DEMO MANUAL DC2397A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 3 C1, C5, C6
2 1 C2
3 2 C7, C8
4 2 C9, C10
5 1 C11
6 1 C12
7 3 R1, R2, R4
8 1 L1
9 1 U1
Additional Demo Board Circuit Components
10 0 C3, C14
11 0 C4
12 0 C13
13 0 R3, R5, R6
14 0 D1
15 6 E1 – E6
16 6 JP1 – JP6
17 6 XJP1 – XJP6
18 4
4
PART DESCRIPTION
CAP CER 1µF 50V 10% X7R 0805
CAP CER 10µF 50V X7R 1210
CAP CER 22µF 25V X7R 1210
CAP CER 0.1µF 50V X7R 0603
CAP CER 4.7µF 6.3V 10% X5R 0603
CAP CER 4.7µF 50V 10% X5R 0805
RES 2MΩ 1/16W 1% 0402 SMD
INDUCTOR, 10µH, ±20%
25V, 600mA BUCK-BOOST DC/DC CONVERTER
CAP , 1210 (OPT)
CAP ALUM 220μF 35V 20% SMD (OPT)
CAP , 0603 (OPT)
RES, 0402 (OPT)
DIODE SCHOTTKY 40V 2A SOD123 (OPT)
TP , TURRET, 0.094", PBF
JMP , 3-PIN 1 ROW 0.079" CC
SHUNT, 0.079" CENTER
SPACER STACKING #4 SCREW NYLON 0.500"
MANUFACTURER/PART NUMBER
MURATA, GRM21BR71H105KA12L
MURATA, GRM32ER71H106KA12L
MURATA, GRM32ER71E226KE15L
MURATA, GRM188R71H104KA93D
MURATA, GRM188R60J475KE19D
MURATA, GRM21BR61H475KE51L
VISHAY, CRCW04022M00FKED
COILCRAFT, XAL4040-103ME
LINEAR TECHNOLOGY, LTC3130UDC-1 #PBF
PANASONIC, EEE-FP1V221AP
ROHM, RB068M-40TR
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
KEYSTONE, 8833
