Illustration A-1 indicate the location of the following service parts:
Protector XStream Replacement Parts
Item Quantity
1A 1
1B 1
1C 1
1D 1
1E 1
2A 1
2B 1
2C 1
2D 1
2E 1
2F 1
2G 1
2H 1
2I 1
2J 1
2K 1
3 1
4A 1
4B 1
4C 1
4D 1
4E 1
4F 1
4G 1
4H 1
4I 1
Product Service 1-800-522-7658
A
A
D I X
D I X
X
X
C T O R
C T O R
O N E N T S
O N E N T S
Part No. Description
9817000 Valve, Labconco ¼" Compression Fitting
9817001 Valve, Labconco 3/8" Compression Fitting
9817002 Valve, Labconco Deionized ¼" Compression Fitting
9817003 Valve, Labconco Deionized 3/8" Compression Fitting
9818000 Nut, Valve Mtg. (Labconco)
9826800 WaterSaver Valve/Gooseneck -GRN
9826801 WaterSaver Valve/Connector (VAC) – YEL
9826802 WaterSaver Valve/Connector (AIR) – ORG
9826803 WaterSaver Valve/Connector (GAS) – BLU
9826805 WaterSaver Valve/Connector (HOT WATER) – RED
9826806 WaterSaver Valve/Connector (CW) – GRN
9826807 WaterSaver Valve/Connector (STEAM) – BLK
9826808 WaterSaver Valve/Connector (NITROGEN) – BRN
9826809 WaterSaver Valve/Connector (OXYGEN) – LIGHT GREEN
9826810 Swivel Gooseneck only – GRN
9826812 Swivel Gooseneck only – WHITE
9818700 Knobs (GRAY, GRN, BLU, ORG, YEL, RED, WHT, BLK,
thru 08 BRN)
9818800 Hose Barb, GRAY – (NEUTRAL OR ARGON)-NOT SHOWN
9818801 Hose Barb, GREEN - (COLD WATER)-NOT SHOWN
9818802 Hose Barb, BLUE – (GAS)-NOT SHOWN
9818803 Hose Barb, ORANGE – (AIR)-NOT SHOWN
9818804 Hose Barb, YELLOW – (VACUUM)-NOT SHOWN
9818805 Hose Barb, RED – (HOT WATER)-NOT SHOWN
9818806 Hose Barb, WHITE – (DEIONIZED WATER) NOT SHOWN
9818807 Hose Barb, BLACK–(NEUTRAL OR STEAM) NOT SHOWN
9818808 Hose Barb, BROWN – (NITROGEN) NOT SHOWN
