backup Reconnect the Ethernet cable. rsync error: error in source TeraStation when the socket IO (code 10) backup job started. Code 10 at clientserver.c(128) A backup destination doesn’t Select another backup destination [sender=3.1.0pre1]...
  • Page 108 Chapter 5 Backup Code Description Corrective Action Log Example Change the filename or folder Invalid characters were used in name using compatible characters. the filename or folder name of Available characters are described in the backup destinations. “Adding a Shared Folder” section in chapter 3.

  • Page 109: Replication

    Chapter 5 Backup Code Description Corrective Action Log Example Check that the backup destination The backup destination folders folders on the backup destination B104 on the backup destination TeraStation exist in the shared folder TeraStation do not exist. list. Check that the drives are recognized properly in Settings.

  • Page 110: Preparing A Replication Destination

    Buffalo NAS device whose subfolders’ access restrictions is available. Preparing a Replication Destination First, configure a folder as a replication destination. Follow the procedure below to prepare a Buffalo NAS device as a replication destination. Note: You cannot use the same replication destination folder for multiple replication source folders.

  • Page 111: Configuring A Replication Job

    A replication destination has been created. Note: If you want to replicate to a Buffalo NAS device on another network, follow the procedure below to add the Buffalo NAS device so it can be used as a replication destination.
  • Page 112 Chapter 5 Backup If you had configured a backup device access key for the replication destination folder, click Set. If you hadn’t, skip to step 6. Enter the backup device access key and click OK. Click Add.
  • Page 113 Chapter 5 Backup Select the shared folder that will be the replication source and destination, then click OK. Click OK, then Yes. Notes: • During setup, you may choose to encrypt and/or compress replication data. Encrypted data will be transferred securely on the network.

  • Page 114: Synchronizing Between Source And Destination Terastations Periodically

    Chapter 5 Backup Synchronizing Between Source and Destination TeraStations Periodically To copy files that are saved via other file sharing protocols such as AFP or FTP to the replication destination regularly, configure “Periodic Sync” in Settings. Follow the procedure below. From Settings, click Backup.

  • Page 115: Failover

    Chapter 5 Backup Failover With failover, two TeraStations are connected to the network for redundancy, with one being the main TeraStation and the other being the backup TeraStation. If an issue renders the main TeraStation inaccessible, operation automatically switches to the backup TeraStation. Data on both TeraStations stays up-to-date.

  • Page 116: Usage Restrictions

    Chapter 5 Backup LAN port 3 (Static IP) Main Network LAN port 3 (Static IP) Backup Using Different LAN Ports Between File Sharing and Failover With this setup, the backup TeraStation and main TeraStation are connected by a second Ethernet cable connecting their LAN port 3.

  • Page 117: Configuring Failover

    To update the firmware while in maintenance mode, the main TeraStation can be updated from Settings, but the backup TeraStation cannot. Download the firmware updater from the Buffalo website for the backup TeraStation and try updating the firmware on it.
  • Page 118 Chapter 5 Backup Click Configure Failover.
  • Page 119 Chapter 5 Backup Select a TeraStation to be the failover backup device and enter its administrator username and password (by default, the username is “admin” and the password is “password”). Select the LAN port to be used for sharing files and enter a virtual IP address and subnet mask. The LAN port you have selected here will also be used for pinging.

  • Page 120: Switching To The Backup Terastation Manually

    Chapter 5 Backup Press the function button. When you press the function button, the TeraStation will beep once. Press and hold down the button until the backup TeraStation beeps again. The I51 message will appear on the LCD panel and NAS Navigator2 for both TeraStations. Wait until initialization finishes.
  • Page 121 Chapter 5 Backup c. Click the settings icon (   ) to the right of “Power Management”. d. Click Edit. e. Select “Sync with UPS connected to this TeraStation” and reconfigure the desired UPS settings. f. Click OK when completed. Click Backup. Click the settings icon ( ...

  • Page 122: Synchronizing Between Main And Backup Terastations Periodically

    Chapter 5 Backup c. Click Edit. d. Select “Sync with UPS connected to another Buffalo NAS device on the same network” and configure the main TeraStation as a sync source. e. Click OK when completed. Reconfigure failover by referring to the “Configuring Failover”...

