- Page 1 KAIXIN KX5600F Full Digital Ultrasonic Diagnostic Instruments (Vet) User’s Manual Xuzhou Kaixin Electronic Instrument Co., Ltd.
-
Page 2: Table Of Contents
Contents Introduction ................................ I Intellectual Property Information........................I Statement ................................I Warranty and Repair Service ..........................I Manufacturer’s Information ..........................I Important Statement ............................II Warning Symbols and Definitions ........................III Safety Symbols ..............................III Labels................................III Safety Precautions ............................IV Chapter 1 Product Specifications ...................... - Page 3 6.2 Obstetric Measurement ..........................6-3 6.3 Measurement Items ........................... 6-4 Chapter 7 System Maintenance ........................ 7-1 7.1 Daily Maintenance ............................ 7-1 7.2 Use and Maintenance for the Rechargeable Lithium Ion Battery Pack ............ 7-3 7.3 Replaceable Parts ............................7-5 7.4 Backup Data ............................. 7-5 7.5 Troubleshooting ............................
-
Page 4: Introduction
Statement Kaixin has the final explanation right of this user’s manual. Kaixin was considered responsible for the safety, reliability and performance in case of meeting all the following requirements: 1. Assembly, expansion, readjustment, improve and repair are all performed by professionals recognized by Kaixin;... -
Page 5: Important Statement
This user’s manual contains warnings for predictable dangers. Users shall also exercise care at any time to be aware of the dangers unforeseen in this manual. Kaixin shall not be liable for the damages and losses arising out of neglecting to follow the operation instructions herein described. -
Page 6: Warning Symbols And Definitions
Warning Symbols and Definitions The following warning symbols are used in this user’s manual to indicate safety level and other important items. Please remember these symbols and understand the meaning as you read this user’s manual. These symbols convey specific meanings as detailed in the table below: Symbols &... -
Page 7: Safety Precautions
Use of multiple portable socket-outlets may affect protective earth to make leakage currents exceed the safety requirements. You must use the power adapter provided by Kaixin; otherwise electric shock may result. You must adopt the power supply method provided by Kaixin, other power supply modes may result in electric shock. - Page 8 15. When the equipment works abnormally, do stop working, turn off the power and check the reason, then contacts the Kaixin Company about it. 16. It is forbidden to load and unload the probe or move the equipment in galvanic to avoid danger of safety.
- Page 9 Warning: 1. Check the probe and connecting cable before and after diagnostic operation. Use of defective probe may cause electric shock. 2. Do not strike or hit the probe; using the damaged probe may cause electric shock to the patient. 3.
-
Page 10: Chapter 1 Product Specifications
Chapter 1 Product Specifications 1.1 Power Supply Adapter ratings: 100-240V~, 1.2-0.6A, 50-60Hz Adapter model: BJE01-40-001M Output of adapter: DC12.8V 3.0A Main device rating: DC12.8V 3.0A Internal supply voltage: DC11.1V±10% 1.2 Environmental Conditions Operating conditions Ambient temperature: 10℃~40℃ Relative humidity: 30%~75% (without condensation) Atmospheric pressure: 700hPa~1060hPa ... -
Page 11: Chapter 2 System Configuration
Chapter 2 System Configuration 2.1 Standard Configuration Main unit 1 unit 6.5MHz animal transrectal linear array probe 1 PC Power adapter 1 PC Power cable 1 PC Shutter release 1 PC Probe holder 1 PC Strap 1 PC Leather bag 1 PC Plastic sealed box 1 PC... -
Page 12: Chapter 3 Product Introduction
Chapter 3 Product Introduction 3.1 Structure Composition of the Instrument KX5600F Full Digital Ultrasonic Diagnostic Instruments (Vet) are composed of main unit, probe and power adapter etc. 3.2 Components Name 3.3 Parts of the Probe Take 6.5MHz animal transrectal linear array probe for example: Figure: Parts name of 6.5MHz animal transrectal linear array probe... -
Page 13: Symbols Description
1. Main-menu; 2. In frozen status, save image/read image/cine loop. Enter Confirm Freeze/Unfreeze the image; Hold down freeze key for some time to achieve screen display up/down reverse. One-key storage image Adjust the imaging depth Direction Keys Quit various states Power switch 3.5 Symbols Description This instrument uses the symbols listed in the following table, and their descriptions are explained. - Page 14 Fragile Stacking limit by number Temperature limits (Storage and transport) Humidity limitation (Storage and transport) Atmospheric pressure limitation (Storage and transport) Marking for the separate collection of electrical and electronic equipment Product Introduction 3-3...
