Oneida Air Systems, Inc. was founded in 1993 to bring cost effective, state-of-the-art
dust collection systems and material handling ductwork to woodworking shops. OAS
designs and manufactures industrial grade dust collection systems that create a prac-
tical, safe and healthy work place environment.
Appearance may vary.
1001 W. Fayette St., Syracuse, NY 13204
ZBM000033
Awarded to our 2hp
Smart Dust Collector
American Woodworker
Dec. - Jan. 2011
www.oneida-air.com
9_11
Advertisement
Table of Contents
Related Manuals for Oneida Air Systems Smart Dust Collector
Summary of Contents for Oneida Air Systems Smart Dust Collector
- Page 1 1001 W. Fayette St., Syracuse, NY 13204 Oneida Air Systems, Inc. was founded in 1993 to bring cost effective, state-of-the-art dust collection systems and material handling ductwork to woodworking shops. OAS designs and manufactures industrial grade dust collection systems that create a prac-...
-
Page 2: Table Of Contents
Thank You for Choosing an Oneida Air Systems Product! OAS manufactures and sells dust collection equipment only. Our qualifi ed technicians and sales staff are available 8:30am - 5:00pm EST Mon. - Fri. to answer any questions concerning OAS products and dust collection. Call for duct- work design and ductwork quotes, including system pricing and shipping cost. -
Page 3: System Start-Up Information
2. Install ductwork completely before operating collector: A.) Seal ductwork with silicone sealant or duct tape. B.) Have dust bin in place and sealed. Smart Dust Collector Owner’s Manual © O.A.S. 2010... - Page 4 For New Product New Patent Pending Flame Guard Arrestor Innovation Bin Level Indicator The Oneida Smart Dust Collector™ is a unique breakthrough in portable dust Remote Control Included collection technology. The Smart System has an infi nitely variable fan curve Silencer...
-
Page 5: Parts List
AFW180000 - Flat Washer USS 5/16” (28) AFT050811 - Hex Nut - 5/8” 11 (2) - 1/2” high RGZ025050 - Gasket 1/2” (25 ft.) RGZ516100 - Gasket 1” (7 ft.) AFT155175 - Whiz Lock Nut 5/16” (6) Smart Dust Collector Owner’s Manual © O.A.S. 2010... - Page 6 All hardware may not be shown because of perspective. Check parts list for complete amounts. Bolt Washer Gasket Material Motor Plate Housing Gasket Material (12) * 35 - Drum Liner Hold Down (Not Shown) Smart Dust Collector Owner’s Manual © O.A.S. 2010...
-
Page 7: Dimensions
Fits through a 36” door. when unit is being moved. Systems Electrical Data 200 to 240 volt single phase 20 amps. A 30 amp circuit breaker is recommended. (Similar to a clothes dryer.) Smart Dust Collector Owner’s Manual © O.A.S. 2010... -
Page 8: System Assembly
Figure 6. Tabs for the back leg braces will be pointed down. Figure 2. Dust drum latches and hardware. Smart Dust Collector Owner’s Manual © O.A.S. 2010... - Page 9 [Figure 12] Fig.10A Fig.10 Attach front wheel and tighten nut on caster assembly to secure. [Figures 12, 13] Figure 13 - Figure 12 - Fig.12 Tighten Nut on caster. Attach wheel Smart Dust Collector Owner’s Manual © O.A.S. 2010...
- Page 10 Tighten up all bolts on the gussets and lid brackets while keeping the legs square. When this is done, tighten up the wheel bolts on the axle to their fi nal positions. Figure 17 - Apply gasket Smart Dust Collector Owner’s Manual © O.A.S. 2010...
- Page 11 Install smaller U - spring nuts Apply 1/2” wide PSA foam rubber strip around top edge of silencer opening. [Figure 31] Figure 31 - Apply gasket Figure 27 - Fasten cowling Plug in Starter. [Figure 28] Smart Dust Collector Owner’s Manual © O.A.S. 2010...
- Page 12 fi lter gasket. [Figure 34] Use outside rows of holes. Figure 36B Figure 36 - Place holder inside bag and drum Figure 34 - Attach fi lter w/ holder Smart Dust Collector Owner’s Manual © O.A.S. 2010...
-
Page 13: Cleaning External Filter
Replace dust bin. Do not over tighten thumb nuts. Filter J-Hook Dust Bin Thumb Nut Dust drums can be lined with plastic bags as long as included Drum Liner Holder is used. Smart Dust Collector Owner’s Manual © O.A.S. 2010... -
Page 14: Fan Motor Maintenance
Table 2 - Lubrication Interval Multiplier Per Baldor specifications, add .30 ounces (8.4 grams) of Mobil Polyrex grease by weight or .6 cubic inches (2 teaspoons) of Mobil Polyrex grease by volume. Smart Dust Collector Owner’s Manual © O.A.S. 2010... -
Page 15: Troubleshooting
Motor Won’t Restart Try re-pushing the red STOP button on the Starter to reset the Starter. If that doesn’t work, unplug the Starter and wait for a minute then replug in and try again. Smart Dust Collector Owner’s Manual © O.A.S. 2010... -
Page 16: Fire Hazards
Electrically ground all equipment and ducting. Static sparks can ignite wood dust. (Avoid using PVC drainpipe) Don’t allow accumulation of layers of fine dust on horizontal surfaces. (Especially overhead lights, electrical boxes, and fuse panels which can ignite dust) Unplug unit before servicing or cleaning. Smart Dust Collector Owner’s Manual © O.A.S. 2010... -
Page 17: Terms And Conditions
Returned Goods Policy Buyer must inform Oneida Air Systems of any shortage or damage, by so noting in writing, on the freight delivery bill prior to signing to indicate receipt of shipment. All claims covered under the limited warranty, are subject to inspection and investigation by Oneida Air Systems. Oneida Air Systems reserves the right to inspect and investigate all returned products before Buyer’s claim is settled.