  • Page 123: Backing Up Your Mac With Time Machine

    Chapter 5 Backup Click Edit. Select “Daily” or “Weekly” from the “Schedule” drop-down list. If “Daily” is selected, configure the sync period. If “Weekly” is selected, specify the weekdays and the sync period. When the configuration is completed, click OK. Backing Up Your Mac with Time Machine Time Machine is a backup program included with macOS.
  • Page 124 Chapter 5 Backup 1. Preparing a Shared Folder for Time Machine From Settings, click File Sharing. Move the AFP switch to the position to enable AFP. Click the settings icon (   ) to the right of “Folder Setup”. Choose a shared folder as your backup destination for Time Machine. Under “LAN Protocol Support”, select the “AFP (Mac)”...
  • Page 125 Chapter 5 Backup Select the shared folder that you enabled AFP for in the previous steps, then click OK. Click OK, then click OK again. Move the Time Machine switch to the position to enable Time Machine. 3. Configuring Time Machine on macOS From the Apple menu, open System Preferences.
  • Page 126 Chapter 5 Backup Click Time Machine.
  • Page 127 Chapter 5 Backup Click Select Backup Disk. Select the TeraStation, then click Use Disk.
  • Page 128 Chapter 5 Backup Click Connect. Enter a username and password to be used for accessing the shared folder and click Connect. Note: If access restrictions are not configured on the destination share, log in with the administrator account. The default username and password for the administrator account are “admin” and “password”. If access restrictions are configured, log in with an account with write privileges.
  • Page 129 Chapter 5 Backup Time Machine will count down from 120 seconds, then backup will begin.

  • Page 130: Chapter 6 Cloud Services And Remote Access

    Chapter 6 Cloud Services and Remote Access Chapter 6 Cloud Services and Remote Access Synchronizing with Dropbox The TeraStation supports synchronizing with Dropbox, the online cloud service. Once linked, you can share TeraStation files via Dropbox (or Dropbox files via TeraStation). To link your TeraStation with your Dropbox account, follow the procedure below.
  • Page 131 Chapter 6 Cloud Services and Remote Access Click Add. Click View Dropbox Authentication Page. The authentication site that is offered by Dropbox will be displayed. Log in to the website with your Dropbox account, then click Allow. The authentication code will be displayed. Copy the authentication code and return to Settings. Authentication code reregistration should be finished within three minutes.
  • Page 132 Chapter 6 Cloud Services and Remote Access Paste the authentication code and click OK. Enter the desired job name; select the TeraStation and Dropbox folders, and configure encryption. Click OK. If you enable encryption, you will need to set an encryption password. The password cannot be changed once you configure it.

  • Page 133: Changing Job Settings

    Chapter 6 Cloud Services and Remote Access • Files that are 900 MB or larger cannot be downloaded using Dropbox Sync. However, even if the file size is smaller than 900 MB, downloading may fail when multiple processes are running at the same time. Changing Job Settings Follow the procedure below to change any job settings you have already configured.
  • Page 134 Chapter 6 Cloud Services and Remote Access Click the Options tab. Click Edit.
  • Page 135 Chapter 6 Cloud Services and Remote Access Configure the desired settings and click OK. Notes: • When specific settings are changed, the changes will not be applied and the files on Dropbox may not be synchronized to the TeraStation. In such a case, delete the target files to be synchronized and upload them to Dropbox again or delete the job and recreate it again.

  • Page 136: Creating A Shared Link (Windows Only)

    Chapter 6 Cloud Services and Remote Access Creating a Shared Link (Windows Only) Buffalo offers a Windows application, “B-Sync”, that can create shared links for the files stored in the TeraStation folders. You can download the application from the Buffalo website.
  • Page 137 Chapter 6 Cloud Services and Remote Access Click Add. The job setup wizard will open. Enter your Azure Storage account name and access key, then click Next.
  • Page 138 Chapter 6 Cloud Services and Remote Access Enter the desired job name and click Next. Select “Backup” and click Next.
  • Page 139 Chapter 6 Cloud Services and Remote Access Select the desired shared folder on the TeraStation as the backup source folder and enter the container name for the backup destination, then click Next. Specify the sync period and click Next.
  • Page 140 Chapter 6 Cloud Services and Remote Access Select the desired action to take for files in the container that share the same name as files in the backup source after they are deleted, then click Next. Configure whether to filter the backup target files. The following screen is available to configure file filtering by file size and whether they’re hidden.

  • Page 141: Creating A New Restore Job

    Chapter 6 Cloud Services and Remote Access The following screen is available to configure file filtering by extensions. Configure the desired filtering settings and click Next. Confirm that all settings are properly configured and click OK. Notes: • Regardless of whether file filtering was configured, the following files will not be backed up to an Azure Storage container: ◦...
  • Page 142 Chapter 6 Cloud Services and Remote Access Move the Microsoft Azure Storage Sync switch to the position to enable Microsoft Azure Storage Sync. Click the settings icon (   ) to the right of “Microsoft Azure Storage Sync”. Click Add.
  • Page 143 Chapter 6 Cloud Services and Remote Access The job setup wizard will open. Enter your Azure Storage account name and access key, then click Next. Enter the desired job name and click Next.
  • Page 144 Chapter 6 Cloud Services and Remote Access Select “Restore” and click Next. Enter the container name for the restore source and select the desired shared folder on the TeraStation as the restore destination, then click Next. Select either to restore data into the first level folder (root folder) or the second level (subfolder) of the restore destination folder, then click Next.

