SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, EtherCAT and
Modbus.
By Pressing the "Set Communication" button from the main window for SW67E52 (Fig. 2) the
window "Set Communication" appears (Fig. 3).
The means of the fields for "Ethernet Connection" are:
In the field "Device Name
defined;
If the field "Obtain an IP Address Automatically (DHCP for Cable
checked, DHCP for LAN connection is enabled;
If the field "Enable DNS" is checked, DNS protocol is enabled;
In the field "Primary DNS" the IP Address of the primary DNS server is defined;
In the field "Secondary
The means for the fields for the "Modbus Slave" are:
In the field "Serial" the serial port to use is defined (RS232 or RS485);
In the field "Baudrate" the baudrate for the serial line is defined;
In the field "Parity" the parity of the serial line is defined;
In the field "Stop Bits" the number of Stop Bits of the serial line is defined;
In the field "ID Device" the ID of Modbus side of the converter is defined;
If the field "Read with Input Register / Status
read the Input bytes of OPC UA side with Input Registers (Function 04) and write the
Output bytes of OPC UA side with Holding Registers (Function 06/16). The Output bytes
are readable with Function 03. Otherwise, only Holding Registers will be used and the
Output bytes of OPC UA side cannot be read back.
ADFweb.com S.r.l.
(Hostname)" the Hostname to assign to the converter is
DNS" the IP Address of the secondary DNS server is defined.
Function" is checked, it is possible to
User Manual EtherCAT Master / Modbus Slave
Document code: MN67E52_ENG
Connection)" is
Figure 3: "Set Communication" window
