- Page 1 KAIXIN MSU1Plus Full Digital Mechanical Sector Scanning Ultrasonic Diagnostic Instruments (Vet) User’s Manual Xuzhou Kaixin Electronic Instrument Co., Ltd.
- Page 2 Statement Kaixin has the final explanation right of this user’s manual. Kaixin was considered responsible for the safety, reliability and performance in case of meeting all the following requirements: 1. Assembly, expansion, readjustment, improve and repair are all performed by professionals recognized by Kaixin;...
- Page 3 This user’s manual contains warnings for predictable dangers. Users shall also exercise care at any time to be aware of the dangers unforeseen in this manual. Kaixin shall not be liable for the damages and losses arising out of neglecting to follow the operation instructions herein described.
- Page 4 User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Safety Cautions 1. Warning Symbols and Definitions The following warning symbols are used in this manual to indicate safety level and other important items. Please remember these symbols and understand the meaning as you read this user’s manual. These symbols convey specific meanings as detailed in the table below: Symbols &...
-
Page 5: Table Of Contents
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Contents Chapter One Technical Specifications………………………………………………………………1 Chapter Two Product Outline………………………………………………………………………2 2.1 Structure composition of the instrument……………………………………………………2 2.2 Name of parts and components…………………………………………………………2 2.3 Parts of the probe……………………………………………………………………………2 2.4 Function keys description………………………………………………………………….. 2 Chapter Three System Configuration………………………………………………………………3 Chapter Four... - Page 6 User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) 6.4.7 Frame Correlation Adjustment………………………………………………………………11 6.4.8 Image Processing Adjustment………………………………………………………………11 6.5 Image Control……………………………………………………………………………11 6.5.1 Magnification Selection……………………………………………………………………11 6.5.2 Depth Range Selection……………………………………………………………………12 6.5.3 Local Zoom and Local Additive Color……………………………………………………12 6.5.4 Image Left/right Reverse……………………………………………………………………12 6.5.5 Image Up/down Reverse……………………………………………………………………12 6.5.6 Color Selection………………………………………………………………………………12 6.5.7 Image Filter…………………………………………………………………………………12...
-
Page 7: Chapter One Technical Specifications
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter One Technical Specifications 1.1 Technical Data 1. Gray scale: 256 2. Monitor: 5.7” LED 3. Adapter rating: 100-240V~, 1.2-0.6A, 50-60Hz (model: BJE01-40-001M) 4. Output of adapter: DC12.8V 3.0A 5. -
Page 8: Chapter Two Product Outline
Chapter Two Product Outline 2.1 Structure composition of the instrument MSU1Plus full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) are composed of main unit and probe, etc. 2.2 Name of parts and components Fig. MSU1Plus main unit sketch map 2.3 Parts of the probe... -
Page 9: Chapter Three System Configuration
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter Three System Configuration 3.1 Typical configuration 1. Main unit 1 unit 2. 3.5MHz mechanical sector probe 1 PC 3. Power adapter 1 PC 4. Internal battery 1 PC 5. -
Page 10: Chapter Five System Installation And Check
Warning: 1. When instrument works abnormally, do stop working, turn off the power and check the reason, then contacts the KAIXIN Company about it. 2. Turn off power and pull out of the plug from socket after each ultrasonic diagnostic operation. - Page 11 User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) As shown in fig, insert the support bracket from the back of the instrument, place the instrument on a desktop; adjust the angle of the support bracket to adjust the screen visual angle. 2.