  • Page 145: Changing Job Settings

    Chapter 6 Cloud Services and Remote Access Confirm that all settings are properly configured and click OK. Note: When deleting a completed restored job, it can be converted to a backup job. If that restore job had been configured to restore to the second level on the shared folder, restored data will automatically move to the first level.
  • Page 146 Chapter 6 Cloud Services and Remote Access Click the Options tab. Click Edit.

  • Page 147: Synchronizing With Microsoft Onedrive

    Chapter 6 Cloud Services and Remote Access Configure the desired settings and click OK. Synchronizing with Microsoft OneDrive The TeraStation supports synchronizing with Microsoft OneDrive, the online cloud storage. Once linked, you can share the TeraStation files via OneDrive (or OneDrive files via the TeraStation). To link your TeraStation with your Microsoft account, follow the procedure below.
  • Page 148 Chapter 6 Cloud Services and Remote Access Click the settings icon (   ) to the right of “Microsoft OneDrive Sync”. Click Add. The sign-in window will open. Enter the username and password of your Microsoft account, then sign in.
  • Page 149 Chapter 6 Cloud Services and Remote Access Enter the desired job name and click Next. Select the sync action and behavior for when files with the same name are already in the target folder. The behavior for when files with the same name already exist will work when the files that have the same name on both the TeraStation and OneDrive are changed.
  • Page 150 Chapter 6 Cloud Services and Remote Access Select the desired TeraStation and OneDrive folders. If you want to create an empty folder first, click Browse under “Folder on TeraStation”, then click Create Folder on the selecting folder window that appears. Click Next after selecting the folders.
  • Page 151 Chapter 6 Cloud Services and Remote Access Specify the sync period and click Next. Files will be uploaded during the start and end time of the period configured in step 9 above. If you want to always upload files during the configured sync period, select “Always sync within the sync period” for “Frequency”.
  • Page 152 Chapter 6 Cloud Services and Remote Access Select whether to encrypt the files using a password. When encryption is enabled, uploaded files will be archived in zip format and encrypted using the entered encryption password. Click Next after selecting. Select whether to check for file consistency. If an inconsistency occurs with a file between the TeraStation and OneDrive, that file will be updated using the latest file version even if it hasn’t been changed.
  • Page 153 Chapter 6 Cloud Services and Remote Access Configure whether to filter the target files. The following screen is available to configure file filtering by file sizes and whether they’re hidden. The file size filtering will work only for the upload process. The available maximum size is up to 15360 MB (15 GB).

  • Page 154: Changing Job Settings

    Chapter 6 Cloud Services and Remote Access Confirm that all settings are properly configured and click OK. Notes: • Files whose filename contains the symbols " # % & * / : > < ? \ } { ~ cannot be synchronized. This symbol limitation is based on “Normalization Form Canonical Composition (NFC)”.
  • Page 155 Chapter 6 Cloud Services and Remote Access Click the Options tab.
  • Page 156 Chapter 6 Cloud Services and Remote Access Click Edit.

  • Page 157: Corrective Actions For In Case Of Error

    Chapter 6 Cloud Services and Remote Access Configure the desired settings and click OK. Corrective Actions for in Case of Error You may encounter error messages that contain the following error codes when creating OneDrive Sync jobs, or the error log may contain the following error codes as well. If you encounter one of the following error codes, refer to the table below and try the respective corrective action.

  • Page 158: Webaccess

    Chapter 6 Cloud Services and Remote Access Code Description Corrective Action Check that the same Microsoft account is used on another TeraStation or Microsoft applications. This error may be resolved by There are too many requests so activityLimitReached reducing the maximum number of threads data could not be synchronized.
  • Page 159 Chapter 6 Cloud Services and Remote Access Configure the desired settings, then click OK. • To use SSL encryption for more secure data transfers, enable “HTTPS/SSL Encryption”. • You may use the BuffaloNAS.com server as a DNS server, or disable it to use a different DNS server. •...

