Futech MULTICROSS 4D ELECTRONIC User Manual page 3

HOUSING
01 Upper horizontal laser line
(H1)
02 Bottom horizontal laser line
(H2)
03 Side vertical laser line
(V1)
04 Front vertical laser line
(V2)
05 Keypad
06 Battery cover
07 1/4" Tripod thread
08 USB-C Power connector
09 Remote control
10 Graphical display
KEYPAD
A Power button
B H-button for horizontal lines
/ Tilt-security button
C V-button for vertical lines
D Receiver button
J Receiver indicator
K Levelling indicator
L Tilt indicator
M Battery indicator
REMOTE CONTROL
a Power button
b H-button for horizontal lines
c V-button for vertical lines
d Receiver / Standby button
e Slope / Tilt-security button
f (arrow right)
X-axis UP button
g (arrow left)
X-axis DOWN button
h (arrow up)
Y-axis UP button
i (arrow down)
Y-axis DOWN button