-
Page 12: Ultrasonic Probe Installation
Probe is highly sensitive to shake, be used with caution. About probe’s use and cleaning, the details see the relevant sections. Warning: 1. The Kaixin ultrasonic probe shall be connected to the dedicated Kaixin ultrasonic system only. Select proper probe model according to the relevant instructions of ultrasonic diagnostic system. -
Page 13: Shutter Release Installation
1. Adapter has no switch. The isolation of the system with the MAINS used to unplug the adapter as the intended isolation means. 2. The device should be used only with power adapter provided by Kaixin Company. 3. To avoid damaging power adapter or harming people by unexpected fallen, make sure the power adapter is placed on the leveled desk. -
Page 14: Ultrasonic Probe Check Before And After Operation
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) 5.7 Ultrasonic probe check before and after operation Before and after ultrasonic diagnosis to check the probe or cable jacket whether has any abnormalities, such as cracks, bulge or oil leakage, whether it be cleaned or disinfected. 5.8 Main unit check before and after operation 5.8.1 Inspection before start-up Check the following items before starting the machine:... -
Page 15: Chapter Six Functional Operation
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter Six Functional Operation 6.1 Startup and Shutdown In shutdown status, press key, machine starts up, power indicator lights. In startup status, press key, machine shuts down, power indicator goes out. Please note that when shut down the machine, the time of pressing key is a rather long than normal pressing key. -
Page 16: Key Sound Setting
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Press direction keys to move cursor to point to Caps, and then press key to achieve capital and small letter conversion; If the cursor point to Shift, press key to achieve the conversion between the letter and punctuation;... -
Page 17: Image Quality Adjustment
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) 2. Change of M speed: Press key to enter main-menu and press direction keys to move cursor to “M Speed” and then press direction keys to select the four kinds of scan speed. 3. -
Page 18: Depth Range Selection
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) 6.5.2 Depth Range Selection In real-time and B mode, press key to enter main-menu and press direction keys to move cursor to “Depth” in the display area and then press direction keys to select depth, press key to quit depth range selection. -
Page 19: Body Mark And Probe Mark
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Lithotripsy positioning line: In real-time B mode, press key to enter main-menu and press direction to move cursor to “Puncture” and then press direction keys keys to choose line 3, press to confirm, lithotripsy positioning line appears on the screen;... -
Page 20: Open Image
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) preceded with asterisk “*”; 5. Press key to quit saving status and press key to return to real-time status. Storage to U disk 1. Plug U disk; 2. -
Page 21: Delete Obstetric Records
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) spreadsheet on the folder of the U disk; the folder is automatically named by the system current date; the EXCEL spreadsheet is automatically named by the system current time; 6. -
Page 22: Chapter Seven General Measurement
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter Seven General Measurement 7.1 Distance Measurement to move cursor to “Measure”; or in the 1. In B mode, freeze desired image, press direction keys B/B or B/M mode, freeze desired image, the cursor is located in the “Measure” position of display area;... -
Page 23: Slope/Heart Rate/Cycle Measurement
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) to choose “Trace”, press key again, the cursor will show “+”; keys 3. Press direction keys to move the “+” mark to desired position, press key to set the “+” mark position as the starting point of the measurement;... -
Page 24: Chapter Eight Obstetric Measurement
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter Eight Obstetric Measurement 8.1 Measurement and Calculation items Obstetric tables of the system including “1.BOVINE 2.EQUINE 3.OVINE 4.CANINE 5.FELINE 6.GOAT 7. LLAMA 8.SWINE”, which is reference for doctor. 8.2 Measurement of Gestational Age (GA) and Estimated Date of Confinement (EDC) Follow the steps below: to choose “OB Measure”... -
Page 25: Chapter Nine System Maintenance
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter Nine System Maintenance The system maintenance should be performed by the user and service engineer. Users shall be in full charge of maintenance and operation of the system after purchasing the product. 9.1 Maintenance by users 9.1.1 System cleaning and disinfection Warning... - Page 26 1. Clean the probe with sterile water to remove the residual chemicals after disinfection, because the residual chemicals may be harmful for humans. 2. Kaixin Company will not make any guarantee for the efficacy of disinfector. Please contact the appropriate manufacturer for details.
-
Page 27: Use And Maintenance For The Rechargeable Battery
9.1.2 Use and maintenance for the rechargeable battery 1. Only use charger and the corresponding battery provided by KaiXin Company. 2. The output port of adapter plugs into the input port of charger to charge; the minimum charging time is 3 hours and up to 4 hours. -
Page 28: Troubleshooting
International Trade Dept of Kaixin for support. If the following problems occur on starting up the machine, try to make corrections following the method in the table. If the problem remains unsolved, contact International Trade Dept of Kaixin for support. -
Page 29: Periodic Safety Checks
9.3 Periodic Safety Checks To ensure the system performance and safety, it must be checked after using 1 year. When check the instrument, please consult the International Trade Dept of Kaixin or its dealers, as they need to have professional technology engineers. -
Page 30: Chapter Ten Storage And Transportation
User’s Manual V1.03 Full digital mechanical sector scanning ultrasonic diagnostic instruments (Vet) Chapter Ten Storage and Transportation Storage and Transportation 1. If the instrument is stored over 3 months, take out the instrument from the packing case, connect it to power supply for 4 hours, and then disconnect the power and place it in the case again following the direction indicated by arrows on the package. - Page 31 KAIXIN ELECTRONIC XUZHOU KAIXIN ELECTRONIC INSTRUMENT CO., LTD. Kaixin Mansion, C-01. Economic Development Zone, Xuzhou, Jiangsu, China. Post Code: 221004 Tel: +86-516-87732932/87733758 Fax: +86-516-87732932/87792848 Website: http://www.kxele.com E-mail: info@kxele.com Shanghai International Holding Corp. GmbH (Europe) Eiffestrasse 80, 20537 Hamburg, Germany Information contained in this manual is subject to change without further notice.