  • Page 160: Ftp

    Allow anonymous: Anyone can access (view) shared folders. (Access restrictions configured for shared folders will not work.) Allow all groups and users: All groups and users registered on the Buffalo NAS device can use WebAccess. (Access restrictions configured for shared folders will not work.) Use inherited folder permissions: Users and groups have the same access permissions with WebAccess that they do locally.
  • Page 161 Chapter 6 Cloud Services and Remote Access Click the settings icon (   ) to the right of “Folder Setup”. Choose a folder to enable remote FTP access on. Under “LAN Protocol Support”, select the “FTP” checkbox on the Basic tab; select read-only or read and write for the shared folder’s attribute on the Option 2 tab and click OK.

  • Page 162: Chapter 7 Advanced Features

    Chapter 7 Advanced Features Chapter 7 Advanced Features Antivirus Software Trend Micro NAS Security can protect your network and data from software viruses, malware, and spyware. Virus scan by Trend Micro NAS Security is available for files in the TeraStation’s shared folders, except for the “usbdisk” folder.

  • Page 163: Configuring Security Settings

    Chapter 7 Advanced Features Click the settings icon (   ) to the right of “Antivirus”. Click Edit. Click Browse and select the quarantine folder. Click OK. Configuring Security Settings Use the Trend Micro NAS Security settings page to configure security settings such as updating pattern files, configuring scan schedules, and activating or extending the license.
  • Page 164 Chapter 7 Advanced Features Click the settings icon (   ) to the right of “Antivirus”. Click Options. Enter your username and password, then click Log On. You can log on using the TeraStation’s admin account. The default username and password are “admin” and “password”.

  • Page 165: Licenses

    Chapter 7 Advanced Features The Trend Micro NAS Security settings page will open. Notes: • The Trend Micro NAS Security settings page is compatible with IE 6.0 SP2 or later (Windows) and Firefox 1.5 or later (Windows or Mac). • To change the display language of the Trend Micro NAS Security settings page, change the system language to the desired settings by referring to the “Name, Date, Time, and Language”...

  • Page 166: Connecting Through A Proxy Server

    Chapter 7 Advanced Features From the left-side menu of the Trend Micro NAS Security settings page, click Administration > Product License. Enter the serial number from the “Trend Micro NAS Security License Pack Guide”, included in your package. Click Activate. The new license is now registered.

  • Page 167: Updating Antivirus Pattern Files

    Chapter 7 Advanced Features From the left-side menu of the Trend Micro NAS Security settings page, click Administration > Proxy Settings. Select the “Use a proxy server to access the Internet (License update)” checkbox. Enter the IP address and port of the proxy server, then click Save.

  • Page 168: Configuring Folders As Virus Scanning Targets

    Chapter 7 Advanced Features Check “Enable Scheduled Update”. Select a time for updates to begin, an interval for updates, and an amount of time for updates to continue. Select the components to update. Click Save. The antivirus software is now configured to update automatically at the scheduled time. Updates will not be downloaded if the TeraStation is turned off, in standby mode, or disconnected from the Internet.

  • Page 169: Configuring Virus Scanning

    Chapter 7 Advanced Features Click the shared folder that you want to exclude from the scan. If the options’ checkboxes are selected on the Option 1 tab, it means the shared folder will be scanned by those scan options. To exclude from the scan, clear the options’ checkboxes. Click OK.

  • Page 170: Checking The Log

    Chapter 7 Advanced Features Click Scan now. This starts the virus scan. If the scan finds a virus, the user can be notified in two ways: • The I34 virus alert message is normally shown on the LCD panel. Once the virus is removed from the quarantine folder, the message is no longer displayed.

  • Page 171: Opening The Online Help

    Chapter 7 Advanced Features Click the log item that you want to check. Click Display Log. This completes the procedure for checking the log. Opening the Online Help For more information on the antivirus software, refer to the online help. Follow the procedure below to access the online help.

  • Page 172: Email Notification

    Chapter 7 Advanced Features Email Notification Your TeraStation can send you email reports daily, or when settings are changed or an error occurs. You can configure the events that will trigger notifications from any of the following functions: quotas, drives (internal, external, or RAID array), fan, backup, replication, failover, antivirus, system alert.
  • Page 173 Chapter 7 Advanced Features If you select an authentication type other than “Disable” from the drop-down list, you can enter the sender email address and credentials of the email server. To change the events of email reports, click Advanced Report Settings. On the displayed screen, select or clear the category’s checkboxes.

  • Page 174: Sleep Mode

    Chapter 7 Advanced Features Email notification will be enabled. Email Notification Categories Notification emails will be categorized into the following importance levels. You can configure them from the “Report Settings” page. Levels Details Daily Report Describes the status of the TeraStation in a daily report email. Sends a notification email if an event occurs.
  • Page 175 Chapter 7 Advanced Features Specify the timer interval, wake-up time, and time to enter sleep mode, then click OK. Notes: • Up to three timers can be set. • The time to enter sleep mode can be set from 12:00 a.m. to 3:45 a.m. of the next day. The time to wake from sleep mode can be set from 12:00 a.m.

