QUICK START GUIDE
A - Power button
- a Power button
B b H-button
C c V-button
D d Receiver button
- e Slope / Tilt button
- f (arrow right)
X-axis UP button
- g (arrow left)
X-axis DOWN button
- h (arrow up)
Y-axis UP button
- i (arrow down)
Y-axis DOWN button
J / LED Receiver indicator
K / LED Slope indicator
4
Press Switch the device ON/OFF
Press Switch the remote control ON/OFF
Press Switch between horizontal lines (H2  H1  OFF  H2  ...)
Hold 3 sec. (De-)activate TILT-security
Press Switch between vertical lines (OFF  V2  V1+V2  OFF  ...)
Press (De-)activate the receiver mode (Pulse)
Hold 3 sec. Sets the device in standby mode
Press (De-)activate the slope function
Hold 3 sec. (De-)activate TILT-security
Press (or hold) X-axis rises on the side pointed by the arrow of the x-axis.
Press (or hold) X-axis descends on the side pointed by the arrow of the x-axis
Press (or hold) Y-axis rises on the side pointed by the arrow of the y-axis.
Press (or hold) Y-axis descends on the side pointed by the arrow of the y-axis
No Receiver mode OFF
Green, continuous Receiver mode ON
Green, flash slow Laser in standby
Green, flash Self levelling
Green, continuous Levelled
Red, continuous Slope modus ON
(ONLY ON DEVICE)
(ONLY ON REMOTE CONTROL)
