PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 3 CIN2, CIN3, CIN4, CIN5
3 2 COUT1, COUT7
4 2 COUT4, COUT5
5 1 C2
6 2 C5, C7
7 1 C6
8 1 C9
9 4 C13, C14, C15, C16
10 1 Q1
11 4 R1, R3, R22, R26
12 4 R5, R24, R27, R36
13 4 R7, R21, R29, R32
14 4 R9, R12, R15, R18
15 2 R10, R13
16 1 R19
17 1 R25
18 1 R30
19 1 R34
20 1 R37
21 1 U1
Additional Circuits
22 0 COUT2, COUT3, COUT6, COUT8,
23 0 C1
24 0 C3, C4, C8, C10, C11, C12
25 0 R2, R4, R6, R8, R11, R14, R16, R17, R20, R23,
R28, R31, R33, R39, R40
26 0 R35
27 0 R38
Hardware/Components (For Demo Board Only)
28 16 E1, E3-E10, E12-E18
29 3 J1, J2, J3
30 6 J4-J9
31 1 JP1
32 1 JP6
33 3 JP2, JP3, JP4
34 1 JP5
35 4 MTGS at 4 corners
36 6 XJP1-XJP6
DEMO MANUAL DC1759A
PART DESCRIPTION
Cap., 150μF, 25V, Aluminum Electr.,
Cap., X5R, 22μF, 25V, 10%, 1210
Cap., 330μF, 6.3V, POSCAP 7343
Cap., X5R, 100μF, 6.3V, 20% 1210
Cap., X7R, 1μF, 25V, 10%, 0805
Cap., X5R, 0.1μF, 25V, 10%, 0603
Cap., 33pF, 10V, 10%, 0603
Cap., 47pF, 10V, 10%, 0603
Cap., X7R, 1μF, 10V, 10%, 0603
N-Channel 30-V Mosfet
Res., Chip, 10Ω, 1%, 0603
Res., Chip, 10k, 1%, 0603
Res., Chip, 0Ω, 1%, 0603
Res., Chip, 60.4k, 1%, 0603
Res., Chip, 6.04k, 1%, 0603
Res., Chip, 8.25k, 1%, 0603
Res., Chip, 13.3k, 1%, 0603
Res., Chip, 191k, 1%, 0603
Res., Chip, 0Ω, 0.5W, 2010
Res., Chip, 0.015Ω, 2W, 2512
LTM4620AEV 15X15X4.41-LGA
OPT 1210
OPT 0805
OPT 0603
OPT 0603
OPT 2010
OPT 2512
TESTPOINT, TURRET, 0.094"
CONN, BNC, 5 PINS
CONN, BANANA JACK, KEYSTONE-575-4
HEADER 4 PIN 0.079 DOUBLE ROW
HEADER 4 PIN 0.079 SINGLE ROW
HEADER 3 PIN 0.079 SINGLE ROW
HEADER 3 PIN 0.079 DOUBLE ROW
STAND-OFF, NYLON 0.50"
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
SUN ELECT., 25CE150AX
MURATA, GRM32ER61E226KE15
SANYO, 6TPF330M9L
AVX, 12106D107MAT2A
AVX, 08053C105KAT2A
AVX, 06033D104KAT
AVX, 0603ZC330KAT2A
AVX, 0603ZC470KAT2A
AVX, 0603ZC105KAT
VISHAY, SUD50N03-09P
NIC, NRC06F10R0TRF
YAGEO, RC0603FR-0710KL
VISHAY, CRCW06030000Z0ED
VISHAY, CRCW060360K4FKED
YAGEO, RC060FR-0760K4L
VISHAY, CRCW06038K25FKED
VISHAY, CRCW060313K3FKED
VISHAY, CRCW0603191KFKED
TEPRO, RN6083
VISHAY, WSL2512R0150FEA
LINEAR TECH., LTM4620AEV
OPT
OPT
OPT
OPT
OPT
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
CONNEX 112404
KEYSTONE 575-4
SAMTEC, TMM104-02-L-D
SAMTEC, TMM104-02-L-S
SAMTEC, TMM103-02-L-S
SAMTEC, TMM-103-02-L-D
KEYSTONE, 8833(SNAP-ON)
SAMTEC, 2SN-BK-G