  • Page 176: Wake-On-Lan

    Chapter 7 Advanced Features ◦ Example 3: If running at a current time of 10:00 a.m. Wednesday Timer 1: Daily 9:00–18:00 Timer 2: Wednesday 10:00–1:00 a.m. of the next day Timer 3: Not used On days other than Wednesday, normal operation begins at 9:00 a.m. and the unit enters sleep mode at 6:00 p.m.

  • Page 177: Ups (Uninterruptible Power Supply)

    Chapter 7 Advanced Features Enable “Wake-on-LAN”, then click OK. Wake-on-LAN is now enabled. As long as the TeraStation is connected to a power source and the network, you can turn it on remotely. Notes: • After receiving the Wake-on-LAN packet, the TeraStation may take up to five minutes to be ready to use. •...

  • Page 178: Port Trunking

    Buffalo NAS device is connected to the UPS, select “Sync with UPS connected to another Buffalo NAS device on the same network”. After making this selection, enter the IP address of the Buffalo NAS device that will be the sync source into “Other Buffalo NAS's IP Address”.
  • Page 179 Chapter 7 Advanced Features Trunking Mode Characteristics Only one NIC slave in the bond is active. A different slave becomes Active-backup active if and only if the active slave fails. The outgoing network packet traffic is distributed according to the current load (relative to the speed) on each network interface slave.

  • Page 180: Offline Files For Windows

    Chapter 7 Advanced Features Connect the hub’s LAN port and TeraStation’s LAN port using the second LAN cable. If you are using an intelligent switch, connect to the LAN port that was previously configured for port trunking. Restart the TeraStation by pressing and holding down the power button for three seconds to power off the TeraStation, then press the power button again to turn the TeraStation on.

  • Page 181: Accessing From An Nfs Client

    Accessing from an NFS Client Note: (US customers only) Buffalo’s customer support will help configure the NFS settings on your TeraStation, and will support VMware and Windows clients but will not provide support for configuring your Linux or other UNIX clients.
  • Page 182 Chapter 7 Advanced Features Click the Client Settings tab. Click Add. Note: To delete a client, select the checkboxes of the clients from the lists and click Delete.
  • Page 183 Chapter 7 Advanced Features Enter the hostname and IP address of the NFS client, then click OK. You should add all NFS clients to access the shared folder. Click the NFS Rules tab.
  • Page 184 Chapter 7 Advanced Features Click Add. Choose the folder to restrict access to, and enter the clients that will have restricted access into the “Hosts” field. Clients may be entered by hostname, IP address, or IP address range. Wildcards are supported. Separate multiple entries with commas.

  • Page 185: Encrypting Data Transmission

    Chapter 7 Advanced Features mean that only clients on this local network would be able to access the NFS share. If the default settings are used (0.0.0.0 for both the public network address and the public subnet mask), then access to the NFS share will not be restricted.

  • Page 186: Snmp

    Chapter 7 Advanced Features default settings was created by Buffalo, and in some cases, the security certificate warning message may appear in your browser or another security software. Disregard this message and continue. Note: Use TLS 1.2 SSL Certificate. server.key (SSL Private Key) This file is used as a pair with server.crt (server certificate).

  • Page 187: Saving And Applying Settings

    Move the SNMP switch to the position to enable SNMP. SNMP has been configured for the TeraStation. For further use, configure your SNMP-compatible network management software using the Buffalo-specific MIB (management information base) file. The MIB file is available from the Buffalo website.

  • Page 188: Saving Settings

    Chapter 7 Advanced Features Settings & Restore Firmware Settings & Settings & Save Restore Firmware Firmware Settings & Restore Firmware Write down the drive configuration (number of drives, RAID, LVM, etc.) of the TeraStation whose settings were saved. Make sure that any TeraStations that you apply these settings to have the exact same drive configuration before you apply the settings.

  • Page 189: Applying Settings

    Chapter 7 Advanced Features Select “Save current configuration to a USB drive”. From “Target USB Drive”, select the USB drive that is connected to the USB port on the TeraStation, then click Execute. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. The TeraStation will save the settings.

  • Page 190: Transferring Another Terastation's Settings

    • Users • Groups Note: This feature currently supports the following TeraStation series as of November 2018. The latest compatibility information will be on the Buffalo website. • TS-X series firmware version 1.58 or later • TS3000 series • TS4000 series •...