-
Page 15: Chapter 4 Installation And Check
Chapter 4 Installation and Check Warning : Heat sinks on the upper and lower sides of main unit to allow heat release. Remove this label before using. When main unit is working, the temperature of heat sink may be high. If used, be careful not to touch the heat sink, so as not to burn! 4.1 System Installation Please carefully read through and fully understand the use-method before installing the equipment, and check the goods for its completeness. -
Page 16: Shutter Release Installation
4.2.1 Ultrasonic Probe Connection Warning: Before connecting or using the probe, make sure that the probe, connecting cable and connector are in normal condition (free of cracks or drop). Use of defective probe may cause electric shock. 1. Turn off the system, pinch the oval position on both sides of the probe cable while keep the arrow above, as shown 2. -
Page 17: Video Recorder Installation
Warning: 1. Should be used the power adapter provided by Kaixin. If other adapters are used, it may cause electric shock. 2. Please use the power adapter in the environment specified in the user's manual. -
Page 18: Main Unit Check Before And After Operation
4.7 Main Unit Check Before and After Operation 4.7.1 Inspection Before Start-up Check the following items before starting the machine: 1. The temperature, humidity and atmospheric pressure shall meet the requirements of operation condition. 2. No condensation occurs. 3. No distortion, damage or contamination on system and peripheral. Clean the parts as specified in relevant sections, if the contaminant is present. -
Page 19: Chapter 5 Functional Operation
Chapter 5 Functional Operation 5.1 Startup and Shutdown In shutdown status, press key, machine starts up, power indicator lights. In startup status, hold down key, machine shuts down, power indicator goes out. Please note that when shut down the machine, the time of pressing key is a rather long than normal pressing key. - Page 20 Note: Go beyond the system setting sleep time without pressing any key, the machine will automatically enter the energy saving status. Press any key, the system will return to normal operation status. 5.3.4 Characters Brightness Setting to move cursor to “Setup”; 1.
-
Page 21: Mode Selection
5.3.7 Grid Setting to move cursor to “Setup”; 1. Press key to enter main-menu, press direction keys 2. Press key to enter setting interface; to move the symbol “<” to point to “Grid Set”; 3. Press direction keys to select “00”-“08”; 4. -
Page 22: Image Adjustment And Control
5.4.3 4B Mode 1. In real-time mode, press key to enter 4B mode. 2. 4B image switch. Press key to enter main-menu, press direction keys to move the cursor to “4B Mode”, then press direction keys to switch display among four images; the selected image is activated and the other three are frozen. - Page 23 5.5.2 Total Gain Adjustment In real-time mode, press key to enter main-menu, press direction keys to move cursor to “Gain” in the display area. Press direction key to increase image total gain and direction key to reduce total gain so as to control the total gain of the entire image. 5.5.3 Near Field Gain Adjustment In real-time mode, press key to enter main-menu, press direction keys...
- Page 24 5.5.10 Edge Enhancement Adjustment In real-time mode, press key to enter main-menu, press direction keys to move cursor to “IE” in the display area and then press direction keys to gain four levels of sharpened images. 5.5.11 Local Zoom and Local Additive Color In real time mode, press key to enter main-menu, press direction keys to move cursor...