  • Page 191: Transferring Settings

    Chapter 7 Advanced Features Access the “usbdisk x” shared folder while connecting the USB drive to the TeraStation whose settings were saved in the previous step. The “x” in the folder name represents the USB port number you connected the drive Copy and paste the .nas_config file to the desired location on your computer.

  • Page 192: Restoring Factory Defaults

    Chapter 7 Advanced Features on the migration target TeraStation, and groups that share the same name with users on the migration target TeraStation. • If the migration target TeraStations have already added some shared folders, users, and groups, the transferred settings may exceed the maximum number of allowed shared folders, users, or groups.
  • Page 193 Chapter 7 Advanced Features From Settings, click Management. Click the settings icon (   ) to the right of “Configuration Management”. Select “Create a USB drive for initializing settings”. From “Target USB Drive”, select the USB drive that is connected to the USB port on the TeraStation, then click Execute.

  • Page 194: Resetting The Administrator Password

    Chapter 7 Advanced Features Resetting the Administrator Password If you forget the admin username or password and cannot log in to Settings, or wrong network settings are configured and Settings becomes inaccessible, initialize these settings by holding down the init button (refer to “Diagrams”...

  • Page 195: Transferring Logs To The Syslog Server

    Chapter 7 Advanced Features Transferring Logs to the Syslog Server From Settings, click Management. Click the settings icon (   ) to the right of “Logs”. Click Edit.

  • Page 196: Creating A Link To The Logs In The Shared Folder

    Chapter 7 Advanced Features Enable “Syslog Transfer”. Enter the IP address of the syslog server where you want to transfer the logs to. Select the type of log that you want to transfer from “Logs to Transfer”. Click OK. Creating a Link to the Logs in the Shared Folder From Settings, click Management.
  • Page 197 Chapter 7 Advanced Features Click Edit. Enable “Share Link to Logs”. Click Browse and under “Target Shared Folder”, select the shared folder where the created link will lead. Click In the selected shared folder, a folder named “system_log” will now contain the logs.

  • Page 198: Changing Archive Rules For File Access Logs

    Chapter 7 Advanced Features Changing Archive Rules for File Access Logs You can configure how many logs are kept or how long each log will be kept on the TeraStation. From Settings, click Management. Click the settings icon (   ) to the right of “Logs”. Click Edit.

  • Page 199: Updating The Firmware

    Chapter 7 Advanced Features • Unit (Size): 1–100 for file sizes and 1–13 for all versions Click OK. Notes: • To delete the saved logs, click Delete at the window in step 3. • If there is not enough space to save logs, the I70 message will appear on the LCD panel. When it appears, delete unnecessary logs or move them to another device from the TeraStation.

  • Page 200: Updating Automatically

     ) to the right of “Update”. Click Install Update. When updating the firmware is completed, refresh the browser and log in to Settings again. You can also download the latest firmware from the Buffalo website. Updating Automatically From Settings, click Management.

  • Page 201: Configuring Update Notification

    Chapter 7 Advanced Features Select “Update the firmware automatically” and click OK. Alternatively, you may choose to schedule updates for a specific time of day. Configuring Update Notification Configure whether or not to receive a notification when new firmware becomes available. From Settings, click Management.
  • Page 202 Select to enable or disable update notification and click OK. For further optimized firmware updates and product usability improvements, Buffalo may ask you to send your usage and environment information, such as the number of shared folders and client computers, and/or S.M.A.R.T.

  • Page 203: Name, Date, Time, And Language

    Chapter 7 Advanced Features If update notification is enabled, it will also automatically enable sending usage feedback to Buffalo. If you don’t want to send this information to us, disable update notification. Note: If a backup job is running and the update time arrives, auto update will be skipped. After backup is completed, auto update will run at the next upcoming update time.
  • Page 204 Chapter 7 Advanced Features Click the Time tab. Enable the NTP server and select the “Use default NTP server” checkbox. If you disable the NTP function, click Use Local Date/Time to use your computer’s time settings for the TeraStation. By default, the TeraStation adjusts its clock automatically by using a default NTP server. This NTP server belongs to Internet Multi Feed Inc.

  • Page 205: Beep Alerts

    Chapter 7 Advanced Features Click the Management Information tab. Enter the desired location and administrator information. When all settings are completed, click OK. Beep Alerts You can set the TeraStation to beep if certain errors occur. From Settings, click Management. Click the settings icon ( ...

  • Page 206: Lcd And Leds

    Chapter 7 Advanced Features LCD and LEDs You may configure options for the LCD panel and adjust the brightness of the LCD panel and LEDs on the TeraStation. From Settings, click Management. Click the settings icon (   ) to the right of “Notifications”. Click Edit.

  • Page 207: Jumbo Frames

    Chapter 7 Advanced Features From Settings, click Network. Click the settings icon (   ) to the right of “Proxy Server”. Enable “Proxy Server”. Enter the proxy server IP address or hostname, port number, username and password, then click OK. Once you configure the proxy server settings, you may use the settings for other cloud storage services such as Dropbox by selecting the “Configured settings”...
  • Page 208 Chapter 7 Advanced Features Click Edit. Select or enter the desired MTU size and click OK.

  • Page 209: Changing The Ip Address

    Chapter 7 Advanced Features Connection Transmission Transfer data using jumbo frames. Jumbo Frame Jumbo Frame Jumbo Frame Compatible Switch Compatible PC Transfer data without using jumbo frames. Jumbo Frame Jumbo Frame Jumbo Frame Incompatible PC Compatible Switch Transfer data without using jumbo frames.
  • Page 210 Chapter 7 Advanced Features Click Edit. Clear the “DHCP” checkbox and enter the desired IP address and its subnet mask. Select “User (static)” for both “Gateway Owner” and “DNS Owner” options from the drop-down list, then enter the desired default gateway address and DNS server addresses. Click OK.

  • Page 211: Mapping Ip Address And Hostname

    Chapter 7 Advanced Features Notes: • Only one default gateway and DNS address can be configured for all LAN ports. Different network addresses cannot be assigned to the LAN ports. • Do not set the IP address of the same segment for all LAN ports. This may cause unstable network communication.

  • Page 212: Boot Authentication

    Chapter 7 Advanced Features Click Add. Enter the hostname (FQDN) and the IP address that you want to map, then click OK. Click OK again to apply settings. Boot Authentication Boot authentication allows you to authenticate the TeraStation while it’s booting, and also prevents the TeraStation from being used in an unauthorized or unexpected manner, such as in cases of theft.

  • Page 213: Notes Before Use

    Chapter 7 Advanced Features Notes Before Use • To use boot authentication, a Windows PC is necessary to serve as the authentication server. • When activating boot authentication, the drives on the TeraStation will be formatted and all data on the drives will be erased.

  • Page 214: Configuring Boot Authentication On The Terastation

    Chapter 7 Advanced Features Download the application for the authentication server, “Boot Authentication Tool”, from the Buffalo website and install it onto the Windows PC. Register the specific port number that is used on the application as a firewall exception rule. Navigate to Control Panel >...

  • Page 215: If The Terastation Cannot Be Accessed

    Chapter 7 Advanced Features The drive formatting process will start. Click Yes. The “Confirm Operation” screen will open. Enter the confirmation number, then click OK. The format will begin. Wait until it finishes. When formatting finishes and the TeraStation is added to Boot Authentication Tool, boot authentication setting is completed.
  • Page 216 Chapter 7 Advanced Features When the user tries to access the TeraStation’s Settings and the TeraStation is not available, the screen below will be displayed. Have the user forward the decryption key to the authentication server administrator. Open Boot Authentication Tool on the authentication server. From Boot Authentication Tool, right-click the target TeraStation from the list and click Decrypt Passcode.
  • Page 217 Chapter 7 Advanced Features The decrypted 20-digit passcode will be displayed. Send the passcode to the user. The user can then enter the 20-digit passcode into Settings and click OK. If the passcode is authenticated, the TeraStation will become available. The user can click OK to log in to Settings.

  • Page 218: Chapter 8 Drive Replacement

    TeraStation may malfunction. • For the replacement drive of other series TeraStations, use a Buffalo OP-HDN series drive. The replacement drive should be the same size or larger as the original drive. If a larger drive is used, the extra space will not be usable in a RAID array.

  • Page 219: Using A Redundant Raid Mode

    Chapter 8 Drive Replacement Using a Redundant RAID Mode Back up the saved data to another location before replacing the failed drive. If one or more drives fail during drive replacement, data can no longer be retrieved from the TeraStation. Open the front cover with the included key.
  • Page 220 Chapter 8 Drive Replacement Drives without red status LEDs lit are still on. Do not unplug or remove them. Pull out the drive cartridge and remove it from the TeraStation. Insert the new drive into the empty slot with the lock mechanism remaining open. Push here to insert.

  • Page 221: Using Raid 0

    Chapter 8 Drive Replacement Swing the lock back down until it clicks into place. When the replaced drive is recognized, the status LED will flash red and the I31 message will appear on the LCD panel. Close the front cover. Press the function button on the front of the TeraStation.

  • Page 222: Using Jbod

    Chapter 8 Drive Replacement Note: If a drive malfunctions in RAID 0, all data on the RAID array will be lost. All of the settings for the shared folders (such as access restrictions) are erased after replacing a drive from a RAID 0 array. Turn off the TeraStation.