-
Page 25: Auto Ruler (Automatic Backfat Measure)
5.5.17 Image Freeze/Unfreeze In real-time mode, press key to freeze the image; in frozen status, press key to unfreeze the image. 5.6 Auto Ruler (Automatic Backfat Measure) 1. In real-time B mode, press key to enter main-menu, press direction keys to move cursor to “AutoRuler”... -
Page 26: One-Key Storage Image
5. Press key to quit froze status. 5.9 One-key Storage Image Press key to freeze the image, press key, the system emits a beep, and then the current frozen image is stored in the main unit. Note: 1. One-key storage can saved the current frozen image into the inter memory of main unit;... -
Page 27: Cine Loop
key, the stored image will be deleted, “*” will automatically disappear; 3. Press 4. Repeat the 2-3 steps, delete other images; 5. Press key to return to real-time status. 5.10.4 Review the Image 1. Press key to freeze the image, continuously press key twice to enter reading image status;... -
Page 28: Check List Management
conversion between the letter and punctuation; 4. Press direction keys to choose “numbers” or “characters” and press key to confirm; key to choose “Pregnancy, Unpregnancy, Suspected, 5. After inputting ID, repeatedly press Disease” four kinds of check results; 6. Press key to confirm and exit;... -
Page 29: Chapter 6 Measurement
Chapter 6 Measurement 6.1 General Measurement 6.1.1 Distance Measurement 1. In B, B/B or B/M mode, freeze the desired image, the cursor is located in the “Meas” position of display area; 2. Press key, the measurement methods are showed in the lower left of the screen, press to choose “1. - Page 30 6. Press key again to quit the minor axis status; Press key to exchange the starting point and end point; 7. Press key to finish the first measurement; 8. Repeat the steps from 3 to 7 to complete the multi-group data measurement; 9.
-
Page 31: Obstetric Measurement
Time: denotes cycle measured in ms (millisecond) HR: denotes heart rate measured in times/minute (times per minute) EF: denotes slope measured in mm/s (millimeter per second) The accuracy of software measurement: distance measurement ≤ Attention: 0.1mm; area measurement ≤ 1mm ;... -
Page 32: Measurement Items
to choose “Clear” in display area and press Press direction keys key to clear all marks and data; Press key to unfreeze and return to real-time status. 6.2.3 Measurement of Swine’s Lean percentage Lean percentage calculation formula uses NSIF formula. to choose “OB”... -
Page 33: Chapter 7 System Maintenance
2. Clean the probe with sterile water to remove the residual chemicals after disinfection, because the residual chemicals may be harmful for humans. 3. Kaixin Company will not make any guarantee for the efficacy of disinfector. Please contact the appropriate manufacturer for details. - Page 34 (3) After finishing the rinsing, use a sterilized cloth or gauze to wipe the water on the surface of probe. Do not dry the probe by heating it. 2. High-level disinfection Please follow the disinfection method provided in this user’s manual for disinfection. (1) Before disinfection, wear sterilized gloves to prevent possible infection;...
-
Page 35: Use And Maintenance For The Rechargeable Lithium Ion Battery Pack
3. Check probe after cleaning and disinfection (1) Check the probe enclosure and its cable to ensure they are free of abnormity (such as scuffing, cracks or drop-off); (2) The sound window of probe is thin; ensure that there are no any abnormity on the sound window, such as scuffing, cracks, peeling, bulge and drop-off. - Page 36 When the battery power is too low, the battery power indicator “ ” icon Attention: appears in the lower left corner of the screen and flashed continuously. Connect the main unit to external power supply and recharge the battery, or turn off the machine to recharge.
-
Page 37: Replaceable Parts
International Trade Dept of Kaixin for support. If the following problems occur on starting up the machine, try to make corrections following the method in the table. If the problem remains unsolved, contact International Trade Dept of Kaixin for support. -
Page 38: Periodic Safety Checks
7.6 Periodic Safety Checks To ensure the system performance and safety, it must be checked after using 1 year. When check the instrument, please consult the International Trade Dept of Kaixin or its dealers, as they need to have professional technology engineers. -
Page 39: Chapter 8 Storage And Transportation
Chapter 8 Storage and Transportation 1. If the instrument is stored over 3 months, take out the instrument from the packing case, connect it to power supply for 4 hours, and then disconnect the power and place it in the case again following the direction indicated by arrows on the package. -
Page 40: Chapter 9 Safety Classification
Chapter 9 Safety Classification 1. Classified according to the type of protection against electric shock: Class I EQUIPMENT + internally power EQUIPMENT 2. Classified according to the degree of protection against electric shock: Type B applied part 3. Classified according to the degree of protection against harmful ingress of water: The main unit belongs to IPX4 4. - Page 41 KAIXIN ELECTRONIC XUZHOU KAIXIN ELECTRONIC INSTRUMENT CO., LTD. Kaixin Mansion, C-01, Economic Development Zone, Xuzhou, Jiangsu, China Post Code: 221004 Tel: +86-516-87732932/87733758 Fax: +86-516-87732932/87792848 Website: http://www.kxele.com E-mail: info@kxele.com Information contained in this manual is subject to change without further notice.