  • Page 223: Using A Hot Spare

    Chapter 8 Drive Replacement Insert the new drive into the empty slot with the lock mechanism remaining open. Swing the lock back down until it clicks into place. Close the front cover. Press the power button on the TeraStation. When the replaced drive is recognized, the status LED will flash red and the I32 message will appear on the LCD panel.
  • Page 224 Chapter 8 Drive Replacement If you must change a drive that is not malfunctioning, either first dismount it in Settings, referring to the “Dismounting Drives” section in chapter 4, or shut down the TeraStation before replacing the drive. If you need to replace more than one drive all at once, replace the drives one at a time to preserve your data.

  • Page 225: Chapter 9 Utilities

    Chapter 9 Utilities NAS Navigator2 NAS Navigator2 is a utility program that makes it easy to display Settings, change the Buffalo NAS device’s IP address, or check its drives. To install NAS Navigator2, refer to the appropriate procedure below for your computer.

  • Page 226: Chapter 10 Appendix

    In such a case, try the corresponding corrective action to recover from the error, described in each section below. If the error is still not resolved, contact Buffalo technical support for assistance. • The power LED keeps blinking instead of turning into a solid glow; follow the procedure at the “Power LED Keeps...

  • Page 227: Booting The Terastation In Emergency Mode

    Chapter 10 Appendix Make sure that “Recover firmware” is selected from the drop-down list under “Action”, then click OK. Note: There are two more options for “Action” other than “Recover firmware”. The details for all options are below: • Use the drive's firmware: The TeraStation will boot using the firmware on the drive. •...

  • Page 228: Cleaning The Dustproof Filter

    Chapter 10 Appendix To recover from emergency mode, follow the procedure below. Download the firmware updater from the Buffalo website. Extract the downloaded file by double-clicking it and launch the updater. Update the firmware for the TeraStation unit that is currently in emergency mode.
  • Page 229 Chapter 10 Appendix Remove the front cover while holding the hook downward. Remove the dustproof filter from the front cover and clear any dust, such as by using a vacuum cleaner. When cleaning is completed, return the filter and the front cover.

  • Page 230: Lcd Panel

    This section explains the details of the event/error code that appears when an event occurs. If there is a corresponding corrective action described for the code, try it first. If the code is still displayed after trying the corrective action, contact Buffalo technical support for assistance. Modes The LCD panel can be cycled through different modes by pressing the display button.

  • Page 231: Errors

    Chapter 10 Appendix LCD Message Description Corrective Action Date Time Displays the date and time set in the Date and Time YYYY/MM/DD TeraStation. hh:mm Displays the IP address. If acquiring from a LANx DHCP DHCP server automatically, “DHCP” will be 192.168.11.150 displayed.

  • Page 232: Status

    Replace the drive by referring to the E30 Replace Drive x removed from the RAID array. “Replacing Drives” section in chapter 8. Contact Buffalo technical support for E41 NVRAM Failure The NVRAM inside the TeraStation failed. assistance. Status After you change settings, one of the following messages will appear on the LCD panel and the info LED will glow amber.
  • Page 233 Chapter 10 Appendix LCD Message Description Corrective Action I26 Initializing Initializing all settings. Settings... I27 Checking USB Checking the USB drive. Drive x... I28 Formatting USB Formatting the USB drive. Drive x... Displays when pressing the function I31 Push Func to Use Press the function button to rebuild the button to rebuild the RAID array after New Drive x...

  • Page 234: Default Settings

    Chapter 10 Appendix LCD Message Description Corrective Action Press and hold down the function button This TeraStation is ready to become I48 Push Func to of the failover backup TeraStation until it the failover backup device for the main Start Failover stops beeping to accept failover backup TeraStation.

  • Page 235: Specifications

    TS6200DN, TS6400DN (with two drives included), TS6400RN (with two RAID Mode drives included): RAID 1 TS6400DN, TS6400RN: RAID 5 Specifications Check the Buffalo website for the latest product information and specifications. IEEE 802.3ab (1000BASE-T), IEEE 802.3u (100BASE- Standards Compliance TX), IEEE 802.3 (10BASE-T) 1GbE LAN Interface...
  • Page 236 Supported RAID TS6400DN, TS6400RN: 0, 1, 5, 6, 10, JBOD (individual Internal Drive drives) Buffalo OP-HDN series drive Note: The replacement drive should be the same Replacement Drive size or larger as the original drive. The drives listed above are available from the Buffalo website.

This manual is also suitable for:

Ts6200dn0402Ts6200dn0802Ts6400dn0804Ts6400dn1604Ts6400dn3204Terastation 6000 ... Show all

Table of Contents
